Do not start or stop the unit by plugging in or pulling out the power cord. Always check the power cord for signs of damage before use. If the power cord is damaged, contact SUNRISE TRADEX Customer Service (see end of this manual). Do not install or use the unit in the following places: •...
INSTALLATION ACCESSORIES MAY DIFFER FROM ILLUSTRATIONS Before beginning installation, make sure to have close at hand all the tools you will need (listed below) and that all accessories and hardware parts provided with your air conditioner (as shown) are included. Top mounting rail and laterals (3 in total) Right Foam gasket...
Note : been detected. Do not use the air conditioner and/or attempt to reset the LCDI plug. Immediately contact SUNRISE TRADEX Customer Service (see end of this book). WARNING ! DO NOT PRESS the TEST button while the air conditioner is operating.
INSTALLATION WINDOW REQUIREMENTS 1. These instructions and installation parts are for a standard double-hung window. It can be installed with our without the expandable panels. Make sure the opening is large enough for the unit size . Modify accordingly for other types of window. 2.
INSTALLATION INSTRUCTIONS Please read ALL instructions before installing. Two persons are recommend to install this product. If a new electrical outlet is required, have the outlet installed by a qualified electrician before installing unit. PRELIMINARY INSTRUCTIONS Do the following before starting to install unit. Window sash seal See illustrations below.
WINDOW MOUNTING 1. Remove chassis 8. IMPORTANT : Mechanical damages 1. Pull down front panel and remove filter. could occur if the protections are not removed before starting the unit. Your (See fig.1). unit may come with internal packaging. 2. Lift front upwards and place to one side. This packaging must be removed prior 3.
INSTALLATION INSTRUCTIONS 3. Shift cabinet left or right as needed to line up cen- ter of cabinet on center line marked on stool. 4. Fasten cabinet to window stool with 2 screws into Air conditioner Plastic cabinet frame holes (you may wish to pre-drill pilot holes). Top view Locking ”I”...
WINDOW MOUNTING 3. Install support brackets (with sill angle brackets 2. Attach right angle safety lock as shown. attached) to correct hole in bottom of cabinet as shown. 4. Tighten all 6 bolts securely. Safety lock 3/4” long hex-head screws 1/2”...
LED DISPLAY CONTROL PANEL To turn the air conditioner on or off. Temp Temp Energy Sleep Timer Timer Clean Check Saver Filter High Mode Timer Press this button to select the mode (in sequence) : On/Off Auto Cool Auto AUTO COOL DRY* Follow...
UNIT OPERATION IMPORTANT NOTICE : Do not pierce the bottom of the air conditioner. Excess water is accumulated to cool down the temperature of the capacitor (outdoor unit). It is normal to hear the capacitor’s blade hit water accumulated in the bottom of the unit. Not respecting this notice will automatically void the warranty of the unit.
UNIT OPERATION ENERGY SAVER MODE This feature can be used when the air conditioner is COOLING. Based on set temperature, the fan cycles on and off with the compressor. This mode results in variations of room temperature and humidity. It is recommended to use this mode when the room is unoccupied. 1.
REMOTE CONTROL Your remote control may differ LED REMOTE DISPLAY from illustration. ON/OFF : Turns the unit on or off FAN : Sets fan speed to AUTO -LOW -MED -HIGH MODE : Sets operation mode to AUTO - COOL - DRY - HEAT - FAN TIMER : Sets the timer to an automatic TURN ON ENERGY SAVER : sets unit to...
Page 15
REMOTE CONTROL HOW TO OPERATE THE REMOTE CONTROL • This air conditioner has a built-in microcomputer memory that will save all set data ; when pressing ON/OFF to start the unit, operations set before the shut off will resume. ETTING THE REMOTE CLOCK Before operating the remote control, it is important to check and set the remote clock.
Page 16
REMOTE CONTROL ETTING THE TEMPERATURE Press to set temperature - it will show on the remote Set Temp display When pressing and holding the keys together for 3 sec., display alternates between C and • Temperature cannot be set and does not show in FAN only mode. ETTING THE TIMER •...
AIR VENT AND AIR DIRECTION CONTROLS AIR VENT AND EXHAUST CONTROL. (ON CERTAIN MODELS ONLY) 1. For maximum continuous cooling, CLOSE the AIR VENT by completely pushing the tab in (Fig. A) ; only the air in the room is circulated. 2.
MAINTENANCE shock. • Always turn off and unplug the unit before cleaning to avoid electrical CLEANING THE FILTER The air filter is removable for easy cleaning. A clean filter helps to remove dust, lint and other particles from the air. A clean filter is also essential to maximize the cooling and operating efficiency of the air conditioner.
Refer to the unit rating plate and properly rated? modify power source accordingly. The unit starts and stops The internal evaporator and Call SUNRISE TRADEX frequently, or frequently outside condenser coils look dirty or Customer Service. obstructed by debris. blows fuses or trips the Make sure that there is no other circuit breaker.
If room temperature is not within the unit working range, it may not work properly. For the air conditioner technical specifications, data may vary ; please refer to the rating plate of the unit. CUSTOMER SERVICE Contact SUNRISE TRADEX Customer Service for : • Replacement parts • Technical support • Warranty claims...
Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, SUNRISE TRADEX CORP. will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
