HDMI & USB, AUDIO, RS232, IR CAT5 Extender
ITEM NO: HXU-1
The HXU-1: HDMI, USB, Analog audio, RS232, and IR extender is designed to extend and distribute all
signals over one CAT5e up to 150 meters, and provides a local HDMI monitor output. It provides superior
video quality up to 1920 x 1200 resolutions using cost effective UTP cable instead of: HDMI, RS232, and
other cables, for an easier, neater, more reliable installation. The transmitter and receiver units can be
connected together for a Point-to-Point connection via CAT5e/6 cable; or a Point-to-Many connection via a
gigabit fast network switch with IGMP snooping and 8K Jumbo Frame support. It is optimized for
applications such as: broadcasting systems, multimedia displays, multi-data sharing, digital signage, home
entertainment integration, industrial control, hospital, education, security, and HDMI over IP matrix
switching.
Features:
!
Extend HDMI, RS232, IR and USB signals over one CAT5E/CAT6 cable.
!
Supports resolutions up to 1080p Full HD and 1920 x 1200 (WUXGA) 32bpp@ 60 Hz
!
Transmission range up to 150M over CAT5e, 180M over CAT6.
!
Supports 2-way RS232 commands at baud rate 115200 (control software on a PC, or other automated
control system hardware) to control devices attached to the matrix using RS232. Full Duplex data
communication.
!
HDMI 1.3b and HDCP compliant.
!
HDMI audio support up to LPCM 7.1@192Khz
!
Built in Bi-Directional analog audio.
!
Built in Bi-Directional IR.
!
HXU-1Tx transmitter unit includes built in HDMI loop output.
!
HXU-1Rx receiver unit features 4USB ports (1 USB 1.1 & 3 USB 2.0), to extend USB peripheral
devices, such as flash disk, hard disk, keyboard, mouse, etc.
!
Supports point to point and multiple source devices to multi-display connections/HDMI matrix switch
over IP via Gigabit network switch with IGMP Snooping and 8K Jumbo Frame support.
!
Matrix extends USB, IR, and RS232 and is controllable via IP, IR, or RS232
Preliminary Owner's Manual
HDMI KVM Over IP with USB,RS232, IR, Analog Audio
Advertisement
Related Manuals for Transformative Engineering HXU-1
Summary of Contents for Transformative Engineering HXU-1
- Page 1 HDMI KVM Over IP with USB,RS232, IR, Analog Audio The HXU-1: HDMI, USB, Analog audio, RS232, and IR extender is designed to extend and distribute all signals over one CAT5e up to 150 meters, and provides a local HDMI monitor output. It provides superior video quality up to 1920 x 1200 resolutions using cost effective UTP cable instead of: HDMI, RS232, and other cables, for an easier, neater, more reliable installation.
- Page 2 Installation View: Multiple Transmitters to Multiple Receivers Connection: (Matrix Switcher) HXU-1Rx HXU-1Tx HXU-1Rx Point to Point Direct Connection: (Extender) HXU-1Tx HXU-1Rx...
- Page 3 One Transmitter to Multiple Receivers Connection: (Splitter) HXU-1Rx HXU-1Tx HXU-1Rx Multiple Transmitters to One Receiver Connection: (Switcher) HXU-1Rx HXU-1Tx...
-
Page 4: Led Indication Status
Panel View: Transmitter Receiver LED Indication Status: Power (Green LED): Flash Booting Boot completed Link (Blue LED): Flash Connecting or connected but no HDMI input Transmitter connected with Receiver RJ45 LED: Green Flash Data transmission Orange On Ethernet connected Back Panel Rotary Switch Function: HXU-1Tx and HXU-1Rx must be set same channel in order to do mutual transmission. -
Page 5: System Default Settings
10pcs for simultaneous video streaming. USB Hot Key Function In multicast mode the HXU-1 supports multiple USB keyboards and mice in each receiver, just plug and play, but only one USB FLASH drive / hard disk may be used at a time. - Page 6 Remote Control Function: If you do not use PC computer management to setup your HXU-1s, then you could use the IR infrared remote control to preset channel selection. The IR remote control and the equipment Remote ID must be using same ID. The default Remote ID is 8.
- Page 7 Remote Control Operation: Select Channel Mode 1: use select channel, if no any action after 3 seconds then it is the select channel or press immediately to confirm the input channel. Mode 2: select the channel number and press to confirm the input channel. Select Function Mode 1: use select function, press...
- Page 8 RS-232 Assign Mode User could use RS-232 port of transmitters at baud rate 115200bps (8-N-1) to operate/setup the receivers at same channel Command format: >CMD_Address> Command Parameters All accord receivers will run the command and parameters. 3 types of user defined numbers are available, in addition to MAC &...
- Page 9 Tx to Rx when in Multicast/Matrix mode. From a control system; affix IR emitter to (or flash) each HXU-1Tx, plug IR flasher included with HXU-1 into a HXU-1Rx’s “IR TX” 3.5mm mini-jack, face that flasher at the IR sensor window on that Rx, and repeat for each receiver. For control of connected displays, add an IR splitter to the HXU-1Rx’s “IR TX”...
- Page 10 e.g.4: Control the receiver with Device No. 123 with IR (all other receivers will not) in 30 seconds: [Start] [All] [Command] [2] [Parameter] [0] [End] (All receivers IR function ready to Off) [Start] [D#] [1] [2] [3] [Command] [1] [Parameter] [3] [0] [End] (IR function of the receiver with Device No.
- Page 11 Computer software operation, please refer to software operating instruction. Web Setting Function The HXU-1 provides detailed settings over your web browser; you have to know the IP address before setting. There are three ways to get the IP address of receiver: 1.Local IP shows on right bottom screen when booting.
- Page 12 Login in to the web setting: Use CAT5 cable to connect transmitter/receiver RJ45 port to PC LAN port, open IE browser then select View " Explorer Bars " Bonjour. Double click on “HTTP on ast-gateway(HXU-1Tx)” or “HTTP on ast-client (HXU-1Rx)”, it will pop up web setup in Bonjour windows as below:...
- Page 13 System Menu: Version Information Firmware version information Update Firmware Update system firmware Utilities System tools Factory Default Set system to factory default Reboot Reboot system Default EDID Set EDID to default Console API Command Run Console API command Statistics System status...
- Page 14 Once MultiCast and Auto USB are selected, click Apply. A Pop-Up will direct you to reboot the HXU-1. To reboot; select the ‘System’ tab at the top of the page, then select the ‘Utilities’ dropdown, and finally select ‘Reboot’.
- Page 15 Functions Menu: For HXU-1Tx Transmitter: Video over IP: This function enables video signals to be sent over a network. Default is checked. Please note HDMI output is OFF when this function is disabled, only analog audio output For HXU-1Rx Receiver: Video over IP: This function setup the video signals send from network, default is checked.
- Page 16 USB over IP Setup: This function allows USB signals to be transmitted over the network, default is checked. Operation Mode: USB device operation setting, default is “Auto select mode” In Unicast mode recommend set to “Active on link”. In Multicast mode recommend set to “Active per request”.
- Page 17 Serial over IP This function allows Serial (RS232) signals to be transmitted over the network Operation Mode: Default is “Type 2 (Recommended. Dumb redirection.)” Baudrate Setting for Type 2 : It could change Baud rate as below : 300, 600, 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200, 230400, default is 115200...
-
Page 18: Specification
(Without USB Power Consumption) Temperature Operation: 0 to 55 , Storage: -20 TO 85 , Humidity: up to 95% Dimensions 125x140x30 125x140x30 Weight Rev. A Transformative Engineering, Inc. 194 Vanderbilt Ave. Norwood, MA 02062-5000 Telephone: 781-769-6410 Fax: 781-255-0975 Email: sales@transformativeengineering.com...
