Summary of Contents for Cyber Solutions CTAP 10-100M
- Page 1 In-Line 10/100M Ethernet Tap PCI CARD CTAP-10/100M User Manual...
-
Page 2: Table Of Contents
Contents Contents of the package Getting Started The Components Installation Hardware specification Troubleshooting Warranty... -
Page 3: Contents Of The Package
Contents of the package The package contains- An In-Line 10/100M Ethernet Tap card (Figure 1) A Connector (Figure 2) A User Manual and Warranty(Figure 3) Figure 1. In-Line 10/100M Ethernet Tap card Figure 2. A Connector Figure 3. A User Manual and Warranty... -
Page 4: Getting Started
Getting Started In-Line 10/100M Ethernet Tap CARD is a PCI half length type card. It allows monitoring of communication data without affecting the communications. It can be installed in any computer by simply inserting the card in an empty PCI slot. Typical usage scenarios: In Network Intrusion Detection devices In Network Traffic Measurement and Analysis devices... -
Page 5: The Components
The Components View of the back panel Part name Description (1) Power LED It lights up when the power supply is on. (2) PC-A socket to connect to computer or router. (3) HUB-B socket to connect to HUB. (4) MON-B (Monitor Port) socket to connect with monitor computer. -
Page 6: Installation
Installation 1) Fixing the CARD Power off the computer and then pull out the power-supply plug. Insert the In-Line 10/100M Ethernet Tap PCI CARD into the PCI slot of the computer. 2) Connection Connect the CARD as shown in connection diagram. (*1) Connect to the computer or router from the PC-A port. -
Page 7: Block Diagram
Note. Please ensure that the length of the cables to/from the CARD is less than 90m Block diagram... -
Page 8: Hardware Specification
Hardware specification Operating Environment Temperature:0-40 Humidity: 10-90 % (No condensation) External Dimensions Approximately 122(W)×89(H)×20(D) (The protrusion is not included) Electric Current consumption 380mA Weight Approximately 82g... -
Page 9: Troubleshooting
Troubleshooting The link connected to the monitor port of the card does not come up or is instable Generally the network interface auto configures itself to half, or full duplex. In case the link does not come up, You may need to manually configure the interface corresponding to the computer interface to the desired communication speed, and other settings.
