AV Stumpfl SC MASTER 6 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SC MASTER 6/16
AV Stumpfl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC MASTER 6 and is the answer not in the manual?

Questions and answers

Related Manuals for AV Stumpfl SC MASTER 6

Summary of Contents for AV Stumpfl SC MASTER 6

  • Page 1 SC MASTER 6/16 AV Stumpfl...

  • Page 3: Table Of Contents

    Contents Introduction Control centre and multi-channel MP3-Player .....1 The features ................2 Scope of supply ..............5 Optional accessory ............5 Address ................7 Documentation status .............7 Front and rear views Front view ................10 Rear View ................12 IR remote control unit ............13 Getting started General .................15 Cable connections and power supply ........15 Programming shows...
  • Page 4 Special features for programming ........ 23 Producing a show medium General ................25 Generating data for the SC MASTER 6/16 ....... 25 The FlashCard Dialog in Wings Platinum..... 27 Generating presentation data for the CF card....29 Specifying show properties .......... 34 Editing Remote properties of shows .........
  • Page 5 Cable Connections and Power Supply ......56 Address configuration ............57 Setting addresses in the Media Pool......57 Setting the addresses at the hardware ......58 Subadresses of the SC MASTER 6/16 ......61 Ensuring communication within the SC Net.......62 The Menu Layout of the Menu ............64 How to use the menu............66...
  • Page 6 Input ................83 Save Volume ..............84 Slider ................85 CUE OUT Signal............... 86 Priority ................86 Cue-Out................ 86 Continue Sign (Continue Signal) ........87 RS232 OUT ..............88 Driver................88 Timer................. 89 AutoTimer..............89 ShowNumber (Show Number) ........89 Timer Time ..............
  • Page 7 List of problems ...............105 Update of operating software Updating ................108 Technical Appendix ASCII Protocol ..............110 Connector configuration...........115 RS232-IN connector ...........115 RS232-OUT connector ..........116 SC NET connector ............117 CUE-OUT connector ...........118 LINE-OUT connectors..........118 REMOTE connector ............119 REMOTE Connector Open-Collector Outputs ....120 DATA IN / OUT connector...........121 POWER connector............122 Technical Data..............122...

  • Page 9: Introduction

    Introduction Control centre and multi-channel MP3-Player SC MASTER 6/16 series units are MP3 players featuring superordinate Show Control Management for controlling multimedia events. Within the SC Net network, such a unit forms the central control system with a variety of input and output options.

  • Page 10: The Features

    This manual is also available as PDF document. The latest version can be downloaded from our website. The features To give you a feeling for the extraordinary efficiency of the SC MASTER 6/16 we have listed the most important features below.
  • Page 11 • Professional, balanced stereo jack outputs to avoid inter- ferences. Allow direct connection of 8 headsets, using the corresponding cable adapters. Control • Control of external components via SC NET, DLC data signal or the integrated RS232 port. • Control of lighting and other devices via DMX512 signals. The first six channels are available via a special optional cable, control of up to 64 channels via the optional DMX Upgrade Module.
  • Page 12 Up to six set-up configurations can be saved and retrieved at any time. • The SC MASTER 6/16 operating software can be updated via a file and a Windows PC at any time. 4 • 0BIntroduction...

  • Page 13: Scope Of Supply

    Scope of supply The SC MASTER 6/16 includes the following: • IR remote control unit • Power Supply Unit AC-3 • User Manual and Wings Platinum CD ROM Optional accessory • Compact Flash cards (CF cards) with varying memory capacities of up to 2 GB.
  • Page 14 • DMX Upgrade Module for direct control of up to 64 DMX channels. • DMX512 extension cable for connection to REMOTE con- nector, SCK-MDMXE • External IR receiver for connection to the REMOTE connec- Important note on the disposal of the equipment Please do not dispose of your Stumpfl equip- ment in unsorted household waste.

  • Page 15: Address

    SC Master 6/16 operating software: 2.05 Wings Platinum Version: 3.50 This manual has been prepared with care and contains all information about the SC MASTER 6/16 available at the time of print. This documentation is also available as a PDF file, which, under certain circumstances, may be more up-to-date than the printed version.

  • Page 17: Front And Rear Views

    Front and rear views 1BFront and rear views • 9 SC Master 16...

  • Page 18: Front View

    IR receiving diode behind the display LCD display Keys for menu and show selection as well as volume control for the SC MASTER 6/16 ESC key for the menu and for aborting running shows (press for more than one second)
  • Page 19 10. CUE LED flashes while a control signal is being generated or when there is an error on the SC Net bus. 11. ON/OFF switch with control LED, is illuminated when ON 1BFront and rear views • 11 SC Master 16...

  • Page 20: Rear View

    RSRS232-IN connector for communication with a com- puter or external devices, connection to a serial LAN adapter, e.g. remote control of the SC MASTER 6/16. SC NET connector for linking up with a Show Control network.

  • Page 21: Ir Remote Control Unit

    IR remote control unit Cover of battery compartment, on the rear. Caution: Strictly observe the correct polarity indicated at the bottom of the battery compartment when inserting the batteries! 1BFront and rear views • 13 SC Master 16...
  • Page 22 Volume control preselection keys; for selection of stereo channels 1 to 4 or 5 to 8 IR transmitting diodes (range from 10 to 20 m) Volume and sound control for joint control of all channels Volume control CARD 1/5 to CARD 4/8 for four stereo channels, changeover via preselection switches CARD 1-4 and CARD 5-8 Skip...

  • Page 23: Getting Started

    Getting started General You may be burning to start testing your new SC MASTER 6/16. However, before you can start presenting your first show, you will have to take a few preparatory steps. Cable connections and power supply Connecting the system cables Connect the cables as displayed below.
  • Page 24 Switching on Press the main switch (POWER ON) to switch on the SC MASTER 6/16. The red LED above it lights up and the display shows several messages one after the other. After about 3 seconds the following display should appear:...
  • Page 25 Important: Strictly observe the correct polarity indicated at the bottom of the battery compartment when inserting the batteries! The SC MASTER 6/16 is now ready for operation. 2BGetting started • 17 SC Master 16...

  • Page 26: Programming Shows

    Wings Platinum in combination with the SC MASTER 6/16 may be worth while. The new Stumpfl system tools certainly open up new avenues for implementing a show. When Wings Platinum is used for...

  • Page 27: Connection To The Computer

    (Com 1...4) of your computer. You should use the supplied cable STK-C010 to avoid possible problems caused by ground loop and interfering voltage. 2. Now switch on the computer and the SC MASTER 6/16 unit. 3. Start Wings Platinum, load a project or create one. The device port "Stumpfl SC Net"...
  • Page 28 DLC port. When the DLC port is used for programming, the DLC data signal is generated at the CUE-OUT connector of the SC MASTER 6/16. Compared to the SC NET port, however, the DLC port only allows a restricted range of cues and much smaller ad- dress space.

  • Page 29: Programming With Wings Platinum

    Fehler! Textmarke nicht definiert. and activate the system. Creating a project Before SC MASTER 6/16 can play back sound, you need to create the corresponding project and copy it onto CF card. In addition to MP3 audio samples, it also requires a show file containing playback information for the samples and, most of the time, also information for the devices to be controlled.
  • Page 30 Wings Platinum when the device control system is enabled. Creating presentation data: Once you have completed your project and want to present it without PC you need to create presentation data for the SC MASTER 6/16. 22 • 3BProgramming shows...

  • Page 31: Special Features For Programming

    The help also contains example projects for classical show control applications. Special features for programming SC MASTER 6/16's innovative technology allows you to work and present in a completely different way - something you should consider during programming: •...
  • Page 32 external applications. (See page Fehler! Textmarke nicht definiert.). • You should also pay special attention to the topic "Special functions for the SC Master" in the Wings Platinum Online Help. There you will find additional information on variables, volume control, key masks or logical show management. 24 •...

  • Page 33: Producing A Show Medium

    MASTER 6/16. These are the control signals for the show on the one hand, and the compressed audio data on the other. Generating data for the SC MASTER 6/16 The presentation data for the CF card are generated and, first of all, stored on the hard disk. These are the control...
  • Page 34 If your project consists of several shows, you should fill in section "Automated output to flashcard" in the Timeline Properties dialog. This allows for a better overview over flashcard shows on tab Timeline on the one hand and en- ables you to generate the entire project data for storage on CF card at the push of a button.

  • Page 35: The Flashcard Dialog In Wings Platinum

    The FlashCard Dialog in Wings Platinum The presentation data for CF card are generated in Wings Platinum via the FlashCard dialog, which can be called up via the main menu "Output"/"FlashCard...". The FlashCard Dialog is the central tool for generating, trans- ferring and managing CF card presentation data.
  • Page 36 The centre field lists the shows contained in the highlighted card directory. The number in front of the show refers to its position on the CF card. The plus sign indicates that the re- quired data for the show are available. A question mark would indicate that the data are missing.

  • Page 37: Generating Presentation Data For The Cf Card

    Generating presentation data for the CF card During this process, the presentation data for a project are, first of all, created and then saved to the hard disk. Please note that an MP3 encoder must be available on the computer to be able to compress audio data in accordance with the MP3 compression format.
  • Page 38 special characters are allowed. Now click "Create single show". Select the required timeline under "Timeline and por- tion". The default setting "Timeline1" only needs to be changed when there are several timelines. Select the project portion for which presentation data are to be generated.
  • Page 39 • "Only selected portion of timeline" ..only the se- lected portion of the timeline will be considered. If no portion is highlighted this option cannot be selected. • Timecode Offset: Offset for the SMPTE timecode generated at the CUE output. The specified time value is added to the current show time.
  • Page 40 Now select a data rate. Usually, 128 kbits/s should be sufficient for CD quality. If you are not satisfied with the quality try to improve the result by choosing a higher data rate. Click "OK" and the presentation data will be generated. Please note the following: •...
  • Page 41 SC MASTER may not be updated and you might end up with problems running the shows. • You can transfer old and new shows together onto one CF card, if you specify the same directory for CF card data in both programs.

  • Page 42: Specifying Show Properties

    Specifying show properties You can assign certain control properties or audio functions to the shows, which are then evaluated by the SC MASTER 6/16 during show presentation. Open the dialog box by double- clicking the show name. The name can be altered in field "Name".

  • Page 43: Editing Remote Properties Of Shows

    Editing Remote properties of shows For Show Control applications, shows frequently need to be remotely controlled. The SC MASTER 6/16 allows you to start shows simultaneously or interactively from CF card by press- ing certain keys or via remote commands. This is defined in the CF card Remote Table.
  • Page 44 And this is how it is done: 1. In the main menu, click Output – FlashCard... and the FlashCard dialog will appear. 2. Double-click the corresponding FlashCard directory and the dialog box FlashCard Settings will appear. In column Remote Input you will find the 32 keys of an IR remote control unit, followed by an additional 200 remote inputs below in accordance with the definition in the Wings Plati- num SC Net options.
  • Page 45 3. Highlight the corresponding Remote input. 4. In column Show click on the entry field, enter the corre- sponding show number and press Enter. 5. In column Mode right-click the entry field and select the corresponding mode for the remote behavior of the show. The various modes have the following effects: •...

  • Page 46: Special Settings

    • Restart ...starts one show additionally, a running show is started again from the beginning, other shows con- tinue. 6. When using one of the inputs Remote 1 to 200 you can specify whether the show is to start when the switching contact opens or closes.

  • Page 47: Editing Remote Properties In Show.ini

    SHOW.INI is located in every CF card directory. Unless you have specified any other location, the show data for the SC MASTER 6/16 can be found in the default folder the location of which can be found in the Options Dialog: 4BProducing a show medium •...

  • Page 48: The Key Table

    Important: • Only edit sections "Key Table" and "Remote Table"; never any other sections. • Only edit contents of CF card directories via the FlashCard Dialog in Wings Platinum; never use Windows Explorer to copy files. The Key Table This section is located at the end of SHOW.INI and defines the properties for using an IR remote control unit.
  • Page 49 The Start Behavior of the addressed show can be defined as follows: Normal start. A show can only be started if no other show is running. The currently running show is not inter- rupted. Interrupt Start; every running show is terminated A running show is started again from the beginning, other shows continue.

  • Page 50: Data Transfer To Cf Card

    Data transfer to CF card After generating the presentation data for the SC MASTER 6/16, you can transfer them onto CF card. For copying onto CF card, the computer must be equipped with a CF card drive. Such drives are also available as external drives with USB connection.
  • Page 51 Click "OK". The data are then transferred onto the CF card. Please note the following: • If you transfer a card directory onto the CF card, the existing files on this CF card will be erased! • The situation is different for updating a show or for a directory which is already located on the CF card: In this case, only the modified or new files are transferred.

  • Page 52: Playback Of Shows

    Playback of shows Presentations - compact layout and comfort- able handling For playing back show or audio projects you need a CF card that contains the show data that have been prepared before- hand using Wings Platinum. In principle, the configuration is the same as for programming.
  • Page 53 Start up the system Insert the CF card into the SC MASTER 6/16 slot, unless this has been done beforehand. As a consequence, a message will appear on the SC MASTER 6/16 display saying that the card was detected. Starting the show: Start the show by pressing the corre- sponding number keys on the IR remote control unit.
  • Page 54 By pressing both CARD VOLUME keys ( ) of a channel simultaneously, the corresponding stereo pair is muted. On the display you can see an "M" instead of the level display. Press one CARD VOLUME key to cancel mut- ing of this stereo channel. Joint volume control of all channels is possible via the VOLUME keys.

  • Page 55: Extended Selection Of Shows

    Extended selection of shows Switch on the system and insert the CF card into the SC MASTER 6/16. To extend the options for show selection you have two alternatives: Show selection via the IR remote control unit Press the YES key: The display will show "Start Show:___".

  • Page 56: Ir Remote Control Range

    It is connected to the REMOTE connector of the SC MASTER 6/16. Show Start with Timer The SC MASTER 6/16 is equipped with a timer for time- controlled show playback. Parameter settings can be made in menu "Timer". Further...

  • Page 57: Time-Controlled Show Start Via The Scheduler

    Central European time. The DCF-77 Receiving Module is connected to the Remote connector of the SC MASTER 6/16. As an indication for a correctly received signal, the PC LED flashes briefly every second, but only if the PC connection has been established.

  • Page 58: Show Start Via Transponder

    Show start via transponder The transponder is an Identification Module containing unam- biguous code for contactless read-out via the corresponding Reading Module. These transponders are available as key rings, bank cards or watches. This unambiguous code allows one particular show on the CF card to be assigned to a transponder.
  • Page 59 SCZ-RFID-RCV to the RS232 OUT connector of the SC MASTER 6/16. • In the menu select "RS232 OUT" as "Driver" transponder. Switch off the SC MASTER 6/16 and on again for it to change over to Transponder mode. • Insert a CF card into the card slot.
  • Page 60 Fehler! Textmarke nicht definiert. in chapter "Fehler! Verweisquelle konnte nicht gefunden werden.". To allow the SC MASTER 6/16 to use the transponder file, option "Activate transponder" in the "FlashCard Settings" must be enabled. 52 • 5BPlayback of shows...

  • Page 61: Structure Of The Card Player

    Structure of the card player General SC MASTER 6/16, in one tiny little unit, offers highly sophisti- cated control and sound technology. The audio components it contains are a card player with up to 16 channels, correspond- ing to 8 stereo channels. Every stereo channel has separate volume and sound control.

  • Page 62: Playback Of Synchronized Multi-Channel Sound

    capacity of 512 MB, for example, more than 8 hours of stereo sound in a CD-like quality can be stored. This is equivalent to a data rate of 128 kbits/s. The playback quality, on the one hand, depends on the data compression: the higher the data rate, the better the sound.

  • Page 63: Volume And Sound Control

    practice this is negligible, however, sound channels with a critical phase relationship should possibly be saved in one stereo sample. Volume and sound control The Master Volume is controlled via the VOLUME keys and a separate hardware control unit, i.e. it is completely independ- ent of the stereo channels volume control.

  • Page 64: The Sc Net System

    The SC Net System General The SC Net System is a network consisting of an SC Master unit and one or several SC Net modules for controlling a variety of different devices. All SC Net modules are run via one single bi-directional network connection, which also serves as a power supply.

  • Page 65: Address Configuration

    the module connected to the power supply unit, but for all SC Net modules within the network. Usually, the power supply unit AC-3 can supply up to five SC Net modules. However, there are also some modules which require a separate power supply unit.

  • Page 66: Setting The Addresses At The Hardware

    Click tab Devices in the Media Pool . If the corresponding devices are not displayed, click on the plus sign in front of the device port. Right-click the corresponding control channel and select Properties. The Properties Dialog will appear. Under Address enter the new address and confirm with Menu item "Change SC Net addresses"...
  • Page 67 Connect the SC MASTER 6/16 with the SC Net modules and switch on the system. In the SC MASTER 6/16 menu go to "Options – SC-Net – IntNetAddress" and select INetAddrs = 1. In order to establish communication within the SC Net, switch on the SC MASTER 6/16 off and on again.
  • Page 68 are briefly displayed on the Master unit display. If this does not work for your units, you may have to update the operating software. 60 • 7BThe SC Net System...

  • Page 69: Subadresses Of The Sc Master 6/16

    Subadresses of the SC MASTER 6/16 The SC MASTER 6/16 features various interfaces which can be addressed as follows for SC Net operation: /2 (..for information on the output of Display messages refer to the Wings Platinum Online Help) /3 and up (up to 64 DMX channels,...

  • Page 70: Ensuring Communication Within The Sc Net

    Ensuring communication within the SC Net For an SC Net system to work reliably, the data rate needs to be set to an appropriate value. SC MASTER 6/16 automati- cally negotiates the baud rate with the modules, provided setting "Auto Baud" has been chosen in Menu "Options – SC Net –...
  • Page 71 SD Net baud rate manually until even the last module starts communicating within the network. If the cable length allows it, you can also set a baud rate that exceeds the predefined value. The maximal baud rate to be set is 460800. This is an appropriate value if a high amount of data is expected to be transferred on the CAN bus.

  • Page 72: The Menu

    This is why it has an ex- tensive menu for configuration purposes. Via this menu, the SC MASTER 6/16 is told what to do. In combination with the display and the keys , ESC and ENTER, the menu is the central input instrument.
  • Page 73 The vertical structure is divided into menu trees while the horizontal structure is divided into menu branches. Every menu branch starts with the main menu and ends with the entry menus. What can be seen on the display? Just imagine covering this structure with a sheet of paper with a rectangular window just as large as the menu name.

  • Page 74: How To Use The Menu

    How to use the menu The best way to comprehend the operating steps is to switch on your control unit and try out the following steps. Print or copy the menu chart and place it next to the unit - this will help you find the corresponding menu more easily.
  • Page 75 rows visible in the picture indicate that further menus can be found above and below. Main menu ..and sub menu arrows Entry menu symbols Let's briefly remember our sheet of paper and the window. Use keys to move the window up and down, i.e. in verti- cal direction along a menu tree.
  • Page 76 • "Timer" for setting the timer functions • "Info" provides information about the device version. If you want to move to a sub menu, simply press the ENTER key. The type of arrow will now change ( ) as an indication that you are in a sub menu and the direction of the arrows shows whether further menu items can be found above or below (...

  • Page 77: Menu Operation Via Ir Remote Control

    together with an ENTER symbol. By the way, this symbol signalizes that a confirmation is required before the corre- sponding menu item can be activated. By pressing the ENTER key you can exit the menu. Good. Now you know how to enter a menu, how to navigate through it and how to make settings.

  • Page 78: Menu Chart

    Menu Chart 70 • 8BThe Menu...
  • Page 79 8BThe Menu • 71 SC Master 16...
  • Page 80 72 • 8BThe Menu...

  • Page 81: The Menu Items

    The Menu Items Setting Load For loading or activating all previously saved configurations, i.e. complete menu settings. Via input menu "Load Setting 1...6" you can select one out of seven previously saved con- figurations. Save For saving complete menu settings. Entry menu "Save as Set 1...6"...
  • Page 82 ExtNetAddress SCNetBaudRate Auto Baud Display/MessageDelay Display/TimeDisplay Display/FastDisplay IR Receive Remote-Out AUX-Out Data In/Out Auto Select External Clock RS232InBaudRat Auto Baud MASTER/Volume Card_1 to Card_8 Volume Bass Treble Signal/Priorty Card Cue-Out Continue Signal Driver RS232 Auto Timer Show Number Timer Time 0000:05 74 •...

  • Page 83: Options

    Options Aux Address (Auxiliary Address) only for DLC mode This menu specifies the address position of a connected Open-Collector Module (AuxAddress= 1...16) in DLC mode. The Open Collector Module does not use the set address group, but the one following after. E.g. if AuxAddress a=1 is set, the first four addresses (A1 to D1) remain unconsidered and the Open-Collector Module starts switching from address A2 onwards.
  • Page 84 Use "IntNetAddress" to set the SC MASTER 6/16's own ad- dress within the SCNet for show control applications (INetAddrs=0...125). The master address is always 1; higher addresses mean that the unit is regarded as a module. A setting of 0 (default) disables SC Net operation.

  • Page 85: Display

    460.8 kBaud. The SC MASTER 6/16 will still start testing at a rate of 19200 Baud but it will increase the baud rate to 460.8 kBaud. With higher baud rate settings you need to bear in mind that faulty data transfer also requires a higher degree of SC Net bus verification activity, which in turn may distinctly reduce the data throughput.

  • Page 86: Ir Receive

    With Time Disp= ON the playing time of an MP3 samples is counted down to zero. Fast Display Usually, the SC MASTER 6/16 display shows the device designation and firmware version number immediately after switching it on. In total, this takes about 3 seconds. If the SC MASTER 6/16 is to be ready for operation (e.g.
  • Page 87 AUX-OC Out ...offers two open-collector switch outputs (SC Net addresses /70 and /71 or DLC address A1 and B1, re- spectively), which can be universally used with two additional relays. For a corresponding wiring of the REMOTE connector refer to page 119.

  • Page 88: Data In/Out

    This menu allows you to select the devices to be operated at the DATA IN/OUT connector. With a default setting of "Auto- Select", the SC Master 6/16 will only detect devices OC 16 out, OC analog, the Slider or a matrix keypad. Any other devices must be chosen manually.

  • Page 89: External Clock

    External Clock An SC Master 6/16 can be synced up with one or several SC VIDEO PLAYERS. SC MASTER 6/16 receives the time clock from the SC VIDEO PLAYER, i.e. it serves as a slave. This 9BThe Menu Items • 81...

  • Page 90: Rs232Inbaudrat (Baud Rate For Rs232-In)

    This menu allows fixed baud rate settings for the serial port RS 232-IN (1200 Bd ... 115.2 kBd). This setting is required if the SC MASTER 6/16 is run as part of a media control system, which uses a baud rate differing from 9600 Bd. When using...

  • Page 91: Sound

    Volume In this menu you can enter the master control volume for the SC MASTER 6/16 after switching on (MasterVol=0...31). Please note: 0 = -79 dB and 31 = 0 dB. Via the IR remote control you can adjust the volume, starting from the pre-set value.

  • Page 92: Save Volume

    -7 = -14 dB (10 kHz) and 7 = +14 dB (10 kHz). Save Volume Saves all current volume levels set via the IR remote control unit. When starting up SC MASTER 6/16 again, those very same volume settings take effect. 84 • 9BThe Menu Items...

  • Page 93: Slider

    Slider The EC Mixer is a remote control unit with keys and two slid- ers for connection to the REMOTE connector. Menus "Slider1" and "Slider2" are used for allocating the function to the corre- sponding slider. It allows comfortable volume control. Slider1 Slider2 Use menus Slider1 and Slider2 to allocate an audio source to...

  • Page 94: Cue Out Signal

    This menu is used for defining whether the control signal set in Wings Platinum and saved with the show or that specified in SC MASTER 6/16 menu is to be valid. Setting "Card" uses the set control signal for playing back (default setting). Setting "Menu", on the other hand, gives priority to the parameters...

  • Page 95: Continue Sign (Continue Signal)

    The control program of a show in progress is output at the CUE-IN connector as MateTrac data signal, but only to the extent it is supported by the MateTrac set of commands. Timecode-25FOut The individual time positions within a show are output at the CUE-IN connector as SMPTE timecode at 25 f/s.

  • Page 96: Rs232 Out

    RS232 OUT These menus are used for selecting drivers for controlling various devices via the RS 232 connector. Driver Below you will find the corresponding driver for your applica- tion: for serial control of special devices RS232 when transponders are to be used Transponder for reading chip cards (e.g.

  • Page 97: Timer

    Timer The SC MASTER 6/16 has a timer for periodic, time-controlled starting of shows from CF card. The following menus allow you to select the corresponding timer parameters. AutoTimer By activating the auto timer (Auto Timer= ON), SC MASTER 6/16 starts timer operation immediately after starting up. This may come in handy for fixed installations running over a period of several days.

  • Page 98: Info

    By pressing the NO key the numbers of the active field can be deleted. Info This menu contains information about the SC MASTER 6/16. Serial Number stands for the serial number of the device. This serial number is required for ordering audio or DMX upgrades, as the enable code depends on this serial number.
  • Page 99 Should the display be the same as in the beginning, you may have made a mistake in entering the number. Check by press- ing ENTER once again and correct the number if necessary. You have 30 tries before entry is blocked. After this it can only to be unblocked again by Stumpfl.

  • Page 100: Show Control

    The SC MASTER 6/16 offers an extensive range of Show Control functions, such as the capability to run up to 18 shows simultaneously from a CF card. The three (SC MASTER 6) or eight (SC MASTER 16) stereo audio channels can both be run in sync with or completely independently of each other.

  • Page 101: Sound Track Management On Cf Card

    Sound track management on CF card The MP3 tracks started in a show are regarded as separate tasks. Basically, they continue even after the show has fin- ished, thus allowing controlled transition from one track to another. Here is an example: some background music is running in a loop, when a visitor entering the room triggers the start of a new show.
  • Page 102 • New start of the show via the Restart Option. • Jump to another show either when a variable condition is fulfilled or via an Action command with the Option "Jump". • The show is terminated either when a particular variable condition is fulfilled or via an Action command with the Op- tion "End".

  • Page 103: Variables

    Variables Variables are internal memories that can take various values depending on their programming in Wings Platinum. These values form the basis for further decisions and logical opera- tions. Possible values range from 0 to 0xFFFF (hexadecimal) and 0 to 65535 (decimal). It is possible to assign certain values to the variables, to trans- fer the content of one variable to another, or to perform mathematical operations, such as incrementing, decrementing,...

  • Page 104: Eeprom Variables

    RAM Variables: • RAM variables are runtime variables. After powering up the SC MASTER 6/16 they are set to 0. • One exception is RAM variable 70, which is set to 1 for SC Net operation, once the SC Net connection has been es- tablished.

  • Page 105: Monitoring Of Variables During Programming

    • This type of variable can be used for logical operations with frequently changing variable contents. Monitoring of variables during programming Wings Platinum allows monitoring of variables, thus enabling you to keep an overview of the variables and their individual values.
  • Page 106 3. Click arrow button and select the corre- sponding variable in the dialog. Any changes in the value of a variable in the SC MASTER 6/16 that come up during programming will be displayed on the Control Panel. 98 • 10BShow Control...

  • Page 107: Remote Input And Key Mask

    Remote Input and Key Mask The SC Master 6/16 can be remotely controlled via four differ- ent input ports: 1. IR remote control unit or IR signal, respectively. More about this can be found in chapter „Fehler! Verweisquelle konnte nicht gefunden werden.“ on page Fehler! Textmarke nicht definiert..

  • Page 108: Key Mask

    • OpenCollector40-Remote for 8 contacts in parallel mode (simultaneous key presses are recognized). In the Remote table these inputs correspond to the first 8 Remote entries. The open-collector outputs are ad- dressed by registering an SC Net "OpenCollector 16out" module at SC Net address 2 with 40 channels. 4.
  • Page 109 above inputs 1,3 and 4 are activated. All other inputs are locked. • Key Mask Set → activates or deactivates all 16 inputs simultaneously (1= activated, 0= deactivated). • Key Mask Or → Value 1 activates additional inputs, value 0 leaves the inputs unchanged. •...

  • Page 110: Text In Display Or Via Rs232

    Text in display or via RS232 The SC MASTER 6/16 display can show any text. This may be useful if you want to display control information during the show. However, it is also possible to display variable contents. The information to be displayed can also be transmitted via one of the two serial ports of the SC MASTER 6/16.
  • Page 111 • 250 is the period in 1/10 seconds for which the text is displayed. 250 = 2.5 seconds. • 255 means that the text is displayed permanently. • 0: The text is transmitted via the serial port RS232OUT (1/90). • 1: The text is transmitted via the serial port RS232IN (1/91).

  • Page 112: Trouble Shooting

    Trouble shooting Finding faults The SC MASTER 6/16 may only be one of a variety of differ- ent components within your installation. Any possible errors may, therefore, also be caused by other devices - which doesn't make troubleshooting any easier. In such a case it can be an advantage to understand what is happening.

  • Page 113: List Of Problems

    SC MASTER 6/16 off and on again with the CF card remaining in the slot. When starting up it is easier for the SC MASTER 6/16 to detect the CF card. When copying presentation data onto CF card the follow- ing message appears in Wings Platinum: "Not enough...
  • Page 114 CF card is formatted to FAT32 or NTFS file system. Solu- tion: Format the CF card to FAT16 file system. In the Win- dows Explorer, right-click the CF card, followed by Format... Select file system FAT and format the CF card. Then copy the presentation data once again onto CF card.
  • Page 115 gram) onto CF card. Recreate all presentation data for the SC MASTER 6/16 and transfer them to CF card. Sound track is not in sync with the device or the show time is in "slow motion". You may have chosen "External clock“ (Menu Options -> External Clock) without an SC VIDEO PLAYER being con- nected or the sync-clock cable may be defective.

  • Page 116: Update Of Operating Software

    Update of operating soft- ware Updating As the SC MASTER 6/16 includes a processor with operating software you can very simply keep your control unit up-to-date by loading new software. Download an Update File from the Internet. It is available at www.AVstumpfl.com under "Download"...
  • Page 117 SC MASTER 6/16 will boot automatically and be ready for use again after that. Important note: • While updating, SC MASTER 6/16 must by no means be switched off nor the connection to the computer be broken! •...

  • Page 118: Technical Appendix

    The maximum time interval between two characters must not exceed 20 ms, otherwise the command is ignored. Note: If you want to control the SC MASTER 6/16 via Wings Platinum or the SC TouchControl you can use a driver, which does not require any protocol knowledge.
  • Page 119 List of functions Function ASCII code Normal show start. A new is only started when no aSNx# other show is running. Currently running shows are not interrupted. x = show number from 1 to 200. Terminate show start. Only shows different from x aSTx# are interrupted.
  • Page 120 Adjusts Master Treble to the value specified by x. aT:x# x = 0 to 14. 0 = -7dB, 7 = 0dB, 14 = +7dB Card Volume up (all channels) aC+# Card Volume down (all channels) aC- # Card Volume up for channel y, aCy+# y = channel number from 1 to 8.
  • Page 121 PAUSE function. Corresponds to the PAUSE key on the remote control unit PAUSE show x. Only the specified show is put in aPx# Pause Mode. x = show number from 1 to 200. PAUSE END Show x Pause Mode is only canceled aPEx# for the specified show.
  • Page 122 Fades output channel c in SC Net module m to aNm.c<x.t# value x at the time specified in t. m = 1 to 125. c = 1 to 512. x = 0 to 255. t = 0 to 999. Time value in steps of 0.1 seconds. 999 corresponds to 99.9 seconds.

  • Page 123: Connector Configuration

    Connector configuration RS232-IN connector N.C. N.C. = not connected N.C. GND RS232 N.C. N.C. N.C. +5V to pin 5 Shield = Internal GND SC Net subaddress: /91 13BTechnical Appendix • 115 SC Master 16...

  • Page 124: Rs232-Out Connector

    RS232-OUT connector N.C. N.C. = not connected N.C. GND RS232 N.C. +5V to pin 5 Shield = GND internal SC Net subaddress: /90 116 • 13BTechnical Appendix...

  • Page 125: Sc Net Connector

    SC NET connector CAN - GND CAN - VDD (+5V, max 50mA) CAN-H CAN-L N.C. N.C. 13BTechnical Appendix • 117 SC Master 16...

  • Page 126: Cue-Out Connector

    With a 0 dB signal (sine wave) generated by Wings Platinum and converted into an MP3 file, SC MASTER 6/16 generates a 4.1 V peak-peak output level (equal to 2.9 V RMS). All internal settings of the SC MASTER 6/16 are adjusted to Card Volume 29 and Master Volume 31.

  • Page 127: Remote Connector

    REMOTE connector Start show 2 Start show 1 + 15 VDC up to + 25 VDC (unstable) output Analog input 1 (max. 0-5VDC) +5V DC regulated output (max. 20 mA) GND internal Toggle input Open-collector output (IR-Out 2, DMX-Out) Analog input 2 (max. 0-5VDC) 10.

  • Page 128: Remote Connector Open-Collector Outputs

    REMOTE Connector Open-Collector Outputs The REMOTE connector switch outputs have the fixed SC Net subaddresses /70 and /71. The maximum load to be applied is 100 mA and they always require a free wheel diode. In order to switch higher power and voltages, external relays can be operated in accordance with the following schematic diagram: Important: This adaptation requires qualified experts! We cannot assume any liability whatsoever for any damage...

  • Page 129: Data In / Out Connector

    DATA IN / OUT connector Data In 1 N.C. = not connected Data In 2 Data In 3 Data In 4 Data In/Out 1 Data In/Out 2 Data In/Out 3 Data In/Out 4 +5VDC (max 20mA) Shield = GND internal 13BTechnical Appendix •...

  • Page 130: Power Connector

    Maximum input voltage 15V AC or 24 V DC! Power Supply unit AC-3 (2x15V/500mA) must be used! Other Stumpfl power supplies do not have enough power handling capacity! Technical Data SC MASTER 6/16 Dimensions (H/W/D): 45 x 212 x 170mm Weight: 1080g...

  • Page 131: Glossary

    Digital Audio Tape - cassette recorder for digital storage of audio signals in CD quality. Dynamic Link Code - modern control signal standard, intro- duced by AV Stumpfl in 1994. DMX512 Protocol for serial control of up to 512 devices. Mainly used in the field of stage technology.
  • Page 132 Cascading Connecting devices in series. With the SC MASTER 6/16 this is done via the SC Net control signal line or by means of serial connections via RS232 in combination with the SC VIDEO PLAYER. MateTrac Widely used control signal standard of Arion, USA. AV Stumpfl has been using this control signal since 1983.
  • Page 133 zation with music as well as for controlling speaker support sequences. 14BGlossary • 125 SC Master 16...

  • Page 134: Index

    Index Abmessungen 126 Adressen – SC Net Sub-Adressen 63 Adressen konfigurieren 59 Anschlussbuchsen Beschaltung 118 Geräteansicht 12 Anschrift von AV Stumpfl 7 ASCII-Protokoll 113 Autostart 35 AuxAdrs (Auxiliary-Adresse) 77 AUX-Out 81 Bass 86 Batterien einlegen 17 Baudrate für RS 232 IN 84...
  • Page 135 Cue-Out 88 CUE-OUT-Buchse 122 DALI-Out 81 DATA IN / OUT-Buchse 125 DataIO (Data In/Out) 82 Daten für SC MASTER erstellen 26 Datenübertragung auf die CF-Card 43 DCF-77 51 Display 79 DLC-Steuersignal 88 DMX-Out 81 EC Mixer 87 Entsorgung des Gerätes 6 ExtAdrs (Externe SCNet-Adressen) 78 ExtClk (External Clock) 83 Features 2...
  • Page 136 Inbetriebnahme 16 IR-Empfang deaktivieren 80 IR-Fernbedienung 14 IRRecve (IR-Receive) 80 Kabelverbindungen 16 Kabelverbindungen im SC Net 58 Klangeinstellung 86 Kommunikation im SC Net sicherstellen 64 Lautstärke per Masterregler 85 LINE-OUT-Buchsen 122 MateTrac 89 Mehrkanalton 84 Memory 39 Menü Aufbau 66 Bedienung 68 Menüpunkte 75 MP3-Cardplayer 55...
  • Page 137 Open Collector-Schaltausgänge 81 Open-Collector-Modul 77 Options 77 POWER-Buchse 126 Präsentationsdaten 26 Priorty (Priority) 88 Programmieren 19 Reichweite der IR-Fernbedienung 50 Remote Extension 82 REMOTE-Buchse 123 Remote-Eigenschaften von Shows 36 RMT-Out (Remote-Out) 81 RS232-IN-Buchse 118 RS232-OUT-Buchse 120 RS232-Protokoll 113 RSOut 90 Rückseite 12 SaveVol (Save Volume) 86 SC Net Sub-Adressen 63...
  • Page 138 Setting 75 SHOW.INI verändern 41 Show-Eigenschaften festlegen 35 Shows starten -erweiterte Anwahl 49 Show-Start mit Scheduler 51 Signal 88 Slider 87 SMPTE-Timecode 89 Startverhalten 42 Stromversorgung 16 TimeDsp (Time Display) 80 Timer 50 Transponder 52 Treble 86 Ü Über die IR-Fernbedienung 49 Update der Firmware 110 Upgrade der Geräteausstattung 92 Volume 86...
  • Page 139 Zeit gesteuerter Show-Start 91 15BIndex • 131 SC Master 16...
