Summary of Contents for SEM IP-100
-
Page 3: Table Of Contents
CONTENTS IMPORTANT SAFETY & NOTICE ....................SYSTEM BASICS Location of Controls - Main Unit .......... Location of Controls - Remote ..........Power Supply AC Operation ..........Back up Batteries ..............Preparation of Remote Control ..........DIGITAL CLOCK Digital Clock Function ............How to Set Correct Time ............ -
Page 4: Important Safety & Notice
IMPORTANT SAFETY & NOTICE The lightning fl ash and arrowhead within the triangle is a warning sign alerting you of “dangerous voltage” inside the product. WARNING: CAUTION To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable RISK OF ELECTRIC SHOCK parts inside. -
Page 5: System Basics
SYSTEM BASICS LOCATION OF CONTROLS - MAIN UNIT 1. SPEAKERS (LEFT & RIGHT) 15. UP KEY 2. DIGITAL BACKLIT DISPLAY 1 6. SD CARD SOCKET 3. STANDBY KEY 17. USB DRIVE SOCKET 4. VOLUME - KEY 18. DOCK ADAPTOR FOR iPod 5. -
Page 6: Location Of Controls - Remote
SYSTEM BASICS LOCATION OF CONTROLS - REMOTE 1. ON/ STANDBY KEY 14. MEM +/ FOLDER + KEY 2. TUNER KEY 15. SKIP +10 KEY 3. USB/ CARD KEY 16. MUTE KEY 4. id3/ FM MODE KEY 17. VOLUME - KEY 5. -
Page 7: Digital Clock
DIGITAL CLOCK DIGITAL CLOCK FUNCTION - The set has a built-in digital clock, which is displayed in 2 situations: (1) When the set is in “standby mode”. (The display will automatically always show the current time). In this situation the blue backlight is normally off (to save electricity) but you can switch on the blue display light by pressing any key, (on the set or remote control) except the “on/ standby”... -
Page 8: Automatic Power On/Off Timer Function
DIGITAL CLOCK AUTOMATIC POWER ON/OFF TIMER FUNCTION - This set has a timer function to enable you to program the unit to automatically switch “on” or “off” at preset times. This is useful as a morning alarm clock : (Note: This timer function only works after the clock has been set). HOW TO SET TIMER 1. -
Page 9: General Function
GENERAL FUNCTION SNOOZE FUNCTION - Whenever the alarm timer comes on, it can be temporarily suspended for a short period of approximately 10 minutes, by pressing the “snooze” key (on remote control) once. - The timer will then automatically come on again after approximately 10 minutes “snooze” period has ended. -
Page 10: Using The Audio Line In Connection
GENERAL FUNCTION USING THE AUDIO LINE IN CONNECTION (AUX-INPUT) - You can connect the audio output of an external device such as a MP3 player to this unit, to listen to the sound of that device through the high quality amplifi er of this music system. - To connect the external device please use a standard stereo headphone (3.5mm to 3.5mm plugs) cable to connect the “headphone-out or audio line-out”... -
Page 11: Radio
RADIO OPERATION OF RADIO - Press the “on/standby” key once to switch on the unit. - Press the FUNCTION key once, the display shows “tuner”. - To improve FM-radio reception, fully extend the FM-antenna wire and adjust it’s position. - Anytime in fm stations, use the “id3/ FM mode” key to select the desired mode (FM Mono/ Stereo). -
Page 12: Cd-Mp3
CD-MP3 WHAT IS MP3 ? - MP3 (MPEG 2, layer 3) is a digital fi le format for audio (music). - You can download MP3 songs from many websites on the internet (please observe the copyright regulations of your country). - MP3 songs are much smaller in memory size compared with normal audio format songs. -
Page 13: Usb & Sd Card
USB & SD CARD USB-DRIVE & SD-CARD MP3 PLAYBACK - This unit is equipped with a USB socket which can accept and play MP3 fi les stored on standard USB fl ash drives (also known as “pen drives”) which are for memory storage. (Compatible with USB version 1.1 &... -
Page 14: Programming For Usb-Pen Drive/ Sd-Card
USB & SD CARD PROGRAMMING FOR USB-PEN DRIVE/ SD-CARD 1. Switch on the set, insert a USB-pen drive or SD-card and select “USB/ card function” function. Then press the STOP key. 2. Press the PROG./CLOCK ADJ. key. The display shows: THREE DIGIT P 01 TRACK (SONG)NUMBER... -
Page 15: Preparation Of Ipod Dock
iPod OPERATION PREPARATION OF iPod DOCK To connect an iPod with a dock connector insert the dock adaptor that fi ts your iPod, and then connect your iPod. Your HiFi includes dock adaptors that work with most models of iPod with dock connectors. If you want to connect another iPod, you can easily remove the dock adaptor from your Hi-Fi using a fi... -
Page 16: Operation With The Ipod
iPod OPERATION OPERATION WITH THE iPod - Turn on both the unit and the iPod. - Connect the iPod with the dock connector as described. - Press the “iPod/ AUX” key repeatedly until the display shows “iPod”. - The unit will automatically start playback of the songs. - The iPod display will indicate the information of the current song (track). -
Page 17: Specifi Cations
SPECIFICATIONS SPECIFICATIONS Power Supply : ....DC 15V, 3A though built-in DC jack External AC-DC power adaptor 100V-240V ~ 50/60Hz Power Consumption : ....25W Speaker : ....Main speaker 2.5” x 2 + additional 3” x 1 E-14...
