FlashLogic FLC-AL-CH6 Install Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
audiovox electronics corp.
iNstall Guide
flc-al(Dl)-ch6
available for : flcaN
Rev. Date: August 30, 2011
Doc. No.: ##6085##
20110829
please visit www.flash-it.com for complete product details
The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2011
!
NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
review the Installation Guide carefully before beginning any work.
CH6

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLC-AL-CH6 and is the answer not in the manual?

Questions and answers

Summary of Contents for FlashLogic FLC-AL-CH6

  • Page 1 audiovox electronics corp. iNstall Guide flc-al(Dl)-ch6 available for : flcaN Rev. Date: August 30, 2011 Doc. No.: ##6085## 20110829 please visit www.flash-it.com for complete product details The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2011 NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of this product, be that either damage to the vehicle itself or to the installed device.
  • Page 2 XX-XX ADS-AL(DL)-CH6 PAGE X-X PAGE 2-4 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 2 of 14 20110829 Doc. No.: ##6085## inSTALL TYPE SELECTiOn FEATURES 300M 99-04 • • • • • • • • • • • • 300M w/Alarm 99-04 •...
  • Page 3 XX-XX XX-XX VEHICLE OWNER NOTICE DETECT OEM ALARM PAGE X-X PAGE X-X ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 3 of 14 20110829 Doc. No.: ##6085## DETECT OEM ALArM EQUiPPED VEHiCLES nOTiCE WITH OEM KEYFOB WITHOUT OEM KEYFOB Close hood and trunk/hatch. Open driver’s door window.
  • Page 4 XX-XX ADS-AL(DL)-CH6 T1 PAGE X-X PAGE X-X ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 4 of 14 20110829 Doc. No.: ##6085## TYPE 1 - wirE CrOSS rEFErEnCE CHArT wirE CrOSS rEFErEnCE CHArT IGNITION J1850 300M 99-04 Blue/White Violet/Yellow Concorde 99-04 Blue/White Violet/Yellow 99-01 Blue/White...
  • Page 5 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 5 of 14 20110829 Doc. No.: ##6085## TYPE 1 - wiring DiAgrAM REMOTE STARTER TACH (AC) INPUT TACH (AC) INPUT <- REQUIRED E-BRAKE STATUS (-) INPUT E-BRAKE STATUS (-) INPUT <- REQUIRED TRUNK (-) OUTPUT TRUNK (-) OUTPUT <- REQUIRED...
  • Page 6 XX-XX ADS-AL(DL)-CH6 T2 PAGE X-X PAGE X-X ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 6 of 14 20110829 Doc. No.: ##6085## TYPE 2 - wirE CrOSS rEFErEnCE CHArT wirE CrOSS rEFErEnCE CHArT IGNITION J1850 Pacifi ca 04-08 Pink/Gray White/Violet Town &...
  • Page 7 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 7 of 14 20110829 Doc. No.: ##6085## TYPE 2 - wiring DiAgrAM IMPORTANT: OEM ALARM EQUIPPED VEHICLES MAY CHIRP ONCE UPON REMOTE START. TO AVOID HORN CHIRP, THE REMOTE STARTER MUST BE SET TO UNLOCK BEFORE REMOTE START AND TO LOCK AFTER REMOTE START.
  • Page 8 XX-XX ADS-AL(DL)-CH3 T3 PAGE X-X PAGE X-X ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 8 of 14 20110829 Doc. No.: ##6085## TYPE 3 - COMPOnEnT LOCATOr XX-XX ADS-AL(DL)-CH6 T3 BLACK COVER GREY COVER BCM: 300M, CONCORDE, INTREPID PAGE X-X PAGE X-X WHITE COVER BCM: LIBERTY...
  • Page 9 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 9 of 14 20110829 Doc. No.: ##6085## TYPE 3 - wiring DiAgrAM REMOTE STARTER TACH (AC) INPUT TACH (AC) INPUT <- REQUIRED E-BRAKE STATUS (-) INPUT E-BRAKE STATUS (-) INPUT <- REQUIRED DISARM (-) OUTPUT DISARM (-) OUTPUT <- REQUIRED...
  • Page 10 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 10 of 14 20110829 Doc. No.: ##6085## TYPE 4 - wiring DiAgrAM RESISTOR BETWEEN 180-210 0HMS USE ISOLATED GROUND WHEN RUNNING FROM REMOTE STARTER TO POWER RELAY DIODE 1N4001 REMOTE STARTER TACH (AC) INPUT TACH (AC) INPUT <- REQUIRED E-BRAKE STATUS (-) INPUT...
  • Page 11 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 11 of 14 20110829 Doc. No.: ##6085## TYPE 5 - wiring DiAgrAM RESISTOR BETWEEN 180-210 0HMS USE ISOLATED GROUND WHEN RUNNING FROM REMOTE STARTER TO POWER RELAY DIODE 1N4001 REMOTE STARTER TACH (AC) INPUT TACH (AC) INPUT <- REQUIRED E-BRAKE STATUS (-) INPUT...
  • Page 12 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 12 of 14 20110829 Doc. No.: ##6085## TYPE 6 - wiring DiAgrAM REMOTE STARTER TACH (AC) INPUT TACH (AC) INPUT <- REQUIRED E-BRAKE STATUS (-) INPUT E-BRAKE STATUS (-) INPUT <- REQUIRED UNLOCK (-) OUTPUT UNLOCK (-) OUTPUT <- REQUIRED...
  • Page 13 XX-XX ADS-AL(DL)-CH6 PAGE X-X PAGE X-X ALL IN ONE iNstall Guide ADS-AL(DL)-CH6 Chrysler/DoDge/Jeep ADS-DL-CH6 98 ADS-TB-CH6 98 FLC-AL(DL)-CH6 Page 13 of 14 20110829 Doc. No.: ##6085## inSTALLATiOn MODE SELECTiOn MODULE PrOgrAMMing Press and release Press and hold programming button programming button to select installation mode.
  • Page 14 XX-XX CLASSIC PAGE X-X PAGE 1-1 ALL IN ONE iNstall Guide Chrysler/DoDge/Jeep FLC-AL(DL)-CH6 Page 14 of 14 20110829 Doc. No.: ##6085## iDEnTiFY VEHiCLE YEAr Locate the Vehicle Identifi cation Match the VIN’s 10th character Number (VIN) and identify the to its corresponding year. 10th character.
