TAG Flash User Manual

Flash/a with a built-in uhf receiver module, a wireless transmitter rp 6016 m uhf and cd/mp3/usb player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNICAL DATA
TECHNICAL DATA
Basic Equipment
Basic Equipment
RMS Power
Not amplified
Speaker
Without loudspeaker
Microphone
Without microphone
More Information
Dimensions folded : H 123 x W 24 x D 61 cm / 48.4 x 9.4 x 24"
Dimensions open : H 123 x W 73 x D 55 cm / 48.4 x 28.7 x 21.7"
Weight: 20 kg / 44 lbs
Outside: cottonwood colored plywood cabinet
Inside: black cladding
Options Flash amplified
Options Flash amplified
RMS Power
70 Watts / 4 ohms
Speaker
2 loudspeakers 6" - 15 cm
Power Requirements
Operates on AC 220v
Frequency Response
50 Hz - 20 Khz
Lead Battery
Built-in battery 9 Ah - 12 V with automatic battery charger
Working Time
6 - 9 hours on built in battery / unlimited on AC main
Inputs
RCA Line control input
1 balanced MIC control input + phantom power on XLR
Bands EQ
Bass, Mid, Treble
Output
Line output on XLR 3 pins
MIC
1 Gooseneck MIC: GM-302/500 mm
3 Slots
For 1 wireless receiver SDR-6216M to introdue questions or comments
from the audience during a presentation.
For 1 wireless transmitter RP-6016M to link Flash to addtional cabinets.
Up to 2 Players possible: CD/USB player CD-456, Digital player
EM010PR, Digital recorder: EM020R
Lamp
Lamp Littlite with LED
More Information
Dimensions folded : H 123 x W 24 x D 61 cm / 48.4 x 9.4 x 24"
Dimensions open : H 123 x W 73 x D 55 cm / 48.4 x 28.7 x 21.7"
Weight: 29 kg / 63.8 lbs
Outside: cottonwood colored plywood cabinet
Inside: black cladding
FLASH User's Manual
20
U S E R ' S M A N U A L
Example of a Flash/A with a built-in UHF receiver module, a Wireless transmitter RP
6016 M UHF and CD/MP3/USB player
Techniques Audio Groupe
Route de Lavérune
Montée du Terral
34430 Saint Jean de Védas
FRANCE
Tel : +33 (0)4 67 27 43 05
Fax : +33 (0)4 67 27 85 64
contact@tag-fr.com
www.tag-fr.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flash and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TAG Flash

Summary of Contents for TAG Flash

  • Page 1: Basic Equipment Basic Equipment

    For 1 wireless transmitter RP-6016M to link Flash to addtional cabinets. Up to 2 Players possible: CD/USB player CD-456, Digital player Example of a Flash/A with a built-in UHF receiver module, a Wireless transmitter RP EM010PR, Digital recorder: EM020R 6016 M UHF and CD/MP3/USB player...

  • Page 2: Table Of Contents

    ADVICE FOR A GOOD USE Page 3 ADVICE FOR A GOOD USE Play mode: Selects first title in previous folder SETTING UP Page 4 SETTING UP BASIC EQUIPMENT OF FLASH/A BASIC EQUIPMENT OF FLASH/A Page 5 REPEAT "REPEAT" Repeat all: - LOUDSPEAKER Page 5...

  • Page 3: Introduction

    Charge the FLASH/A to 100 % before first use. recording will not be possible. The display indicates REC Do not use the FLASH in a humid or dusty place, or near any heat sources such as radiators, NG if problem with recording heat registers, neither under the sun or at very low temperatures.

  • Page 4: Setting Up

    2. Put off the slide which is situated in the left inner side of the lectern. PLAY/ Plays music PAUSE Pause 4. Fix the slide in the middle of the lectern. 5. Your Flash is ready to work. Stops music STOP FUNC To change mode CARD UP/CUE Press briefly to select next title.

  • Page 5: Basic Equipment Of Flash/A

    BATTERIES The FLASH/A is equipped with a lead 9Ah / 12V battery making lots of loadings and unloadings possible. When connected on AC main the Flash / A can work without time limit, while charging.

  • Page 6: Control Leds

    Random play mode On/Off + Volume RECEIVER SDR-6216M VOL- Decreases volume by 1 dB The FLASH/A can be equipped with a UHF 16 frequencies (lowest volume = 0 dB) handheld microphone The receiver module is integrated in the inferior part of VOL+...

  • Page 7: Handheld Transmitter Mic Sq-5016

    Press this to skip to next file FOL- Stop mode : to choose next file DER>> Program mode : to select the first title in next file. Play mode : to select the first title in next file FLASH User’s Manual FLASH User’s Manual...

  • Page 8: Belt Transmitter Sm-5016

    Press on Set for 2 seconds to enter into Settings. Use UP or DOWN button to go to the CHANNEL /FREQUENCY page. The cursor will flash to allow changes to be made. Pressing UP or DOWN button will increase or decrease the channel number.

  • Page 9: Wireless Transmitter Rp-6016M

    Mute: to cancel Mute press this button again. Changes mode and skips to CD-MP3 mode The RP-6016M transmitter enables the link between Flash / A and other active sound systems (Nomade UHF, Premio UHF,...) or another sound system with a rackable UHF receiver (SDR...

  • Page 10: Players

    Front Panel Keys Explanation Remote The FLASH/A can be equipped with 3 possible players: a CD/MP3/USB Player(reference CD-456), a digital player (reference EM010PR) or a digital player/recorder (referenceEM020R), built in under PLAY/ If on Stop CD starts playing the LED.
