BJ-214
BJ Enabler Alarm
User guide
www.bjliveat.com
1. Description of the device
The BJ Enabler Alarm allows activating an emergency
alert. To activate the alarm you can use a switch or a
BJ
System
controller.
This
device
frequency signals.
It is possible to choose from 4 different signal tones
and plug an appliance into the socket. The appliance
Sound output
Switch
input
RF Code selector
does not depend on the Enabler's status.
Fig.1: BJ Enabler Alarm
2. Technical data
Power supply
Maximum power supply
RF working frequency
Dimensions
Socket for 3.5-mm mono female jack switch
3. Operating instructions
A) Using BJ System remote controllers
To activate remotely the alarm using the BJ System
controllers follow these steps:
1.
Select a position on the Enabler's "RF code
selector" (Figure 1). The code assigned to the
Enabler is given by Table 1. A different melody
is assigned to each selector position.
uses
radio
2.
Connect the enabler to the mains, taking into
account the device's technical characteristics.
3.
Program on the controller the RF code assigned
in step 1 (check the controller's User Guide to
carry out this operation).
4.
Press the button on the controller to activate
Socket
the alarm. Once it is activated, the beep will
sound for a few seconds.
Selector
RF Code
Function
Mains plug
Table 1
Activating various enablers at the same time:
It is possible to activate various Enablers located in
different places at the same time by adjusting the
"RF code selector" to the same position in all of
them.
Activating different enablers:
230~ / 50Hz
250V~
It is possible to activated different Enablers by
pressing a different button on the BJ System
433 MHz
controller. You just need to adjust a different position
105x59x50 mm
on the "RF code selector" in each Enabler.
IMPORTANT:
Whenever
selector" is modified to assign a different code
to the Enabler, it must be unplug from the
mains socket for at least 5 seconds. The new
code will be recorded when the Enabler is plug
again.
0
1
2
3
4 to 9
25
26
27
28
Tone 1 Tone 2 Tone 3 Tone 4
Not used
the
position
of
the
"RF
code
-
Advertisement
Table of Contents
Summary of Contents for BJLive BJ-214
- Page 1 Select a position on the Enabler’s “RF code 1. Description of the device BJ-214 selector” (Figure 1). The code assigned to the The BJ Enabler Alarm allows activating an emergency Enabler is given by Table 1. A different melody is assigned to each selector position.
- Page 2 B) Using a switch Disposal It is possible to control the Enabler directly using a Waste electrical products should not be disposed switch. of with household waste! Dispose of the waste product via a collection point for electronic scrap or via your specialist dealer.
