Fisher SMZ-140-N2GG Instruction Manual

Smz series

Advertisement

Quick Links

Instruction Manual
SMZ Series
Copyright © 02/02
Motic Microscopes, European Division.

Advertisement

loading

Summary of Contents for Fisher SMZ-140-N2GG

  • Page 1 Instruction Manual SMZ Series Copyright © 02/02 Motic Microscopes, European Division.
  • Page 2 8. Incident light 21. Column adjustment screw 22. Incident 9. On/Off switch illumination switch (I) 10. Slide stage clips 23. Transmitted illumination 11. Stage switch (T) 12. Stage plate locking screw 24. Light intensity 13. Base control SMZ-140-N2GG...
  • Page 3 Terminology used to describe components and controls can be found in the diagram on page 2. These instructions are based on the assembly and use of the SMZ-140-N2GG model with additional notes applying specifically for the other models in the series.
  • Page 4 Assembly All the steps described for the assembly of the stereomicroscope must be undertaken with extreme care, and without forcing the placement of the distinct parts and elements of the stereomicroscope. A. Place the base of the microscope (13) upright on a flat, Focus stable and clean surface.
  • Page 5 3. Press the principal switch (9) to an ON position “I”. 4. Press the incident illumination (22) or transmitted illumination (23) or both at the same time “I” or “II”, according to your needs in observing the sample. 5. Light intensity should be adjusted according to the objective used, or the type of sample observed.
  • Page 6 For differences in eyesight: 1. Using only the right eye, look through the right eyepiece (1) and adjust focus. 2. Next, using the left eye, look through the eyepiece and adjust the focus by turning the diopter adjuster (2) located on the left-hand tube (3) until the image appears sharp. Do not use the focus knobs to adjust focus (18).
  • Page 7 To adapt a video camera an adapter tube is needed. This adapter tube includes 0.5X lenses that correct the parfocality of images, from both binocular and vertical ports, shown on the TV monitor. This is providing that parfocality has been correctly adjusted according to the steps followed in point “D.
  • Page 8 B. Electrical maintenance. 1. Changing the bulb. • Changing the transmitted illumination bulb. a. Rest the stereomicroscope on its side being extremely careful, especially with the eyepiece (1) and the stage (11). b. Unscrew the 4 screws indicated (Fig. 3) and open the cap on the base.
  • Page 9 C. Mechanical maintenance 1. Adjusting the tension of the focus. Tension comes pre-adjusted by the factory. The best point of tension is that which permits the focus knobs to move as loosely as possible, without the head sliding down with its own weight.
  • Page 10: Troubleshooting

    Troubleshooting: ELECTRICAL PROBLEMS PROBLEM CAUSE SOLUTION The bulb does not work. Outlet inoperative. Have it repaired by a qualified specialised technician. Cable not connected. Connect the cable to the power source. Bulb burned out. Replace bulb. Fuse blown. Replace fuse. Wrong Bulb.
  • Page 11 Moving the microscope • If possible, avoid moving the stereomicroscope. • Carry the stereomicroscope in both hands. One hand should hold the stereomicroscope column (21), and the other should support it under the base (13). • Maintain the stereomicroscope in a vertical position. Repair If the stereomicroscope needs repairing, or revision by authorised personnel, we would recommend that it be stored in its polystyrene box and returned to the distributor.
