Welcome to use Soft LED Display system, in order to use this product with
security, reliability and convenience, please read the instruction carefully and
comply the guide before using this product.
. Safe Caution
1. After receiving the new Soft LED Display, please open the packing case to check the
goods and all other accessories whether they are consistent with packing list, in case
finding something broken, please contact the reseller or distributor to repair or change.
2. The connection, installation and operation of Soft LED display should be processed as per
instruction by special person.
3. Soft LED display should be far from the place of flammability, explode and heating.
4. Soft LED display should be installed in the place of well ventilation.
5. Soft LED display should be installed far from the children's reach.
6. Never try to trample and tear the Soft LED display, keep the internal cable connection and
electronic in order.
7. Keep the hard or sharp article from lacerating the product.
8. Prohibit sinking into the pouring water or other liquid.
9. Handle with care when install and disassembly the Soft LED display to avoid the damage
of the connecting wire and other electronic component.
10. The power cable should be connected to the power supply with ground.
11. Prohibit connecting the power when soft LED display was folded.
12. Before finishing the installation, please do not connect the power.
13. Must cut off all power before replace and maintainence the power adapter.
14. Not to take off the protecting clothing at the back of the display.
15. When there is wind, the display should be fixed firmly with safe belt.
16.
When folding the Soft LED display the surface of the curtai should be face to
17. Please comply with the local relative regulations.
. Characteristic
1. SMD RGB 3-in-1LED, small, bright and colorful, can display clear and smooth image
2. Soft and flexible, can be folded and curved, suitable for many shape application;
3. Against fire, water, dirt;
4. Small volume and light weight easy installation and transportation.
5. Multipurpose function, suitable for various situation.
6. Easy connection and combination.
7. elegant shape;.
User Manual
face.
1
Advertisement
Table of Contents
Summary of Contents for Huasun FLC-2500
-
Page 1: User Manual
User Manual Welcome to use Soft LED Display system, in order to use this product with security, reliability and convenience, please read the instruction carefully and comply the guide before using this product. . Safe Caution 1. After receiving the new Soft LED Display, please open the packing case to check the goods and all other accessories whether they are consistent with packing list, in case finding something broken, please contact the reseller or distributor to repair or change. -
Page 2: Technical Data
. Technical Data Model FLC-2500 Voltage AC 90~260V 50~60Hz/ DC 5V Max .Power 65 W/m² Max Pixel density 2500dots/sq.m Pitch 20mm Pixel SMD RGB 3-in-1 LED, 100000hrs life LED wave length: Red 625±5 nm, Green 520±5 nm, Blue 470±5 nm... -
Page 3: Installation
Rear The rear protection clothing and main body of the soft LED display is connected by magic sticker. . Soft LED display Installation and Disassembly 1. Installation Please follow the below drawing to install the Soft LED display: 1) After receiving the new Soft LED display, take out to check whether the Soft LED display is damaged, whether all accessories is all all ready. - Page 4 How to combine several piece of soft LED display There are bracket around every soft LED display, after adjusting the distance between two curtain, fasten the bracket by screw.
- Page 5 How to adjust the distance ( up and down ) between two Soft LED display: In the middle of every hanging belt, there is a adjustor for adjusting the length of the hanging belt, with which the distance between the upper curtain and the below curtain can be adjusted.
- Page 6 AC 90V ~260V 50~60Hz, which must be contacted with ground to ensure the safty of the whole system. To connect the signal cable Connect the signal wire between Soft LED display and Receiver There are signal wire with 15pin plug at one side of the Soft LED display, from up to down,connect them with the signal cable on the receiver one by one ( signed with serial number as 1 2 3 4 5 6 7 8), then lock the nut on the plug.
-
Page 7: Setup And Operation
Breaking the button; Breaking Soft LED Display; Falling off the LED Display cause other unsafe affair. 3. Disassembly Cut off all power cable and signal cable. Unbutton the button between Soft LED Display. Release all hanging belt and hook. Take off the Soft LED display from the truss and pull out the supporting stick Fold the display and put into the case. - Page 8 All the hardware setups are through the software—LED Studio. 1) Enter setup dialog box Open LED Studio software, Click the “software setup”, as shown in below figure; shown in below figure; And then will appear a dialog box, as As soon as the above dialogue box appears, input “linsn”, then password “168”. (Computer screen shows nothing when inputting “linsn”...
- Page 9 2) Sender setup Display mode: if PC works under the 1024*768 resolution, nothing changes; otherwise choose the right resolution of PC, then click “Save on sender”. (Remarks:1024*768 resolution is recommended) m suddenly without any reason, Default: when the LED display brightness di click Default and Save on sender will solve the dim problem.
- Page 10 Save on receiver: Click this item can save data in receiving card permanently. If not, the data lost when power is down. Intelligent setups are shown below: Click the “intelligent setup” Next Next:...
- Page 11 Next: Next: Next:...
- Page 12 Next: Next Next...
- Page 13 Next: Chose send to receiver Next:...
-
Page 14: Set Up Finished
Chose save on receiver Set up finished. . Software This system can play many kinds of file by LED studio, you can also play video file by other software, for example, resolume 2.41. Software operation confer LED STUDIO USER’S MANUAL LED Control System Manual . - Page 15 connected. 2. The data processor at the Check whether the signal wire between back of the soft LED display controller and PCB is well connected input or output no signal. 3. The connector of the signal Check the connector, fasten the locknut wire between Soft LED again, make sure the connector touch display and the receiver is...
- Page 16 It will come across following situation if the power adapter is broken or the connector doesn’t touch together completely. 1) The LED in back area in horizonal (dashed area) will not work from the broken one. 2) All LED in dashed area will not work from the broken one.
- Page 17 When coming across the above situation, deal with them according to following steps, Turn off the power for the Soft LED display. Remove the rear protection cloth. Check every connector whether it is fastened from unworking area, after fastenning every connector again, turn on the power for testing. Still without recovering, use multimeter to test whether the AC and DC output voltage is steady, if without output voltage or unsteady, replace the power adapter.
- Page 18 When coming across following situation, please check the LED, maintain and replace the LED: 1) some single pixel unwork or the color is out of the way, replace this LED. Move away the back plastic cover with screwdriver, take out the PCB board with LED, replace the bad LED with soldering iron, then fasten the back cover with screw.
- Page 19 4) To maintain LED as per the following steps The end.
