Summary of Contents for oxic XFO1013TS
- Page 1 TRANSMITER AND RECEIVER PAIR SINGLE MODE XFO1013TRS SERIES TRANSMITER : XFO1013TS / XFO1013TM RECEIVER: XFO1013RS / XFO1013RM 1-CHANNEL DIGITALLY ENCODED VIDEO / 1-CHANNEL BI-DIRECTIONAL DATA MULTIPLEXER USER’S MANUAL...
-
Page 2: Table Of Contents
Table Of Contents General Information ……………………………………………. 2 Introduction …………………………………………………… 2 Technical Specifications ………………………………….. 2 Installation Instructions ………………………………………... 4 Installation Procedure …………………………………….. 4 System Terminal Block Connections …………………. 5 Indicator LEDs ………………………………………………. 6 Troubleshooting …………………………………………………. 8 Limited Warranty ………………………………………………….9 １... -
Page 3: General Information
GENERAL INFORMATION Introduction: The OXIC XFO-1013TRS Series video and data transmitter and receiver support simultaneous transmission of one channels of 8-bit digitally encoded video and one channel of bi-directional data over one multimode and single-mode optical fiber. The modules are universally compatible with major camera systems and support RS-485 and RS-232 data protocol. - Page 4 WAVELENGTH 850/1310nm Multimode 1310/1550nm Singlemode OPTICAL EMITTER: Laser Diode NUMBER OF FIBERS CONNECTORS Optical： Video： Data： Shield RJ-45 Plug GENERAL Power Supply： DC12V @ 600mA Size： 195mm x 191mm x 36mm Construction： Aluminum MTBF： > 100,000 hours Operating Temp： -30℃ to +50℃ Storage Temp：...
-
Page 5: Installation Instructions
LED should be avoided at all times. INSTALLATION INSTRUCTIONS Installation Procedure The OXIC XFO-1013TRS video transmission systems series are preset for immediate use. There are indicator LEDs on the units for monitoring the real-time status of video, data and power. The following instructions describe the typical installation procedure and the function of the LED indicators located on each unit. -
Page 6: System Terminal Block Connections
6. The system should now be operational. System Terminal Block Connections The various input and output connections for OXIC XFO-1013TRS Series system are as follows: Video Input or Output: BNC Connectors Data RS-485 Connection: Terminal No.1——①: RS-485 (+) -
Page 7: Indicator Leds
Data RS-232 Connection: Terminal No.6: Signal being transmitted out over fiber Terminal No.7: Signal being received in from fiber Terminal No.8: Ground *Terminal Block for Data Connection Camera Site Connect the Terminal No.7 (232T) in the terminal block connected from the transmitter to RS-232 (232R) port of the controlled unit (pan/tilt, dome), and Terminal No.8 (GND) is used for ground connection. - Page 8 Transmitter: Video: OFF: Indicates no video detected on input BNC connector (No Video present on input BNC) ON: (blue) Indicates video detected on input BNC connector (Video present on input BNC) Data (DATA1): OFF: Indicates no data detected on the transmit data cable Blinking: (Blue) Indicates data transmitted at the rate of the operation data.
-
Page 9: Troubleshooting
TROUBLESHOOTING Optical Fiber The OXIC XFO-1013TRS Series is available with most applications using multimode or single mode optical fibers. Please be certain that the correct size and type of the fiber is being used for the particular mode transmitter/receiver combination. -
Page 10: Limited Warranty
LIMITED WARRANTY Tiandy Tech guarantees two (2) year repair at no charge and lift-time maintenance at prevailing rate from the date of delivery. Tiandy Tech series products are warranted to be free from defects in materials or workmanship for one year from the date of retail purchase. We reserve the final right to judge the malfunction of the products.
