Manual Chromatic Tuner

Precautions

1) Please read all instructions before operating this unit.

2) Please read all safety warnings and instructions, and keep this manual for future reference.

3) Do not use this apparatus near water or moisture.

4) Do not install near any heat sources or other apparatus that produce heat.

5) Only use attachments/accessories specified by the manufacturer.

6) Clean only with dry cloth.

7) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in any way, does not operate normally, or has been dropped.

DO NOT ATTEMPT TO SERVICE THIS EQUIPMENT. ONLY QUALIFIED PERSONNEL SHOULD SER-

VICE THIS EQUIPMENT. DO NOT MAKE ANY INTERNAL ADJUSTMENTS OR ADDITIONS TO THIS

EQUIPMENT AT ANY TIME OR TAMPER WITH INTERNAL ELECTRONIC COMPONENTS. FAILURE TO

FOLLOW THESE INSTRUCTIONS MAY RESULT IN ELECTRICAL SHOCK AND WILL VOID THE WAR-

RANTY.

Do not expose this unit to excessive heat. This unit is designed to operate between 32F and 104F (0oC and

40oC). This unit may not function properly under extreme temperatures, and should be allowed to return to

recommended temperatures before use.

Calib – The seven LEDs on the front of the pedal represent seven different calibrations. Pressing the Calib

button, allows scrolling through these settings. The calibration settings of the tuner are from 437Hz to

443Hz with the default value at 440Hz. Disconnecting the power source and then reconnecting will reset the

calibration to 440 Hz.

Note – Press the Note button to cycle the display through 0,A,A#,B,C#,C,,D,D#,E,F,F#,G,G#, for individual

or 'fixed' note tuning. The chosen note will blink three times indicating the tuner has entered the 'fixed' note

tuning mode. In this mode, the far left LED indicates 'flat' tuning, and the far right LED indicates 'sharp'

tuning. The LED's blink faster to indicate distance from the note, and blink slower as the tuning gets closer.

When neither LED is lit, accurate tuning has been achieved. Holding the Note button for 2 seconds and

then releasing, will return the display to '0', and will exit the 'fixed' note mode immediately.
