Summary of Contents for Inno home Stove Guard SGK300
- Page 1 INNOHOME Stove Guard SGK300 user manual www.innohome.com smart safety for your kitchen...
- Page 2 Congratulations! You now own one of the most intelligent cooker safety products in the world. Control Unit SGC500-2 Intelligent Heat Sensor SGS300 Control Unit SGC500-3...
-
Page 3: Table Of Contents
CONTENTS 1. Innohome Stove Guard and how to use it 1.1. A quick guide 1.2. Structure of the Stove Guard 1.3. Stove Guard use and features 1.4. Meaning of alarm signals 1.5. Automatic fault diagnosis 1.6. Additional devices 2. Monthly Maintenance 3. -
Page 4: Innohome Stove Guard And How To Use It
STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it 1.1 A quick guide When the Stove Guard is signalling, press the Intelligent Heat Sensor push-but- ton once. Also note that: When the Intelligent Heat Sensor is emitting a pre-alarm signal, a short sound fol- lowed by a long break (--____--____), it has identified a hazardous situation. -
Page 5: Structure Of The Stove Guard
Sensor push-button is being pressed. Telecare. A red light flashes during an alarm. Distinguishing the Stove Guard type: Stove Guard SGK300-2 includes a Control Unit SGC500-2 with one blue connector, SGK300-3 includes a Control Unit SGC500-3 with two white connec- tors. - Page 6 STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it (cont.) Stove Guard features a) Overheating Monitor The Intelligent Heat Sensor, installed above the cooker, reacts to a dangerously high tempera- ture or steep temperature rise. The Sensor’s self-adjusting technology ‘learns’ the users’ cook- ing styles, making hazard recognition precise, with no false alarms.
- Page 7 STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it (cont.) Gas and dual-fuel cookers’ timer: The timer has a fixed time and starts when the hob tempera- ture starts to rise. The cooker is turned off after two hours (in some dual-fuel cookers the oven is not turned off ).
-
Page 8: Meaning Of Alarm Signals
STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it (cont.) 1.4 Meaning of alarm signals The Intelligent Heat Sensor signal has a higher tone than the Control Unit signal. The Intelli- gent Heat Sensor is attached above the cooker, the Control Unit signal sounds from behind the cooker. - Page 9 STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it (cont.) Sound Meaning Course of Action Control Unit: a short The cooker has been turned off due to the First turn all cooker knobs to signal at approximate- Intelligent Timer function, detecting the ‘0’...
-
Page 10: Automatic Fault Diagnosis
STOVE GUARD SGK300 USER MANUAL 1. Innohome Stove Guard and how to use it (cont.) 1.5. Automatic fault diagnosis Electric cookers: The automatic fault diagnosis ensures that the Stove Guard is working per- fectly each time the cooker is used for cooking (the diagnosis will not start if the cooker is only used for a short period of time eg. -
Page 11: Monthly Maintenance
STOVE GUARD SGK300 USER MANUAL 2. Monthly Maintenance Electric cookers: Since the automatic fault diagnosis tests the Stove Guard operation every time the cooker is used for cooking, only the Alarm Signal Detection feature needs to be tested on a monthly basis. For the Alarm Signal Detection test, refer to the section 6.2. -
Page 12: Intelligent Heat Sensor Installation
STOVE GUARD SGK300 USER MANUAL 4. Intelligent Heat Sensor Installation 1. Remove the Intelligent Heat Sensor from its packaging and allow about 15 minutes for it to reach room temperature. 2. The Intelligent Heat Sensor uses different settings for electric and gas burners. Carry out initialization as described below, depending on hob type. -
Page 13: Intelligent Heat Sensor Installation
STOVE GUARD SGK300 USER MANUAL 4. Intelligent Heat Sensor Installation (cont.) supported housing, for example), set the sensitivity level manually (section 9). The screw (2, see image on previous page) on the bottom of the Intelligent Heat Sensor opens the cover for changing the battery. -
Page 14: Control Unit Installation And Setup
STOVE GUARD SGK300 USER MANUAL 5. Control Unit Installation and Setup If the cooker is connected to the mains electricity via a plug and a socket, the Control Unit can be installed by the user. In any other case, the installation needs to be carried out by a qualified electrician. -
Page 15: Testing After Installation
STOVE GUARD SGK300 USER MANUAL 6. Testing after Installation 6.1 Intelligent Heat Sensor test Turn a burner on. Press the Intelligent Heat Sensor push-button and hold it down until you hear a signal. The Control Unit will turn the cooker off by cutting its gas/electricity supply and start to emit a signal. -
Page 16: Changing The Hob Type Setting
STOVE GUARD SGK300 USER MANUAL 7. Changing the hob type setting The Intelligent Heat Sensor uses different settings for gas and electric burners. Changing the hob type setting may be required if the gas burners setting was not successfully implemented during the Intelligent Heat Sensor setup, or if you later change your cooker to a different type. -
Page 17: Setting The Sensitivity Level Of The Intelligent Heat Sensor
STOVE GUARD SGK300 USER MANUAL 9. Setting the sensitivity level of the Intelligent Heat Sensor The sensitivity level determines the level of heat and the rate of temperature change required to trigger an alarm. The Intelligent Heat Sensor reduces its sensitivity automatically, when the user presses the Intelligent Heat Sensor push-button during the Intelligent Heat Sensor pre-alarm signal (see section 1.3). -
Page 18: Alarm Output
STOVE GUARD SGK300 USER MANUAL 10. Alarm output The alarm output is a 3.5 mm stereo jack found C N 1 on the Control Unit. The alarm output is potential Alarm free and normally open (opto). It closes for one... -
Page 19: Troubleshooting
STOVE GUARD SGK300 USER MANUAL 11. Troubleshooting (cont.) The Control Unit emits a short signal, followed by a long signal (‘be-beep’), at approxi- mately 5 second intervals • The automatic fault diagnosis has detected that the Intelligent Heat Sensor is not in its origi-... - Page 20 STOVE GUARD SGK300 USER MANUAL 11. Troubleshooting (cont.) still triggers a false alarm. When a false alarm is no longer triggered, then make sure that the Stove Guard still responds to the alarm signals of external alarms by re-testing the Alarm Signal Detection feature as advised in section 6.2.
-
Page 21: Technical Information
STOVE GUARD SGK300 USER MANUAL 12. Technical Information Certification CE, Casing IP20 Patent FI 117526, FI 117878, PCT pending Unit Connection Voltage/power Cut-off time Features Control 1-3 phase SGC500-2: 230VAC, 0,5 - 3 h Alarm Signal Detection Unit 1-phase and star... - Page 22 IMAGES...
- Page 23 IMAGES...
- Page 24 smart safety for your kitchen Innohome Ltd www.innohome.com info@innohome.com www.facebook.com/innohome Linnoitustie 4B smart safety for your kitchen FI-02600 Espoo Finland SGK300-000UU1...
