SOLAR BOOST™ 6024H
60AMP 12/24VDC MAXIMUM POWER POINT TRACKING
INSTALLATION AND OPERATION
2003167
THIS MANUAL INCLUDES IMPORTANT SAFETY INSTRUCTIONS FOR MODELS
CE MANUEL CONTIENT D'INSTRUCTIONS IMPORTANTES POUR LES MODELES
DIESES HANDBUCH ENTHÄLT WICHTIGE HINWEISE FÜR DIE MODELLE
ESTE MANUAL INCLUYE INSTRUCCIONES DE SEGURIDAD IMPORTANTES PARA
COVERED UNDER ONE OR MORE OF THE FOLLOWING US PATENTS
© RV Power Products, Inc. 2002
HIGH VOLTAGE INPUT
PHOTOVOLTAIC CHARGE CONTROLLER
MANUAL
CONFORMS TO
UL STD. 1741
CERTIFIED TO
CAN/CSA STD. E335-1/2E
CONFORMS TO
EN 50081-1
EN 50082-1
EN 60335-1
SB6024HL, SB6024HDL, SB50RD25
SAVE THESE INSTRUCTIONS
SB6024HL, SB6024HDL, SB50RD25
PRIERE DE SAUVEGARDER CES INSTRUCTIONS
SB6024HL, SB6024HDL, SB50RD25
BITTE BEHALTEN SIE DIESE HINWEISE
LOS MODELOS
SB6024HL, SB6024HDL, SB50RD25
CONSERVE ESTAS INSTRUCCIONES
6,111,391 • 6,204,645
This device complies with part 15 of the
FCC rules. Operation is subject to the
following two conditions: 1) This device
may not cause harmful interference, and 2)
This device must accept any interference
received, including interference that may
cause undesired operations.
430-0017 C
Advertisement
Table of Contents
Summary of Contents for RV Products SB6024HL
- Page 1 EN 50081-1 cause undesired operations. EN 50082-1 EN 60335-1 THIS MANUAL INCLUDES IMPORTANT SAFETY INSTRUCTIONS FOR MODELS SB6024HL, SB6024HDL, SB50RD25 SAVE THESE INSTRUCTIONS CE MANUEL CONTIENT D’INSTRUCTIONS IMPORTANTES POUR LES MODELES SB6024HL, SB6024HDL, SB50RD25 PRIERE DE SAUVEGARDER CES INSTRUCTIONS DIESES HANDBUCH ENTHÄLT WICHTIGE HINWEISE FÜR DIE MODELLE...
-
Page 2: Table Of Contents
RV Power Products - Solar Boost 6024H TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS .................... 2 PRODUCT DESCRIPTION ......................... 6 Part Numbers and Options ....................6 OPERATION ............................6 Optional Digital Display......................7 Charge Status Indicator ......................8 Three Stage Charge Control ....................8 Bulk Charge....................... -
Page 3: Important Safety Instructions
Installation and Operation Manual IMPORTANT SAFETY INSTRUCTIONS This manual contains important instructions for Models; SB6024HL, SB6024HDL, SB50RD25 SAVE THESE INSTRUCTIONS 1. Refer installation and servicing to qualified service personnel. High voltage is present inside unit. Incorrect installation or use may result in risk of electric shock or fire. - Page 4 RV Power Products - Solar Boost 6024H IMPORTANT INSTRUCTIONS DE SECURITÉ Ce manuel contient d’instructions importantes pour les modèles SB6024HL, SB6024HDL, SB50RD25 PRIÈRE DE SAUVEGARDER CES INSTRUCTIONS 1. Pour l’installation et la maintenance, consulter le personnel qualifié. L’unité contient des composantes de haut voltage. L’installation incorrecte pourrait entraîner des risques de choc électrique ou d’incendie.
-
Page 5: Wichtige Sicherheitshinweise
Installation and Operation Manual WICHTIGE SICHERHEITSHINWEISE Dieses Handbuch enthält wichtige Hinweise für die Modelle SB6024HL, SB6024HDL, SB50RD25 BITTE BEHALTEN SIE DIESE HINWEISE 1. Vertrauen Sie Installation und Reparaturen nur Fachpersonnel an. In der Einheit bildet sich eine hohe Stromspannung. Eine falsche Installation oder Benutzung kann einen elektrischen Schock oder einen Brand als Folge haben. -
Page 6: Instrucciones De Seguridad Importantes
RV Power Products - Solar Boost 6024H INSTRUCCIONES DE SEGURIDAD IMPORTANTES Este manual de instrucciones es para modelos; SB6024HL, SB6024HDL, SB50RD25 CONSERVE ESTAS INSTRUCCIONES 1. Solamente permita la instalación y el servicio técnico a personal capacitado. Existe la presencia de alto voltaje en el interior de la unidad. El uso o la instalación incorrecta pueden resultar en descarga eléctrica o fuego. -
Page 7: Product Description
SB6024HDL ......Solar Boost 6024H controller with digital display • SB50RD25 ......SB6024H remote digital display with 25’ cable (standard duplex box mount) • SB6024HPDL......SB6024HDL front panel with digital display (add to SB6024HL to make SB6024HDL) • 930-0022-20......SensorLug™ battery temperature sensor with 20’ cable •... -
Page 8: Optional Digital Display
RV Power Products - Solar Boost 6024H Una vez instalado y configurado, las operaciones de control de carga y del MPPT son completamente automáticas. La carga se enciende siempre que el conjunto fotovoltaico sea capaz de producir ≈0.2 Amperes a ≈4.0V por encima de la tensión de la batería. Cuando la carga con el conjunto fotovoltaico esté encendida, el LED de estado de carga indicará... -
Page 9: Charge Status Indicator
20 amps of output current. CHARGE STATUS INDICATOR An LED charge status indicator is provided both with and without the optional digital display. Indicator function is identical for the SB6024HL, SB6024HDL, and SB50RD25. CHARGE STATUS INDICATOR INDICATEUR ETAT CHARGE... -
Page 10: Bulk Charge
RV Power Products - Solar Boost 6024H Bulk Charge During the bulk charge stage the battery is typically less than 70% charged, and the unit delivers as much charge current as possible to rapidly recharge the battery. Bulk charge occurs when; 1) Charge current during float increases above the Float Transition Current setting, or 2) Insufficient charge current is available to hold the battery at the desired acceptance or float voltage. -
Page 11: Float Charge
Installation and Operation Manual Float Charge Once the battery is fully charged the unit switches to float, where the float voltage is applied to the battery to maintain it in a fully charged state without excessive water loss. The float voltage is factory set to ≈13.3/26.6V. -
Page 12: Disabling Equalization
RV Power Products - Solar Boost 6024H températures basses. L’égalisation est activée lorsque le bouton-poussoir rouge de l’égalisation est relâché. VORSICHT: Die Angleichung ist eine kontrollierte Überbeladung der Batterie bei einer relativ hohen Stromspannung indem eine hohe Batteriegasierung erzeugt wird. Eine Handangleichungsfunktion wird besorgt, denn ein Operator soll immer den Vorgang plannen und monitorisieren. -
Page 13: Maximum Power Point Tracking (Mppt)
Installation and Operation Manual When mounted vertically as described in the installation section, the unit can deliver full output in an ambient temperature of up to 40°C (104°F). If an over temperature condition exists, the unit will cycle on/off, reducing average power delivery to within safe limits. -
Page 14: Installation
RV Power Products - Solar Boost 6024H TYPICAL 48V IN / 24V OUT CURRENT BOOST PERFORMANCE (EIGHT 75 WATT MODULES) BATTERY CONDITION AMBIENT PV INPUT OUTPUT CHARGE PERCENT AND VOLTAGE CONDITIONS CURRENT CURRENT INCREASE FULLY DISCHARGED 4.40 AMPS 12.10 AMPS 35°F 21.8V EARLY MORNING... - Page 15 Installation and Operation Manual CAUTION: The Solar Boost 6024H must be used to charge a lower voltage battery from a higher voltage PV array. If the unit was a conventional non-MPPT type controller using the same nominal input would be 48 amps (60A ÷ 1.25). Since input and output voltage, maximum PV input short circuit current I voltage is much higher than output voltage, I must be reduced by the ratio of conventional system PV...
-
Page 16: Over Voltage / Reverse Polarity Protection
RV Power Products - Solar Boost 6024H OVER VOLTAGE / REVERSE POLARITY PROTECTION Solar Boost 6024H is fully protected against reverse polarity and high voltage transients for both the PV and the battery. If the battery is connected reverse polarity, Solar Boost 6024H will not operate. If the PV array is connected reverse polarity, Solar Boost 6024H will not provide output current and the Solar Panel Current display will show negative current. -
Page 17: Grid Tied Systems
Installation and Operation Manual GRID TIED SYSTEMS Systems configured to sell excess PV power to the power grid use inverters specially designed for this purpose. In grid tied systems it is the inverter that actually controls battery voltage and therefore battery charge. Maximum power will be delivered to the grid if the Solar Boost 6024H remains in it’s bulk charge mode while selling to the grid. -
Page 18: Charge Mode
RV Power Products - Solar Boost 6024H Charge Mode Solar Boost 6024H can be configured for two stage or three stage charging. Typically three stage charge is used, but certain battery types or system configurations (such as grid tied systems) may benefit from two stage charge. When configured for two stage charge, equalization still operates as described. -
Page 19: Float Transition Current Measurement Shunt
Installation and Operation Manual Float Transition Current Measurement Shunt Solar Boost 6024H can use the internal current shunt measuring Output Charge Current, or an external current shunt measuring net battery current to determine full charge. When the battery is unloaded during charge or the load during charge is relatively constant, use the internal shunt. -
Page 20: Maximum Power Voltage
RV Power Products - Solar Boost 6024H La valeur établie du courant de transition de flotteur contrôle le moment où le système passe de l’acceptance au flotteur. Si le courant de chargement a une valeur inférieure à la valeur du courant de transition de flotteur pendant la phase d’acceptance, l’on considère que la batterie est chargée et le système passe à... -
Page 21: Optimizing Mppt
Installation and Operation Manual le réglage soit correct pour que le système de conversion optimale d’énergie fournisse un accroissement maximal du courant. La valeur spécifiée par les producteurs est de 4.4 volts, valeur qui correspond à plusieurs modules fréquents. Die nominale MPPT Einstellung bildet den Unterschied zwischen der offenen Stromkreisspannung (V des PV Moduls und der maximalen Stromkraftspannung (V ). -
Page 22: Acceptance Charge Voltage
RV Power Products - Solar Boost 6024H Acceptance Charge Voltage Acceptance and Float charge voltage setpoints are calibrated by adjusting actual battery charge voltage as measured at the Solar Boost 6024H’s battery terminals. Setting charge voltage therefore requires that the battery be at or near full charge so that the unit is actually controlling battery voltage. -
Page 23: Metallic Conduit
Installation and Operation Manual VORSICHT: Setzen Sie die Einheit mit senkrecht orientierten Heizungssenkungskanten ein, um die Konvektionskühlung zu fördern und schließen Sie sie nicht in einem geschlossenen Raum ein. Wenn sie nicht senkrecht angesetzt sind, kann der Durchschnittsausgangsstrom gesenkt werden um die von hohen Temperaturen verursachten Beschädigungen zu vermeiden. -
Page 24: Battery And Pv Wiring
RV Power Products - Solar Boost 6024H BATTERY AND PV WIRING WARNING: This unit must be installed and wired in accordance with National Electrical Code, ANSI/NFPA 70. Over current protection for the battery must be provided externally. To reduce the risk of fire, connect to a circuit provided with 75 amperes maximum branch-circuit over current protection in accordance with National Electrical Code, ANSI/NFPA 70. -
Page 25: Optional External Current Shunt
Installation and Operation Manual Larger wire sizes will tend to improve boost performance whereas smaller wire sizes will reduce boost performance. When considering wiring, fuse, and connection options think big and short as larger heavier components and shorter wire lengths offer less resistance and voltage drop. -
Page 26: Input Power Sources Other Than Pv Modules
RV Power Products - Solar Boost 6024H INPUT POWER SOURCES OTHER THAN PV MODULES The Solar Boost 6024H is a high efficiency series pass “buck” type power converter and can operate with power sources other than PV. Examples of this type of charge control include hydroelectric or wind generators, or charging a 24 volt battery from a 48 volt electrical system. - Page 27 Installation and Operation Manual SYMPTOM PROBABLE CAUSE ITEMS TO EXAMINE OR CORRECT Charge current is Battery is highly charged Normal operation, system will be in Acceptance or Float and current is reduced to lower than expected, control battery voltage. PV current may be low as well Worn out PV modules Replace, or use as is.
-
Page 28: Specifications
RV Power Products - Solar Boost 6024H SPECIFICATIONS Output current rating ......60A Temperature compensation Max. PV short circuit current....32A Lead-Acid ......-5.0mV/°C/cell Output current limit......60± ± ± ± 2A NiCd ........-2.0mV/°C/cell PV input voltage......... 36V/48VDC nominal Current consumption Max.
