User's manual
FinKey
Content
1 General instructions _____________________________________________________________ 2
2 Visual signals ___________________________________________________________________ 3
3 Reader unit/Remote control _______________________________________________________ 3
4 Self-test - before starting the system ________________________________________________ 3
5 Programming the fingerprint scanner _______________________________________________ 4
6 Operating of fingerprint scanner/lock ______________________________________________ 7
7 Setting operation mode __________________________________________________________ 8
8 Additional functions on the remote control __________________________________________ 9
© Carl Wittkopp GmbH - Errors and omissions excepted
User´s manual no. 9999-126-0
Advertisement
Related Manuals for Wittkopp FinKey
Summary of Contents for Wittkopp FinKey
-
Page 1: Table Of Contents
5 Programming the fingerprint scanner _______________________________________________ 4 6 Operating of fingerprint scanner/lock ______________________________________________ 7 7 Setting operation mode __________________________________________________________ 8 8 Additional functions on the remote control __________________________________________ 9 © Carl Wittkopp GmbH - Errors and omissions excepted User´s manual no. 9999-126-0... -
Page 2: General Instructions
FinKey 1 General instructions • Please read the operating instructions carefully, before activating the lock. 1.1 Liability notes • We don’t assume liability for malfunctions due to incorrect operation, use of force or inappropriate handling. In cases of damage to property or valuables, which are due to incorrect locking of the safe, we also don’t assume liability. -
Page 3: Visual Signals
Hold the remote control directly towards the blue LED of the reader unit. A functional key will be confirmed by flashing of the green LED. 1. FinKey is in delivery status. G R B 2. Press the button on the remote contol. -
Page 4: Programming The Fingerprint Scanner
5.1 Programming of master fingers - (Set 1 - 6/Set 9 - 14) The same finger or three different ones can be programmed as master finger. 1. FinKey is in delivery status. G R B ☼ 2. Pull the 1st master finger over the sensor. - Page 5 5.2.1 Programming of user fingers - (Set 1 - 2/Set 9 - 10) The master finger should not be the user finger. 1. FinKey is ready to operate. ☼☼ ☼ 2. Pull the master finger over the sensor.
- Page 6 The lock opens normally; simultaneously an alarm signal will be triggered. The alarm finger must not be a master- or user finger. 1. FinKey is ready to operate. ☼☼ ☼ 2. Pull the master finger over the sensor.
-
Page 7: Operating Of Fingerprint Scanner/Lock
6. Pull the master finger over the sensor for a third time. ☼☼ 7. Wait until the green and red LED flashes. ☼ 8. FinKey is back in delivery status after a few seconds. G R B • Reset can be done alternatively as described in 8.5. Rel. 1.4... -
Page 8: Setting Operation Mode
The opening time of the lock ist controlled by relay 1. The factory set value of the relay cicrcuit is 5 seconds. 1. FinKey is ready to operate. ☼☼ ☼ 2. Pull the master finger over the sensor. -
Page 9: Additional Functions On The Remote Control
The time delay of the „silent alarm“ is controlled by relay 2. The factory set value of the relay cicrcuit is 5 seconds. 1. FinKey is ready to operate. ☼☼ ☼ 2. Pull the master finger over the sensor. - Page 10 8.4 Overview users - (Set 1 - 6/Set 9 - 14) This function provides an overview of free or already occupied users. 1. FinKey is ready to operate. 2. Press the button on the remote contol. 3. Enter the user-ID that has to be checked.
- Page 11 FinKey User-ID Name Rel. 1.4...
- Page 12 FinKey User-ID Name Rel. 1.4...
