DM-X10
192 Channel DMX Controller
USER MANUAL
154.091UK
Vers ion 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-X10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for QTX Light DM-X10

  • Page 1 DM-X10 192 Channel DMX Controller USER MANUAL 154.091UK Vers ion 1.0...

  • Page 2: Table Of Contents

    DMX 5 1 2 C ON T R OL L E R S E R IE S Content Before you begin What is included........... . .

  • Page 3: What Is Included

    DMX 5 1 2 C ON T R OL L E R S E R IE S 1.1 What is included 1) DM-X10 controller 2) DC 9-12V 500mA, 90V~240V Power Adapter 3) Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition.

  • Page 4: Features

    * Polarity selector General Overview * The DM-X10 is a universal intelligent lighting controller. It allows the control of 12 fixtures composed of 16 channels each and up to 240 programmable scenes. Six chase banks can contain up to 240 steps composed of the saved scenes and in any order.

  • Page 5: Channel Faders

    DMX 5 1 2 C ON T R OL L E R S E R IE S Item Button or Fader Function Fixture select buttons Fixture selection Fixture indicator LEDS Indicates the fixtures currently selected Universal bump buttons representing scene Scene select buttons location for storage and selection...

  • Page 6: Common Terms

    DMX 5 1 2 C ON T R OL L E R S E R IE S 2.5 Common Terms The following are common terms used in intelligent light programming. Blackout is a state by where all lighting fixtures light output are set to 0 or off, usually on a temporary basis.

  • Page 7: Fixture Addressing

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.1.2 FIXTURE ADDRESSING The DM-X10 is programmed to control 16 channels of DMX per fixture, therefore the fixtures you wish to control with the corresponding FIXTURE buttons on the unit, must be spaced 16 channels apart.

  • Page 8: Fade Time Assign

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.1.3 FADE TIME ASSIGN You can choose whether the board s fade time during scene execution is implemented broadly to all output channels or only to the Pan & Tilt movement channels. This is relevant because often you will want gobos and colors to change quickly while not affecting the movement of the light.

  • Page 9: Review Scene Or Chase

    3.3.2CREATE A SCENE : A scene is a static lighting state. Scenes are stored in banks. There are 30 bank memories on the controller and each bank can hold 8 scene memories. The DM-X10 can save 240 scenes total. Action : Notes : 1) Press the PROGRAM button until the LED blinks.

  • Page 10: Running A Program

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.3.3 RUNNING A PROGRAM Action : Notes : Use BANK UP/DOWN buttons to change Program Deselect Blackout if LED is lit. banks if necessary. Press the AUTO DEL button repeatedly until the AUTO LED turns on.

  • Page 11: Chase Programming

    DMX 5 1 2 C ON T R OL L E R S E R IE S Chase Programming A chase is created by using previously created scenes. Scenes become steps in a chase and can be arranged in any order you choose. It is highly recommended that prior to programming chases for the first time;...

  • Page 12: Edit Chase (Copy Scene Into Chase)

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.4.5 EDIT CHASE (COPY SCENE INTO CHASE) Action : Notes : Press and hold the PROGRAM button to enter programming mode. Press the desired CHASE button. Select the BANK that contains the scene to be copied using the BANK UP/DOWN buttons.

  • Page 13: Delete All Chase Programs

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.4.9 DELETE ALL CHASE PROGRAMS CAUTION! This procedure will result in irrevocable loss of chase step memory. The individual scenes and program banks will be preserved. Action : Notes : Turn OFF controller.

  • Page 14: Delete A Scene

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.5.3 DELETE A SCENE Action : Notes : Press and hold the PROGRAM button to enter When deleting a scene the physical location is not programming mode.

  • Page 15: Blackout

    DMX 5 1 2 C ON T R OL L E R S E R IE S 3.6.4 BLACKOUT The Blackout button brings all lighting output to 0 or off. 4 APPENDIX DMX Primer There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A fixture capable of receiving DMX 512 will require one or a number of sequential channels.

  • Page 16: Dmx Dipswitch Quick Reference Chart

    DMX 5 1 2 C ON T R OL L E R S E R IE S 4.3 DMX Dipswitch Quick Reference Chart DMX Address Quick Reference Chart Dip Switch Position DMX DIP SWITCH SET 0=OFF 1=ON X=OFF or ON 128 160 192 224 256 288 320 352 384 416 448 480 129 161 193 225 257 289 321 353 385 417 449 481 130 162 194 226 258 290 322 354 386 418 450 482...

  • Page 17: Technical Specifications

    DMX 5 1 2 C ON T R OL L E R S E R IE S 4.4 Technical Specifications 130mm 70mm 482mm Weight........................... 3.5 Kg Operating Range..................DC 9V-12V 500mA min Maximum ambient temperature..................45 C Data input .................. locking 3-pin XLR male socket Data output ................
