XR6/XR10

User's Guide

Table of Contents

Need help?

Do you have a question about the XR6 and is the answer not in the manual?

Questions and answers

Summary of Contents for SecurityCommand XR6

Page 1 XR6/XR10 User’s Guide...
Page 2 Silencing an Alarm All/Perimeter and Home/Away Systems 1. While the alarm bell or siren is sounding, enter your user code. The keypad displays DISARM SILENCE. 2. Press the Select key under SILENCE to stop the bell or siren. This does NOT disarm the system. 3.
Page 3: Table Of Contents
Security Command User's Guide ® for XR6 and XR10 Command Processor Panels Table of Contents Section Page Section Page Emergency Evacuation Plans ........ii Zone Event Displays ........... 18 About Your Security System ........1 Arming and Disarming Event Displays ...... 18 The Security Command Keypad ......
Page 4: Emergency Evacuation Plans
Emergency Evacuation Plans The National Fire Protection Association recommends that you First Floor Second Floor establish an emergency evacuation plan to safeguard lives in the event of a fire or other emergency. Use the following steps as a guide. Fire Escape Draw a floorplan of your home or business On a clean sheet of paper, draw the walls, windows, doors, and stairs.
Page 5: About Your Security System
Introduction About Your Security System A Note About False Alarms One of the most important concerns facing the security industry Your Security Command system has been designed with your safety today is false alarms. The accidental dispatching of police and fire and comfort in mind.
Page 6: The Security Command Keypad
The Security Command Keypad Data Entry keys These keys allow you to enter your user code when arming or Your system may have one or more easy to use Security Command disarming or enter other information into the system. keypads (16 or 32 character) that allow you to properly operate the system.
Page 7: Special Security Command Messages
Special Security Command Messages SYSTEM TROUBLE or SERVICE REQUIRED There is an electronic failure in your system. Contact our service As you use your system, you will occasionally see a keypad display department as soon as possible. that asks you to enter a code or that describes a condition on the system.
Page 8: Understanding Security System Terms
Understanding Security System Terms Entry or Exit Zone Almost all systems have one or more doors through which you can Throughout this guide, and in some displays on your keypad, you will enter or exit the premises. These doors are programmed with a delay see certain words or phrases that might be unfamiliar.
Page 9: Status List
Understanding Security System Terms Status List The keypad Status List displays any alarm or trouble condition on a Central Station Monitoring zone and any trouble condition that occurs with the AC power or Your system can also be programmed to automatically send alarm, battery power.
Page 10: How Your System Operates
How your System Operates A force armed zone is ignored by the system until it restores to normal. A bypassed zone is ignored by the system during the entire Your system has been programmed to operate in one of two modes: armed period.
Page 11: All/Perimeter System Arming
All/Perimeter System Arming Arming an All/Perimeter System 1. Enter your user code. The keypad displays PERIM ALL. Area Assignment: Your security system is divided into two separate areas. Motion detectors, inside doors, and other interior protection 2. Select PERIM to arm the Perimeter area only. devices are assigned to the Interior area while windows and exterior 3.
Page 12: All/Perimeter System Disarming
All/Perimeter System Disarming Disarming During an Alarm Disarming: While the system is armed, you can only enter the 1. While the alarm bell or siren is sounding, enter your user code. premises through an entry/exit delay door without causing an alarm. The keypad displays DISARM SILENCE.
Page 13: Home/Away System Arming
Home/Away System Arming 4. Select AWAY to arm the Perimeter, Interior, and Bedroom. 5. The keypad displays zones that have been bypassed prior to Area Assignment: Your security system is divided into two or three arming and 24 hour zones that are in a bad condition. separate areas.
Page 14: Home/Away System Disarming
Home/Away System Disarming Disarming a Home/Away System 1. During the entry delay, the keypad displays ENTER CODE:. Disarming: While the system is armed, you can only enter the Enter your 4-digit user code. premises through an entry/exit delay door without causing an alarm. After opening the door, the Security Command keypad sounds a 2.
Page 15: Security Command User Menu
Security Command User Menu Sensor Reset Many of the features of your system have been put into a User Menu User Code Level: Master or Standard you can access from any Security Command keypad. The menu Function: Resets smoke or glassbreak detectors. Also clears Fire/ requires you to enter your user code and then only shows those Supervisory alarm and trouble keypad displays.
Page 16: Outputs On Off
Outputs On Off Bypass Zones User Code Level: Master or Standard. User Code Level: Master or Standard. Function: Allows you to turn the system's outputs on and off. Function: Allows you to bypass a zone prior to arming the system. This function is used to individually turn your system’s relay outputs Bypassing is usually done when a zone cannot be restored to normal on and off.
Page 17: Zone Monitor
Zone Monitor Using the Zone Monitor Function 1. Access the User Menu. User Code Level: Master and Standard. 2. Press the COMMAND key until ZONE MONITOR? displays. Function: Allows the system to monitor selected disarmed zones (doors, windows, or motion detectors). The keypad will sound a tone 3.
Page 18: System Test
System Test User Codes User Code Level: Master or Standard. User Code Level: Master only. Function: System Test is used to test the battery, alarm bell or siren, Function: Allows you to add or delete a user from the system or and communication to a central station.
Page 19 User Codes 7. The display changes to MASTER? NO YES. Select YES to make continued this a Master code level with the authority to Add, Delete, and User Code Authority Levels Change user code information. Selecting NO displays TEMP CODE NO YES. System Options Standard Master...
Page 20: Ambush Codes
User Codes Ambush Codes continued Your system may be programmed to allow user number 1 to be an Changing User Code Numbers Ambush code. This Ambush code functions identically to other codes 1. Access the User Menu. with the exception that it sends a silent alarm to the central station. This silent alarm alerts the operator to a duress situation at the 2.
Page 21: Display Events
Display Events Using the Display Events Function 1. Access the User Menu. User Code Level: Master or Standard. 2. Press the COMMAND key until DISPLAY EVENTS? displays. Press Function: Allows you to review up to 16 past events that occurred any Select key.
Page 22: Zone Event Displays
Zone Event Displays Arming and Disarming Event Displays This section displays alarms, troubles, and other events that could This displays any arming or disarming of system areas. occur on your system's protection zones. Display Description Display Description JONES RESIDENCE All areas of the system were armed by JONES RESIDENCE A burglary alarm occurred on zone 2.
Page 23: User Code Change Event Displays
User Code Change Event Displays User Checkin Event Displays This displays any addition, deletion, or change to a user code. This shows when a user selected the pager CHECKIN feature from the User Menu. See page 11 for more information. Display Description Display...
Page 24: System Setup
System Setup Security Command keypads We have provided this System Setup section to allow you to track the Address Locations current and future status of the programmable options on your 1 _____________________________________________ Security Command system. If you make changes to the system, you 2 _____________________________________________ should update the information contained on these pages.
Page 25: User Codes
User Codes Your system provides you with twelve user codes you can program Area Names for individual users. As you add new users or change current user's List your system's area names and numbers below: codes, you can keep track of their name, user number, and authority level here in this section.
Page 26 Numeric Pager Display 00128–301 234 Account Message Always Zone, Area, or Number Zero User Number Account Number This number has been programmed into your Security Command system as an identifier. Whenever the system sends a message to your pager, it will always send the account number first to identify itself.
Page 27 Notes:...
Page 28 LT-0226 (8/02)

This manual is also suitable for:

Xr10
