Summary of Contents for Brownlee Precision 410
- Page 1 Instruction Manual Brownlee Precision Model 410 Four-Channel Instrumentation Amplifier...
-
Page 2: Operating Instructions
Brownlee Precision Model 410 Four-Channel Instrumentation Amplifier Power: The Model 410‟s power requirements are 120 VAC, 47-63 Hz unless otherwise indicated on the back panel near the power connector. Run an IEC line cord from a wall socket to the back panel power connector. - Page 3 Amplifier Settings: There are 5 main parameters, which can be adjusted on each amplifier channel: Gain, Lowpass Filter cutoff frequency, Output Offset voltage, Input Selection, and Input Coupling. There is a button corresponding to each one of these parameters. Pushing one of these buttons puts that parameter‟s value on the 8-digit alphanumeric display.
- Page 4 To select which input is to be amplified, push the „Input Select‟ button and turn the knob until desired configuration is displayed. “Gnd” ignores both input lines and internally ties the inputs to 0 Volts for equipment setup and testing. The “A” setting amplifies the single-ended signal on the A input.
- Page 5 The electronic components at each stage of the amplifier have inherent offset voltages, which could appear as a shift of the “zero” level of the output. The Brownlee Precision Model 410 has a self- trimming feature, which compensates for these errors automatically.
- Page 6 Lithium Rechargeable Battery: Very unlikely this battery will lose its charge. If the amplifier is no longer holding its settings when power is turned off, or you find you must frequently push the reset button to turn the amplifier on, then contact Brownlee Precision Company for replacement instructions.
- Page 7 (This page is intentionally left blank!)
-
Page 8: Amplifier Specifications
Amplifier Specifications: Gain Range 1 to 10,000 Gain Accuracy < 2% error Input Impedance 1 M, 15 pF Input Voltage Range +/- 10 Volts Input Bias Current < 50 pA Input Offset Voltage < 5 µV Common Mode Rejection Ratio >... - Page 9 Serial number: _______________ Firmware version: V 3.0 Ship Date: _______________ Warranty: 12 months, parts and labor Instruction manual: 410 Rev. G For inquiries call: 1-650-209-6666 Phone 1-408-538-3101 Fax mail@brownleeprecision.com www.brownleeprecision.com Brownlee Precision Company 2318C Walsh Ave Santa Clara, CA 95051 USA...
- Page 10 April 2014 Brownlee Precision Company 2318C Walsh Ave. Santa Clara, CA 95051 1-650-209-6666 Phone 1-408-538-3101 Fax mail@brownleeprecision.com www.brownleeprecision.com...
