Koresound
user Manual
Version 0.1
july 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KoreSound and is the answer not in the manual?

Questions and answers

Related Manuals for K-Team KoreSound

Summary of Contents for K-Team KoreSound

  • Page 1 Koresound user Manual Version 0.1 july 2004...
  • Page 2 • All effort have been made to ensure the accuracy of the content of this manual. However, should any error be detected, please inform K-Team S.A. • The above notwithstanding K-Team can assume no responsibility for any error in this manual. K-Team S.A.

  • Page 3: Table Of Contents

    2.1 Overview ......2.2 KoreSound Connections .....

  • Page 4: Introduction

    1 Introduction The KoreSound board is a KoreBot extension that provides audio playback and recording capabilities. It offers one audio stereo output and two audio stereo inputs. This document presents how to use KoreSound. K-Team S.A.

  • Page 5: Koresound Hardware

    2 KoreSound Hardware Overview KoreSound can be used in application that requires sound playback and recording (such as MP3 player, speech synthesis and recognition). The hardware is quite simple and provides one audio output (OUT) and two audio inputs (IN1 and IN2).

  • Page 6: Korebot Connections

    The KoreBot connection is pretty straightforward, the boards should be simply stacked together. The KoreBot will provide the +3.3V power supply to KoreSound. Hardware Protection 2.3.1 Electrostatic Discharge Protection As any electronic device, the KoreSound may be damaged by Electrostatic Discharge. K-Team S.A.

  • Page 7: Koresound Software

    3 KoreSound Software Overview This chapter presents how to use KoreSound from a KoreBot using the Linux Operating System. It requires: • a KoreBot (with a KoreConnect or a KoreSDK) • a KoreSound • a terminal emulator software (such as minicom or HyperTerminal) •...

  • Page 8: Basic Commands

    This section shows how to access to the sound driver from your standard Linux application. The examples given are in standard C and use the stan- dard C library. It requires some knowledge about the file functions on Linux. K-Team S.A.

  • Page 9: Sound Devices

    /* read some samples from the wave file */ cnt = read( wav_fd , buf , sizeof(buf) ); if ( cnt == EOF ) break; /* write the samples into the sound device */ write( dsp_fd , buf , cnt ); K-Team S.A.

  • Page 10: Sound Device I/O Controls

    1 and selects the input 1 for recording. 3.4.2 Sound device I/O controls The I/O control are useful to read and to change the settings of the sound device. Only the sampling rate can be changed. Supported I/O control commands: K-Team S.A.

  • Page 11: Mixer Device I/O Controls

    The I/O control are useful read and changes the settings of the mixer device. The mixer device is only used for I/O control. It allows to obtain information about the channels and to change output volume level, bass level, treble level and inputs level. Supported I/O control commands: K-Team S.A.
  • Page 12 /* change the input 1 level to 80% */ level = 80; ioctl(mixer_fd , MIXER_WRITE( SOUND_MIXER_LINE1 ) , &level ); /* read the level of the input 1 */ ioctl(mixer_fd , MIXER_READ( SOUND_MIXER_LINE1 ) , &level ); printf("input 1 level %u\n" , level ); K-Team S.A.
  • Page 13 K-Team SA 1028 Préverenges Ch de Vuasset, CP 111 Switzerland...
