Summary of Contents for Acapella Audio Arts Duke
- Page 1 Instruction manual...
- Page 2 The front sides are grinded by hand, the emblems founded. King, Queen & Duke on principle will be supplied as a integrated unit in a wooden case. They come with all required connection cables and are ready to play.
-
Page 3: Setup And Installation
If the indicated voltage is incorrect relative to that supplied in your area, see your dealer. Connections and cables Connect the loudspeakers "Duke" to the amplifier "King", using the supplied XLR-cables. Connect one of the two pairs of outputs (C) of the CD-player/Tuner combination "Queen" to the central pair of inputs (B) of the amplifier "King", using the RCA-type cable (Cinch) which is supplied as well. -
Page 4: Remote Control
Remote control King and Queen turn off Queen CD-PLAYER and King turn on resp. switch to CD Queen TUNER and King turn on resp. switch to Tuner CD track back or Tuner station back CD track forward or Tuner station forward 1x = CD pause (center LED of Queen is blinking) 2x = Stop CD Play... - Page 5 1-2-3. Left channel = white above, right channel = red below. • Socket C = outputs for Duke's. Connect them with the supplied special cable (XLR). Looking from the front panel right side = right Duke, left side = left Duke.
- Page 6 Queen Buttons (Press the bottom !) • Center: On/Off, switch over, stop. Pressing shortly = start CD, pressing again = switch to tuner (Queen's reaction time approx. 3 seconds), from CD-play = stop. Pressing longer = turn off. • Left: CD = pause from play mode. Repeated pressing within 1 second = track back.
- Page 7 Duke Front side • Above: Two-way-Duplex-loudspeaker chassis with fixed cover. • Below: Outlet of the bass reflex channel. Rear side • Above: Cavity for fixing the loudspeaker chassis. Do not loosen in any case the visible screw on the rear side.
- Page 8 King, Queen & Duke KING integrated pre - power amplifier Casted dustproof resonancefree aluminum cabinet. Cooling is implemented over the complete surface and garanties constant thermal environment for all electronic parts. Professional in and output sockets. Power output with 3-pol gold plated XLR Connectors.
- Page 9 QUEEN CD drive DA - converter and FM tuner Casted resonancefree aluminum cabinet. Cooling is implemented over the complete surface and garanties constant thermal environment for all electronic parts. Professional in- and output sockets. Two parallel output sockets for playback and recording useage.
