Summary of Contents for IPcopter tVip_2
- Page 1 Manual tVip_2 10/2011 __________________________________________________________________________ tVip_2 Installation and Operation Manual Please note, that the internet access must not be used near airports (within a radius of 5 km)! 1/34...
-
Page 2: Manual Tvip
Manual tVip_2 10/2011 __________________________________________________________________________ Important Notes • Please be informed, that this product is designed for use on RVs, campers or caravans. The use of the system for any other purpose is not permitted. • Any modification of the system, e.g. by change of reflector, use of... -
Page 3: Table Of Contents
Manual tVip_2 10/2011 __________________________________________________________________________ Contents: Installation Manual......................4 1.1 Deliverables........................4 1.2 Blockdiagram ........................6 1.3 Installation Antenna Systemt ................... 7 1.3.2 Preparation of motor unit ................... 7 1.3.3 Outdoor Installation of Antenna................. 9 1.3.4 Mounting of Reflector ..................10 1.3.5... -
Page 4: Installation Manual
Manual tVip_2 10/2011 __________________________________________________________________________ Installation Manual 1.1 Deliverables Fig. 1: Deliverables 4/34... - Page 5 2-axis Motor, iLNB (Option Internet Kit), TV LNB, feedarm, reflector backstructure, cabling Parabolic reflector Roof mounting plate Receiver + Remote Control (Dreambox) IPcopter Modem + Ethernet cable (Option Internet Kit) DC-Block + short coax cable Antenna mount with manual Az fix Cable clamp Beeper Antenna Security Control...
-
Page 6: Blockdiagram
Manual tVip_2 10/2011 __________________________________________________________________________ 1.2 Blockdiagram Interactive LNB Interactive LNB Rx Tx Rx Tx TV LNB TV LNB STB LNB STB LNB with with integrated integrated DiseqC switch DiseqC switch ignition ignition Antenna Security Antenna Security Control Control Internet Internet... -
Page 7: Installation Antenna Systemt
If you have any doubts, please ask your dealer or vehicle manufacturer IPcopter is not responsible for any damages caused by the installation of the system. 1.3.2 Preparation of motor unit Before installation the motor unit shall be moved to an upright position of the reflector. Please connect the Rx line to the Dreambox and push the blue button on the remote control of the Dreambox. - Page 8 Manual tVip_2 10/2011 __________________________________________________________________________ Blue button: Elevation of antenna backstructure Exit: Stop movement Dreambox Cable without black mark Installation position of of antenna backstructure Fig. 4: Preparation of motor unit 8/34...
-
Page 9: Outdoor Installation Of Antenna
Manual tVip_2 10/2011 __________________________________________________________________________ 1.3.3 Outdoor Installation of Antenna Step 1: Step 5: Select location and Fix antenna mount on mark position of center mounting plate hole and mounting plate. Please ref. To Fig. 3 Step 2: Step 6: Drill 32mm hole Press mounting plate through the roof. -
Page 10: Mounting Of Reflector
Manual tVip_2 10/2011 __________________________________________________________________________ 1.3.4 Mounting of Reflector After the installation the reflector can be mounted on the according backstructure: Please fit the reflector at first on the upper two screws, which are already inserted on the backstructure. Afterwards please fix the lower two screws and finally the upper two screws. -
Page 11: Cabling
Manual tVip_2 10/2011 __________________________________________________________________________ 1.3.6 Cabling After mounting of the antenna the cables shall be fixed. The twin coaxial cable shall be rotated twice around the motor axis with a wide radius, approximately the radius of the mounting plate, and then fix the cables with the cable clamp, please see fig. 5. -
Page 12: Installation Incl. Fritz!Box
IPcopter Modem Please use only the LAN 1 input or DECT Basestation to connect the IPcopter Modem! Fig. 9: Installation Indoor Unit incl. Fritz!Box 1.4.3 Power Supply Ideally the system is supplied directly from the suitable car battery. Please make sure, that the supply cables have a diameter of at least 4 mm. - Page 13 Manual tVip_2 10/2011 __________________________________________________________________________ Connect your Laptop. Google some websites; Send e-mail Browse to 192.168.1.1 Read at “Demodulator Es/No = ?? dB At clear sky the value shall be above 9,5 dB Move antenna to park position (red button) Point to Internet satellite (blue button). Max. number of Scans until...
-
Page 14: Operation Manual
Manual tVip_2 10/2011 __________________________________________________________________________ Operation Manual 2.1 General The duration of the pointing process depends mainly on the distance to your last location: Depending on the location the elevation of the antenna is different: The satellite is stationary located on an equator of a radius of 40.000 km. If you would stay directly below the satellite on the equator, your antenna would look vertically up to the satellite. -
Page 15: Usage Of Remote Control
Manual tVip_2 10/2011 __________________________________________________________________________ The Azimuth (East – West) direction has a limited motion range of +/- 65 degrees. Therefore the antenna roughly has to be manually preadjusted in East –West direction following Fig.10. Fig. 10 shows the preadjustment on the example of a RV, which is positioned with the entrance/awning direction south. - Page 16 Manual tVip_2 10/2011 __________________________________________________________________________ Fig.12: Moving to last position of TV satellite I For pointing to the TV Satellite I please push the orange button on the remote control (for TV satellite II please push the green button). At first you see the above picture: It means, that the antenna is moving to the last position of the TV satellite, in this case Astra 19,2 degrees East.
-
Page 17: Operation Of Tv Receiver
The reset to factory settings may cause the loss of the channel list configuration. • The installation of a software image not provided by IPcopter causes the the distortion of • the control software and the system does not work any more. -
Page 18: Internet Mode
Manual tVip_2 10/2011 __________________________________________________________________________ 2.5 Internet Mode 2.5.1 Pointing of Antenna to Internet Satellite The pointing on the internet satellite, which is the Hellas Sat 2 at 39 degrees East, works analogue to the pointing on the TV satellite: Please push the blue button on the remote control of the Dreambox. - Page 19 Manual tVip_2 10/2011 __________________________________________________________________________ Fig. 16: Fine pointing after satellite detection If fine pointing is finished, the position of the satellite is stored for the next pointing. Sometimes it may happen, that the antenna does not find the satellite or looses the satellite lock.
-
Page 20: Operation Of Satellite Modem
LED goes on. As long as the warning LED is on there is no internet connection! After further 1-2 minutes the Rx LED becomes green. This means, that the IPcopter carrier is received properly. After about one further minute the Tx LED starts to flash. -
Page 21: Booking And Controlling Of Internet Subscription
Manual tVip_2 10/2011 __________________________________________________________________________ 2.5.4 Booking and Controlling of Internet Subscription First of all the subscriber shall register himself in our portal www.ipcopter.com as shown by the screenshots below. Step 1: Registration at www.ipcopter.com Fig. 19: Registration at www.ipcopter.com 21/34... -
Page 22: Load Balancing
Step 2: After Login purchase of Kick off Pack at http://www.ipcopter.com/en/shop/shop.php?catID=100 Fig. 20: Shop at www.ipcopter.com 5 days and 2 days before expiration of the subscription IPcopter forwards a reminder e-mail to the subscriber. Follow on packages easily can be booked on the webshop. 2.5.5 Load Balancing Why is Load Balancing necessary? Unfortunately bandwidth especially at networks for mobile internet access is limited. - Page 23 Especially the thresholds are subject to changes for optimum use of bandwidth at maximum customer satisfaction. The IPcopter Load Balancing scheme checks and counts, within how many of the four time windows the SLA related threshold is exceeded. We call those windows „volume excess windows“.
- Page 24 Manual tVip_2 10/2011 __________________________________________________________________________ download the threshold for the last 5 minutes is not exceeded any more and the maximum speed goes up 768 kbps at medium priority, after less than 60 minutes it goes up to 1500 kbps at medium priority.
-
Page 25: Expert Mode: Modem Web Interface
Manual tVip_2 10/2011 __________________________________________________________________________ 2.5.6 Expert Mode: Modem Web Interface Please open your internet browser and type the management address of the modem 192.168.1.1 Now the web interface of the modem is opened, see the picture below. Should be above 9 dB at clear sky... - Page 26 Manual tVip_2 10/2011 __________________________________________________________________________ 2) Push red button on Remote Control 1) turn antenna until the symbol with the red point is below the open clamp. Close clamp Fig. 23: Parking of antenna Fig. 22: Screenshots Parking 26/34...
-
Page 27: Frequently Asked Questions
Audio (Red/White) cinch connected cable. Q: How can I connect a WiFi Router to the Modem? A: Please connect the data cable of the IPcopter Modem with the WAN Port (please see manual of the WiFi Router) of the WiFi Router. -
Page 28: Antenna
A: No, the antenna controller is not linked to the ignition detect line. One of the reasons is the simplicity of installation. IPcopter strongly recommends a warning note on the dashboards, which reminds you on the antenna or the installation of the Antenna Security Control, which is part of the deliveries. - Page 29 A.: No, because the transmit beam could be damaged. Please order a new reflector. Q.: I am operating my tVip_2 with a tripod. Is it dangerous to be close to the antenna? A.: No. Even close to the antenna the power density is below the legal EMC values. Only between iLNB and reflector those values are exceeded.
-
Page 30: Internet
Q.: I would like to point on another than the preconfigured TV satellites. Is it possible to change the configuration accordingly? A.: This cannot be done by the user. Please inform IPcopter about your requirements and we try to find a solution. - Page 31 A.: Skype is transmitted over the Internet without priorisation. Therefore it is competing for bandwidth with all other applications. If the bandwidth is not sufficient, then the voice quality is reduced. However, IPcopter offers the Skype HP driver for Windows systems to give Skype packets a high priority: http://www.ipcopter.com/en/shop/shop.php?catID=1027 Q.: For voice communication I am using a SIP service and a SIP phone.
-
Page 32: Technical Data
Manual tVip_2 10/2011 __________________________________________________________________________ A.: Especially Windows, but also other software like anti virus software, often automatically start software upgrades in the background. Especially the Windows upgrades have a significant volume. The automatic upgrade of Windows can be switched off. -
Page 33: Declaration Of Conformity
Manual tVip_2 10/2011 __________________________________________________________________________ 5. Declaration of Conformity We, the manufacturer IPcopter GmbH & Co. KG Ziefelei 5 D-88090 Immenstaad Germany declare, that our product tVip_1 and its variants are compliant with the essential requirements and other relevant positions of the R&TTE •... -
Page 34: Contact
Manual tVip_2 10/2011 __________________________________________________________________________ 6. Contact IPcopter GmbH&Co. KG Ziegelei 5 D-88090 Immenstaad Germany Phone: +49 7545 202260 (on working days only, 9:00 – 12:00 and 14:00 – 17:00) Fax: +49 7545 202264 e-mail: info@ipcopter.com 34/34...
