Summary of Contents for Soneco MC3
-
Page 1: User Manual
™ 1(20) Soneco MC3 USER MANUAL SONECO Oy Tuotekuja 5 FIN-90410 Oulu Finland Tel. +358 10 77 88 300 Fax. +385 8 311 4486 e-mail: info@soneco.fi www.soneco.fi © Soneco Oy July 2013 © Soneco Oy. V 25.3.2013 JR... -
Page 2: Warranty
In consumer trade Soneco is liable for the warranty defined by EU regulation. The authorized seller of Soneco products will either repair or replace the defective device that fall under warranty. Warranty does not apply to wear due to use or accessories. The warranty does not apply if the device has been in wrong or inappropriate use, opened, altered, connected to other equipment, used with other charger than Soneco P4300. -
Page 3: Table Of Contents
Warranty........................2 Purpose ot MC3 ......................5 To start with......................5 Preparing for the use....................5 Quick procedure for using MC3 for the first time .............6 1. Charging of the battery..................7 2. Warning message due to low battery ..............7 3. Start-up .......................7 4. The programming mode ..................8 5. - Page 4 ™ 4(20) © Soneco Oy. V 25.3.2013 JR...
-
Page 5: Purpose Ot Mc3
Purpose ot MC3 Soneco MC3 is a small radio device for messaging and voice calls. With a single press of its only button, MC3 sends a text message to one, two or three stored telephone numbers. MC3 operates in all 900 and 1800 MHz mobile communication networks with which the provider of SIM-card in MC3 has access or a roaming agreement. -
Page 6: Quick Procedure For Using Mc3 For The First Time
™ 6(20) Quick procedure for using MC3 for the first time 1. Switch ON the power by pressing the button (for over 5 seconds) until the yellow light starts to blink. Release the button. 2. If the device has not been programmed before, it enters to the programming mode automatically and the YELLOW and the GREEN lights start blinking alternately. -
Page 7: Charging Of The Battery
If you wish to change the existing settings start up the device as explained above, but press the button shortly during the start-up while the GREEN light is on for 5 seconds. The device enters the programming mode. © Soneco Oy. V 25.3.2013 JR... -
Page 8: The Programming Mode
U- numbers. The X (eXtra) number is for messaging or calls in a way that is not possible for numbers 1 to 3. In MC3, the X number is for voice calls. The 5 or U © Soneco Oy. -
Page 9: Setting The Message
The message is set in programming mode with a message to the device. The message has to contain between command brackets “<<<” and “>>>” a command "sms:" and the message with a maximum length of 150 characters as below <<<sms:Own_message>>> E.g.<<<sms:Contact reception>>> © Soneco Oy. V 25.3.2013 JR... -
Page 10: Basic Settings
The character x with value 0 or 1 defines whether the device is able to make a call to the 4 number (x=1) or not (x=0). E.g. a command “<<<MC30>>>” defines MC3 without a possibility to make a call to the 4 number. 8. Options The device offers several options. -
Page 11: Security And General Settings
. x5 is a buzzer beep when the called party picks up, i.e. goes to off-hook and the audio line to called party is open. For text messages, only x1 is relevant. The default setting for MC3 is that all tones 1 to 4 are ON. In elder devices this setting is fixed. -
Page 12: Standby Mode
Rxxxxxyyy: Voice call settings in alarm mode. Values x apply to MC3 and y apply to CC3. In alarm mode, MC3 can make a call to X-number or receive calls as instructed by x values. x = 10 instructs the device to automatically call the X-number (i.e. -
Page 13: Sending Of The Message
The device responds to the same number with a message containing estimated remaining battery capacity in %, battery voltage in mV and the information about whether a charger is connected and a call ongoing. © Soneco Oy. V 25.3.2013 JR... -
Page 14: Voice Call Features In Normal Ready State
In most models earpiece volume can be controlled (G-command) during the call. 15. Voice call features in alarm mode In the alarm mode, MC3 can be set to make an automatic call, a call by pressing the button, to enable or to reject incoming calls and to make them silent or automatically answered. -
Page 15: The Life-Time, Capacity And Maintenance Of The Battery
The device stores the events of network losses, switching the device on or off and device's internal errors. In the service this data can be read with date and time stamps. © Soneco Oy. V 25.3.2013 JR... -
Page 16: Unrecognized Fault Situations
If an entry to the programming mode by the user has been prevented and the users have lost the information for sending and acceptable PRG-command, the GSM phone number of Soneco's service can command the device in to programming mode and read the technical information. This number can not control the calls or the messages nor can it be used as a calling number. - Page 17 ™ 17(20) © Soneco Oy. V 25.3.2013 JR...
-
Page 18: Annex A: Tone And Light Indications Of Mc3
™ 18(20) Annex A: Tone and light indications of MC3 A1. When the device is OFF (OFF mode) In the OFF mode there is no indication. Upon pressing the button, the device gives and audible signal and the YELLOW light is on. - Page 19 Three RED flashes with a tone after continuous GREEN or blinking YELLOW. Transmission of the message failed. The device returns to ready state. A6. In MC3 alarm mode GREEN blinking frequently: Alram mode actice. In earlier models this indication is stopped by the user's next action.
-
Page 20: Important To Observe
Operating temperature: -10 ... + 55 C (when charging, 0 ... + 45 C) SIM card: 3,0 V SAR: < 0,5 W/Kg Operating voltage: 3.7 V 0523 Declaration of conformity: The product complies with the requirements of the European Council directive 1999/5/EY. © Soneco Oy. V 25.3.2013 JR...
