- Page 1 Shot Trak HD Shot Trak-X HD HIGH DEFINITION GUN CAMERAS OPERATOR’S MANUAL (SHOT TRAK HD / SHOT TRAK-X HD) REV. 2 – SEPT. 2014 o p e r a t o r ’ s m a n u a l...
- Page 2 Lens cap The information in this manual furnished for information use only, is subject to change without notice, is not to be construed as a commitment by ATN Corp. ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
-
Page 3: Specifications
Standard Weaver Mount Dimensions 2.6” x 1.3” x 1.8” / 66 x 33 x 46 mm Weight 0.3 lb /120 g Warranty Limited one year * ATN reserves the right to change the above specifications at any time without notice. -
Page 4: Battery Installation
(1920 x 1080p). Most action cameras today offer only a wide lens that may take great videos close up but fail miserably when attempting to capture your game at a distance. The Shot Trak HD delivers 5 times the Magnification of a standard action camera capturing your action perfectly every time. Its the best way to show off your victories to your friends and family back home and on-line. -
Page 5: Setting The Time
Please always make sure that the lens is al- ways positioned as shown below, keeping the ATN logo pointing towards the ground. To move the mount to a different side of Shot Trak... - Page 6 mount to. Position the mount to the new location and replace screws tightening accordingly. Do not over tighten. Remember to plug the empty holes with the remaining screws, that will prevent moisture from seeping into the device. Examples of Shot Trak right side up Examples of incorrect installation mounting.
-
Page 7: Operation
OPERATION Shot Trak HD (Model without laser) Control of the Shot Trak is performed with the ON-OFF switch. The switch has 2 positions. Position 1 (Figure A). The Shot Trak is turned off. The Red LED is off. Position 2 (Figure B). The Shot Trak is turned on. Red LED will turn on. - Page 8 Position 3 (Figure E). The Shot Trak and laser is on. Start recording video. Red LED will turn on. Position 4 (Figure F). Only the laser is turned on. If the indicator in position 2 and 3 blinks, the memory card is missing or full. LASER WINDAGE AND ELEVATION ADJUSTMENT Shot Trak-X HD ONLY)
- Page 9 Q: What does it mean indicator blinking? A: When no card/card error/card full, led lamp emits red light flicker rapidly; when status is 1080p recording , led lamp shines red light all the time; when status is 1080p recording on condition of low electricity, led lamp flashes red light a time per three sec- onds.
-
Page 10: Year Product Warranty
ATN, at its option, will either repair or replace the product, and such action on the part of ATN shall be the full extent of ATN’s liability, and the Customer’s sole and exclusive remedy. This warranty does not cover a product (a) used in other than its normal and customary manner;... -
Page 11: Product Warranty Registration
Agreement extend solely to the Customer. ATN’s liability hereunder for damages, regardless of the form or action, shall not exceed the fees or other charges paid to ATN by the customer or cus- tomer’s dealer. ATN shall not, in any event, be liable for special,... - Page 12 For customer service and technical support, please contact American Technologies Network Corp. 1341 San Mateo Avenue, South San Francisco, CA 94080 phone: 800-910-2862, 650-989-5100; fax: 650-875-0129 www.atncorp.com ©2014 ATN Corporation...
