Be Next-iHome Panic Watch EU Quick Start Manual

Technical specs
Normal operating voltage
Frequency range
Wireless Range
Basic operations
- The Panic Watch can trigger any rule or lifestyle.
- The Panic Watch can be configured to your needs.
- The Panic Watch is easy to install and configured.
- Indoor use only.
- Water resistant
- Big red button with time configurable activation time
ow it operates
H
After a successful inclusion the Panic Watch can be used.
When pressing a button the led will blink to notice the customer of successful alarm message is sent.
With a controller you can make all different kind of rules and lifestyle changes.
It also possible sent the alarm directly to a Z-Wave based alarm device.
Use
1. Before use, the Panic Watch should be included into a Z-Wave network and associated.
2. You can Test you Panic Watch by pressing the button for 1sec untill the led is turned on. (press time is
configurable)
3. Don't forget to update and syncronize your rules in the Internet Gateway.
Include or Exclude in Z-Wave network
1. Press and hold the SOS Push Button until the indicator light starts blinking then release the button to
start the inclusion or exclusion process.
(Note: Normally button should be pressed for 2 seconds but in case the product is already included it
can take up to 12 seconds before the indicator light will start blinking.)
2. When classic inclusion failed, the product will start Network Wide Inclusion automatically.
Force Wakeup Notification
1. When included press and hold the SOS Push Button for approx. 4 seconds.
1
Make sure your Z-Wave controller is in the correct operation mode (include or exclude).
Version 0.2
Quick start: Panic Watch EU
1x CR2032 3V battery
868.42 MHz
Min 150 meters in a mesh network
1
31 July 2013 www.iHome.eu
