- Page 1 Version 1.0 SIGMA Summit SS6 Assembly instructions Long Fight-time Hexacopter Read the manual carefully before using SIGMA Summit SS6 461mm 170mm 69mm 920mm 273mm Weight of frame:800g 282mm STEP 1 6 sets complete SIGMA Summit SS6 User Manual Page 1...
- Page 2 STEP 2 M3 x 6 Socket Screw Back View IMU Mounting Plate STEP 3 12x Arm Mount Back View SIGMA Summit SS6 User Manual Page 2...
- Page 3 STEP 4 Battery Mounting Plate Install Power HUB GPS Mounting Plate Install XA Landing Gear XA Landing Gear System Completed SIGMA Summit SS6 User Manual Page 3...
- Page 4 Overview SIGMA Summit SS6 User Manual Page 4...
- Page 5 Version 1.0 SIGMA Summit SS6 Layout Refer Document Long Fight-time Hexacopter Read the manual carefully before using SIGMA Summit SS6 Install ESC Install the ESC cover Install the ESC to the back of motor mount A.K.E HighSPEED 30A High Voltage ESC...
- Page 6 Complete view Install Power HUB Back view Front view SIGMA Summit SS6 User Manual Page 6...
