Oki B410d User Manual

Monochrome page printer
Hide thumbs Also See for B410d:
Table of Contents

Advertisement

Quick Links

See also: Setup Manual
Downloaded From ManualsPrinter.com Manuals

Advertisement

Table of Contents
loading

Related Manuals for Oki B410d

Summary of Contents for Oki B410d

  • Page 1 Downloaded From ManualsPrinter.com Manuals...

  • Page 2: Copyright Information

    Trademark Information _______________________________ ________________________ Oki, OkiLAN are registered trademarks of Oki Electric Industry Company Ltd. Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Computers Inc. Microsoft, MS-DOS, Windows, Windows Vista, Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 3: Table Of Contents

    B410d and B410dn ........33...
  • Page 4 B410d and B410dn ........67...

  • Page 5: Notes, Cautions And Warnings > 5

    OTES AUTIONS AND ARNINGS NOTE A note provides additional information to supplement the main text. CAUTION! A caution provides additional information which, if ignored, may result in equipment malfunction or damage. WARNING! A warning provides additional information which, if ignored, may result in a risk of personal injury.

  • Page 6: Introduction

    Memory: 32MB for B410d, B410dn and B420dn; 64MB for B430dn. > High speed printing: 28ppm A4 and 30ppm Letter. > Resolution: 1200 x 600 dpi for B410d, B410dn and B420dn; 1200 x 1200 dpi for B430dn. > Paper handling: 250 sheets (75g/m²) for B410d, B410dn, B430dn; 530 sheets for the B420dn.

  • Page 7: About This Manual

    BOUT THIS MANUAL This manual is the user’s guide (check the Oki Printing Solutions website, www.okiprintingsolutions.com, for the most up-to-date version) for your printer and forms part of the overall user support listed below: > Quick Setup Poster: easy to follow graphical instructions for quick printer setup.

  • Page 8: Abbreviations Used

    Pages from and to for the range of pages you specify by entering their page numbers. Click OK. BBREVIATIONS USED The following abbreviations are used in this manual: ABBREVIATION MEANING Ctrl Control dots per inch DIMM Dual In-line Memory Module duplex network card installed Light Emitting Diode...

  • Page 9: Printer Components

    RINTER COMPONENTS Apart from the Operator panels, which are described in the next chapter, the B410d/ B410dn/B420dn/B430dn printers look similar from the outside. The important components are identified in the representations below. Operator panel (B430dn shown) Output Stacker (150 sheets, face down)
  • Page 10 Power cable connection Duplex unit Parallel interface connection USB interface connection LAN interface connection (only for B410dn, B420dn and B430dn) Test button (only for B410dn, B420dn and B430dn) Memory panel (to upgrade your printer’s memory RAM DIMM) Cooling fan Downloaded From ManualsPrinter.com Manuals Printer components >...

  • Page 11: Operator Panels

    This chapter describes the function of the operator panel on your printer. It is useful to describe the Printer Menu Setup Tool at this point as it provides the B410d and B410dn, the equivalent of the menu control panel on the B420dn, B430dn (See “Printer drivers”...

  • Page 12: Lcd

    FLASH TYPE READY LED (1) ATTENTION LED (2) MEANING Flash The printer is receiving and processing data during printing or the printer is resetting. There is a printing error, for example, a problem with paper, the cover is open or the paper tray is empty while a job is processing.

  • Page 13: Changing Language

    > Resetting the printer and clearing the buffer after printing has been cancelled. NOTE To reset the printer to the default settings of the manufacturer, the Online button is pressed and held down while the printer is switched on with the main power switch.

  • Page 14: Menu Functions

    ENU FUNCTIONS The Printer Menu allows you to view and change the printer’s internal settings. You can think of this as the software equivalent of the LCD operator panel. The settings are grouped into categories or “menus” such as Information Menu or Print Menu.
  • Page 15 Print menu This menu provides adjustment of various print job related functions. ITEM DEFAULT REMARKS COPIES DUPLEX MANUAL PAPER FEED TRAY1 AUTO TRAY SWITCH TRAY SEQUENCE DOWN MEDIA CHECK ENABLE RESOLUTION 600DPI TONER SAVE MODE DISABLE ORIENTATION PORTRAIT LINES PER PAGE 64 LINES EDIT SIZE CASSETTE SIZE...
  • Page 16 System configuration menu This menu adjusts general printer settings to suit the way you prefer to work. ITEM DEFAULT REMARKS POW SAVE TIME 10 MIN PERSONALITY AUTO EMULATION CLRABLE WARNING ONLINE AUTO CONTINUE MANUAL TIMEOUT 60 SEC TIMEOUT INJOB 40 SEC TIMEOUT LOCAL 40 SEC TIMEOUT NET...
  • Page 17 PPR Emulation This menu controls the printer’s PPR emulation. ITEM DEFAULT REMARKS CHARACTER PITCH 10 CPI FONT CONDENSE 12CPI TO 20CPI CHARACTER SET SET-2 SYMBOL SET IBM-437 LETTER O STYLE DISABLE ZERO CHARACTER NORMAL LINE PITCH 6 LPI WHITE PAGE SKIP CR FUNCTION LF FUNCTION LINE LENGTH...
  • Page 18 Parallel menu This menu controls the operation of the printer’s parallel data interface. ITEM DEFAULT REMARKS PARALLEL ENABLE BI-DIRECTION ENABLE ENABLE ACK WIDTH NARROW ACK/BUSY TIMING ACK IN BUSY I-PRIME 3 MICRO SEC USB menu This menu controls the operation of the printer’s USB data interface. ITEM DEFAULT REMARKS...
  • Page 19 ITEM DEFAULT REMARKS HUB LINK SETTING AUTO NEGOTIATE FACTORY DEFAULTS EXECUTE Print Statistics menu This menu provides information on the number of A4/Letter pages printed and allows you to reset the counter. ITEM DEFAULT REMARKS USAGE REPORT ENABLE RESET COUNTER EXECUTE GROUP COUNTER DISABLE...

  • Page 20: Printing Menu Settings

    RINTING MENU SETTINGS The menu settings can be printed as a menu map as follows. Using the Online button Press the Online button to take the printer off-line. Press and hold down the Online button for at least four seconds, but less than seven seconds.

  • Page 21: B420Dn, B430Dn

    B420 , B430 PERATOR PANEL The B420dn, B430dn operator panel consists of a menu driven control panel, an LCD display and two LED indicators. ANEL ELEMENTS Liquid crystal display. (LCD) panel. Two rows of up to 16 alphanumeric digits displaying print status, menu items in menu mode and error messages. Menu Scroll Buttons.

  • Page 22: Menu Functions

    ENU FUNCTIONS The Printer Menu allows you to view and change the printer’s internal settings. The settings are grouped into categories or “menus” such as Information Menu or Print Menu. Some of these settings are similar to those found in your printer driver or application software.
  • Page 23 ITEM DEFAULT REMARKS MP TRAY USAGE DO NOT USE MEDIA CHECK ENABLE RESOLUTION 1200DPI TONER SAVE MODE DISABLE ORIENTATION PORTRAIT LINES PER PAGE 64 LINES EDIT SIZE CASSETTE SIZE Media Menu This menu provides adjustment to suit a wide range of print media. ITEM DEFAULT REMARKS...
  • Page 24 ITEM DEFAULT REMARKS TIMEOUT NET 90 SEC B430dn only LOW TONER CONTINUE JAM RECOVERY ERROR REPORT START UP PCL emulation This menu controls the printer’s PCL emulation. ITEM DEFAULT REMARKS FONT SOURCE RESIDENT FONT NO. FONT PITCH 10.00 CPI SYMBOL SET PC-8 A4 PRINT WIDTH 78 COLUMN...

  • Page 25: Parallel Menu

    ITEM DEFAULT REMARKS LINE LENGTH 80 COLUMN FORM LENGTH 11.7 INCH TOF POSITION 0.0 INCH LEFT MARGIN 0.0 INCH FIT TO LETTER DISABLE TEXT HEIGHT SAME FX Emulation This menu controls the printer’s FX emulation. ITEM DEFAULT REMARKS CHARACTER PITCH 10 CPI CHARACTER SET SET-2...
  • Page 26 USB menu This menu controls the operation of the printer’s USB data interface. ITEM DEFAULT REMARKS ENABLE SOFT RESET DISABLE SPEED 480Mbps OFFLINE RECEIVE DISABLE SERIAL NUMBER ENABLE Network menu This menu controls the operation of the printer’s 10Base-T/100Base-TX network interface. ITEM DEFAULT REMARKS...
  • Page 27 Print Statistics menu This menu provides information on the number of A4/Letter pages printed and allows you to reset the counter. ITEM DEFAULT REMARKS USAGE REPORT ENABLE RESET COUNTER EXECUTE GROUP COUNTER DISABLE CHANGE PASSWORD Enter the new password. Maintenance menu This menu provides access to various printer maintenance functions.

  • Page 28: Printing Menu Settings

    RINTING MENU SETTINGS Current menu settings can be confirmed by printing a Menu Map, using the control panel. Press the Menu button until the INFORMATION MENU is available, then press button. Press the button until the display prompts you to print the menu map. Press the button to print the menu map.

  • Page 29: Paper Recommendations

    “Paper and tray information” in the “Specifications” chapter. NOTE The reference to Manual Feed Tray is for the B410d and B410dn models and the Multi Purpose Tray is for the B420dn and B430dn models. APER AND ENVELOPE TYPES...

  • Page 30: Postcards

    OSTCARDS The manufacturer of this printer recommends the following guidelines when selecting postcards for use in your printer: > Always manually feed single postcards using the Manual Feed Tray or Multi Purpose Tray, depending on your printer model. > Use unfolded double postcards. >...
  • Page 31 Adjust the rear paper support (5) to the size of paper you are using by gripping the lugs, tilting and sliding the support forwards or backwards as necessary. Adjust the paper guides (5). It is important to adjust the paper guides correctly to ensure that the paper is not skewed in the print process.

  • Page 32: Multi Purpose Tray And Manual Feed Tray

    ULTI PURPOSE TRAY AND MANUAL FEED TRAY B420, B320: Pull down the Multi Purpose Tray (1), fold out the paper supports (2), and adjust the paper guides to the width of the paper (4). B410: Pull down the Manual Feed Tray (1), and adjust the paper guides (2) to the width of the paper.

  • Page 33: Paper Feed, Size And Media Setting

    > Envelopes should be loaded flap down, face up with the top edge to the left and short edge into the printer. NOTE Do not select Duplex printing on envelopes. > Load Transparencies face up and top edge into the printer. >...

  • Page 34: B420Dn, B430Dn

    B420 , B430 Using the control panel on your printer, you can choose: > which paper to use > the size of the paper you wish to use > the weight of the paper (thickness) > the type of paper NOTE >...
  • Page 35 Press either button until the required paper size is displayed, then press button. An asterisk (*) appears next to the selected paper size. Press the Cancel or Online or the button repeatedly to exit the MENU mode. Select the correct paper settings in the printer driver before printing the file. Media type and weight Set media type and weight as follows: CAUTION!

  • Page 36: Interfaces

    NTERFACES Your printer is equipped with a selection of data interfaces: Parallel – For direct connection to a PC. This port requires a bi-directional (IEEE 1284 compliant) parallel cable. USB – For connection to a PC running Windows 2000 or later or Mac OS X or later. This port requires a cable conforming to USB version 2.0 or above.

  • Page 37: Printer Drivers

    Ensure that any installed options are enabled in the printer driver. HOOSING A AC DRIVER The B410d, B410dn and B420dn models allow you to use only a PCL Mac driver. The B430dn models can also use a PS driver on Macintosh operating systems. Downloaded From ManualsPrinter.com Manuals...

  • Page 38: Operation

    PERATION This chapter provides a broad outline of how to operate your printer from either a Windows or a Macintosh environment. In the former, while PCL emulation is available on all printer models, PS emulation is available on the B430dn models. RINTER SETTINGS IN INDOWS NOTE...
  • Page 39 You can choose the source of the paper to feed, which may be Tray 1 (the standard paper tray), Manual Feed Tray (B410d and B410dn), Tray 2 (if you have the optional second paper tray installed) or the Multi Purpose Tray (B420dn, B430dn). You can also click on the appropriate part of the screen graphic to select your preferred tray.
  • Page 40 The output resolution of the printed page can be set as follows. > The ProQ1200 setting for B410d and B410dn prints at 2400 x 600dpi. This setting requires the most printer memory and takes the longest to print. Your printed pages can be scaled to fit larger or smaller stationery.
  • Page 41 Image tab Dithering produces an intermediate greyscale by adjusting the combination of dots used in printing. Selecting a setting determines the degree of detail with which a graphics image will be printed. Mesh determines that a screen of dots is used for dithering while Line Art determines that an array of lines is used for dithering.

  • Page 42: Ps Emulation (B430Dn)

    (B430 EMULATION The tabs available are the Layout Tab, the Paper/Quality Tab and the Job Options Tab. Layout tab My Printer Printing Preferences Page orientation can be set to portrait (tall), landscape (wide) or landscape rotated by 180 degrees. Print on both sides (duplex printing) can be set to long edge or short edge of the document.
  • Page 43 The output resolution of the printed page can be set as follows. > The ProQ1200 for B410d and B410dn setting prints at 2400 x 600dpi. This setting requires the most printer memory and takes the longest to print. It is the best option for printing photographs.

  • Page 44: Setting From Windows Control Panel

    You can print watermark text behind the main page image. This is useful for marking documents as draft, confidential, etc. If you would like to print on special stationery, such as forms and letterhead, but do not want to use pre-printed stationery, you can create your own using Overlays (for B430dn).
  • Page 45 Advanced tab My Printer Properties You can specify which times of day your printer will be available. Indicates current priority, from 1 (lowest) to 99 (highest). Highest priority documents will print first. Specifies that documents should be spooled (stored in a special print file) before being printed.
  • Page 46 compatibility problems occur you can disable the feature. However, these advanced options may then not be available, even though the hardware might support them. This button provides access to the same setup windows as when printing from applications. Changes made via the Windows Control Panel become the Windows default settings.

  • Page 47: Printer Settings In Macintosh

    Device settings tab You can set the desired paper sizes in each of the available paper feed trays. You can make a variety of font settings depending on your application. You can set which optional upgrades are installed on your printer. See the chapter entitled “Installing options”.

  • Page 48: Power Saving Mode

    CHANGING THE LENGTH OF TIME BEFORE ENTERING POWER SAVING MODE B410d and B410dn Use the Menu Setup Tool Select Start > Programs > Oki Data > OKI B410 printer Menu Setup Tool > Printer Menu Setup Tool. Double-click System Configuration Menu then select Power Save Time.
  • Page 49 B420dn and B430dn Use the Printer Menu via the Operator Panel Press the Menu button until Maintenance Menu appears. Press Press until Power Save appears. Press Press until Disable appears. Press . An asterisk (*) will appear to confirm the selection. Press Online.

  • Page 50: 2-Sided Printing

    To carry out Auto Duplex Printing: Select File -> Print and click the Properties button. Select the input tray: Tray1 (or optional Tray2), or Manual Feed Tray (B410d and B410dn), or Multi Purpose Tray (B420dn, B430dn) from the Source drop down.

  • Page 51: Manual Duplex Printing Using The Paper Tray (Windows Only)

    ANUAL DUPLEX PRINTING USING THE PAPER TRAY INDOWS ONLY NOTE Manual Duplex printing is available only for Windows PCL Driver. You cannot use A6 paper size for printing from Tray 1 or Tray 2 (option). To carry out 2-sided, or Manual Duplex Printing you must pass paper through the printer twice.
  • Page 52 Take the printed paper from the Output Stacker (3) and place it in the Paper Tray, ensuring that the printed side is facing up and the bottom of the page facing into the printer (4). Close the Paper Tray and press the Online button. The message window should disappear from your screen and the document finishes printing the remaining pages of your document.

  • Page 53: Manual Duplex Printing Using The Manual Feed Tray (B410D And B410Dn) Or The Multi-Purpose Tray (B420Dn And B430Dn)

    (B410 B410 ANUAL DUPLEX PRINTING USING THE ANUAL D AND (B420 B430 OR THE ULTI URPOSE DN AND NOTE You can use A4, A5, A6, B5, Letter, Legal 13 and 14, Statement, Executive and Custom paper sizes, using paper stocks from 60 - 124g/ Position the paper guides on the Manual Feed Tray or Multi-Purpose Tray according to the paper size.

  • Page 54: Short Edge

    HORT Press the Online button. The remaining page(s) of your document print on the blank side of the paper, one sheet at a time as you feed it into the B410 Manual Feed Tray or the stack of pages from the Multi-Purpose Feeder (B420 and B430). Downloaded From ManualsPrinter.com Manuals 2-sided printing >...

  • Page 55: Overlays And Macros (Windows Only)

    VERLAYS AND ACROS INDOWS ONLY HAT ARE OVERLAYS AND MACROS If you would like to print on special stationery, such as forms and letterhead, but do not want to use pre-printed stationery, you can create your own using these advanced features.

  • Page 56: Create And Download The Project

    REATE AND DOWNLOAD THE PROJECT From the Windows Start menu, start Storage Device Manager (SDM) and allow SDM to discover the printer. Choose Projects→New Project. Choose Projects→Add File to Project. Set the Files of Type drop-down list to PRN Files(*.prn). Navigate to the folder where the.PRN files are stored and select one or more of these to include in your overlay set.

  • Page 57: Printing With Postscript Overlays

    In the Define Overlays window, enter a suitable name (2) for this overlay and choose which page(s) (3) of your documents will use this overlay. Enter the name of the overlay file (4) exactly as it appeared in the Storage Device Manager project window. Remember that this name is case sensitive.

  • Page 58: Creating Pcl Overlays

    PCL O REATING VERLAYS Three steps are required to create an overlay: Create the form data using your own application software and print it to a printer (.PRN) file. Use the Storage Device Manager utility software supplied on CD with your printer to create a “project file,”...

  • Page 59: Test Printing The Macro

    If you wish to edit the names or ID numbers, double-click the file entry and edit the details. Note that the names are case sensitive. Choose Projects→Save Project and enter a meaningful name (e.g. “Letter Stationery”) so that you can recognise it. Choose Projects→Send Project Files to Printer to download the project to the printer.

  • Page 60: Printing With Pcl Overlays

    The new overlays will now appear in the Defined Overlays list in the printer properties window. When done, click OK to close the printing preferences window. Your new overlays are now ready and available to be used for any future documents you wish.

  • Page 61: Consumables And Maintenance

    This section deals with the replacement of the toner cartridge and image drum and general maintenance. ONSUMABLE ORDER DETAILS ITEM LIFE ORDER NO. Toner, 3.5K: B410d/B410dn/B420dn/B430dn 3500 Letter/A4 @ 5% 43979101 ISO/IEC19752 Toner, 7K: B420dn, B430dn 7,000 Letter/A4 @ 5%...
  • Page 62 If you do spill any toner powder, lightly brush it off. If this is not enough, use a cool, damp cloth to remove any residue. Do not use hot water, and never use solvents of any kind. They will make stains permanent. WARNING! If you inhale any toner or get it in your eyes, drink a little water or bathe your eyes liberally in cold water.
  • Page 63 Gently shake the cartridge (3) from end to end several times to loosen and distribute the toner evenly inside the cartridge. Remove the wrapping material and peel off the adhesive tape from the underside of the cartridge (4). Holding the cartridge by its top center with the colored lever to the right (5), lower it into the printer over the image drum unit from which the old cartridge was removed.
  • Page 64 Pressing gently down on the cartridge to ensure that it is firmly seated, push the colored lever towards the rear of the printer (8). Push the lever all the way forward until the pointers on the drum and the toner are aligned (8a). This will lock the cartridge into place and release toner into the image drum unit.

  • Page 65: Image Drum Life

    MAGE DRUM LIFE The life of an image drum depends on a number of factors, including temperature and humidity, the type of paper used, and the number of pages per job. The image drum should last approximately 25,000 pages continuous printing. This number is approximate because different numbers of pages are printed each time and the environmental conditions and the paper type used may vary.
  • Page 66 Put the assembly down gently onto a piece of paper to prevent toner from marking your furniture and to avoid damaging the green drum surface. CAUTION! The green image drum surface at the base of the ID unit is very delicate and light sensitive.

  • Page 67: Generating A Cleaning Page

    ENERATING A CLEANING PAGE If the printed page shows signs of fading, streaking or erratic marks, the problem may be cleared by generating a drum cleaning page as follows. B410 B410 D AND Using the Printer Menu Setup Tool Start the Printer Menu Setup Tool for the printer. Click Maintenance Menu.
  • Page 68 Press the button. The printer grips the paper and prints a cleaning page. The printer should now be ON LINE. If subsequent printing appears faded or uneven, try replacing the toner cartridge. Downloaded From ManualsPrinter.com Manuals Consumables and maintenance > 68...

  • Page 69: Cleaning The Led Array

    LEANING THE ARRAY Clean the LED array whenever a new toner cartridge is installed or if there are faded vertical areas or light printing down a page. Wipe the LED array gently with a soft tissue. Downloaded From ManualsPrinter.com Manuals Consumables and maintenance >...

  • Page 70: Troubleshooting

    ROUBLESHOOTING TATUS AND ERROR MESSAGES Your printer has been designed to give you helpful status feedback not only during normal operation but also if a printing problem occurs so that you can take appropriate corrective action. The LCD on the printer operator panel provides the self-explanatory status and error messages in your chosen language.

  • Page 71: Input Jam

    NPUT JAM NOTE The B430dn model has been illustrated below. The principles are the same for all models of this printer. Remove the paper tray from the printer (1). Remove any crumpled or folded paper. Remove any paper from the underside of the printer (2). Replace the paper tray.
  • Page 72 Carefully lift out the image drum, complete with the toner cartridge. Be careful not to touch or scratch the green drum surface. Remove any jammed sheets from the paper path. Re-install the image drum complete with toner cartridge, ensuring that the pegs (1 & 2) correctly locate into the slots on each side of the printer (3).
  • Page 73 If the paper is difficult to remove, push the cover in the arrow direction, raise it and remove the paper. Open the Multi Purpose Tray (1) (Manual Feed Tray for B410d and B410dn). Downloaded From ManualsPrinter.com Manuals Troubleshooting > 73...

  • Page 74: Print Quality Problems

    > Remove any paper that you find (2), and then close the tray. Close the top cover and press down to latch it closed. The printer will warm up and commence printing when ready. The page lost through the jam will normally be reprinted. NOTE If the edge of the jammed paper protrudes (or can be seen) from the exit, reinstall the image drum, close the top cover and switch the printer on.
  • Page 75 SYMPTOM PROBLEM SOLUTION Vertical white Toner is low and does Replace toner cartridge. Check drum and streaking or faint not distribute properly, replace the drum, if necessary. Contact areas on page. or the drum is worn out. service. LED array is dirty. Clean LED array.

  • Page 76: Paper Feed Problems

    APER FEED PROBLEMS SYMPTOM PROBLEM SOLUTION Paper Jams occur frequently. The printer is tilted. Place the paper on a stable Multiple sheets of paper are and flat surface. fed at the same time. Paper is too thick or too thin. Use paper suitable for the Paper is moist, folded, printer.

  • Page 77: Software Problems

    OFTWARE PROBLEMS Your software (operating environment, applications and printer drivers) controls the printing process. Make sure you have selected the right driver for use with your printer. See your software documentation for more information. SYMPTOM PROBLEM SOLUTION Printing is garbled. Incorrect driver is Install an appropriate driver.

  • Page 78: Installing Options

    NSTALLING OPTIONS The following options are available to extend the performance of your printer: > 128 and 256MB RAM DIMM: to extend the main memory of your printer and speed up the processing of large files > Second paper tray: to increase your printer’s paper handling capacity by 530 sheets (75g/m²) NSTALLING OPTIONS ORDER NUMBERS 128MB RAM DIMM...

  • Page 79: Specifications

    A summary of the basic characteristics of your printer appears in the table below: ITEM SPECIFICATION Dimensions B410d, B410dn and B420dn: 369mm x 395mm x 268mm (W x D x H) B420dn, B430dn: 369mm x 395mm x 268mm (W x D x H) Weight B410/B420/B430: 10.3 kg approximately (without second tray...
  • Page 80 Paper feed B420dn, B430dn: Automatic feeding via paper trays (including optional second tray and Multi Purpose Tray) B410d, B410dn and B420dn: Automatic feeding via paper trays (including optional second tray) and Manual feeding of single sheets Paper feed capacity B410d, B410dn and B430dn: Tray 1: 250 sheets at 75g/m²...

  • Page 81: Paper And Tray Information

    APER AND TRAY INFORMATION Feed and ejection methods vary depending on the type, size and thickness of medium used. Use the chart below and the notes/symbols/terms on the following page for initial guidance. (Minor variations to settings may be necessary depending on user setup and environmental conditions).
  • Page 82 Duplex Printing Auto Manual Paper Size Wei- type Plain L, ML, paper M, MH Letter Legal (13) Legal (14) L, ML, MH, H Executive Statement L, ML, MH, H L, ML, MH, H Custom L, ML, M, MH W: 90 - 216 L: 148 - 356 Postcards Enve-...

  • Page 83: Notes/Symbols/Terms

    OTES SYMBOLS TERMS Notes: When an optional second paper tray is used, the original tray is referred to as Tray 1 and the optional tray as Tray 2. It is possible to use custom paper sizes with the PS emulation driver. Tray 1 can accommodate paper with width of 100 to 216mm and length of 210 to 316mm.

  • Page 84: Service And Support

    ERVICE AND UPPORT Available 24 hours a day, 7 days a week > Visit our multilingual web site: www.okiprintingsolutions.com > Call 1-800-654-3282 Downloaded From ManualsPrinter.com Manuals Service and Support > 84...

This manual is also suitable for:

B420dnB430dnB410dn
