Windows Embedded CE 6.0 will be pre-installed when it leaves the factory. Figure 1 Product photo 1.2 Architecture Diagram Figure 2 is the architecture map for K7 and peripheral equipment of this board is also shown.
3 Hardware Specification 3.1 Power Input Function: to provide 5V voltage and 2A current for K7 Description of interface: please see table 3-1. Signal Function Power supply (+5V) 2A (Type) Table 3-1 Power Input interface 3.2 USB_DEVICE Function: K7 上的 USB_DEVICE interface...
Description of interface: please see table 3-4 Signal Function Right Right output Left Left output Table 3-4 Audio_Out interface 3.5 TV_OUT Function: A standard TV_Out interface. Description of interface: please see table 3-5 Signal Function TV_OUT TV analog output Composite Table 3-5 TV_OUT interface 3.6 Micro_SD Function: A standard Micro_SD interface...
3.7 SIM_CARD Function: A standard Sim_Card interface Description of interface: please see table 3-7 Signal Function UIM power UIM reset UIM Vpp UIM clock UIM data intput/output DATA0 MCMD CD_DT GND1 Table 3-7 SIM_CARD interface 3.8 Mini PCI_E Function: A standard mini PCI_E interface Description of interface: please see table 3-8 Signal Function...
RESERVED11 1.5V_3 RESERVED12 GND12 RESERVED13 3.3V_2 3.3V power Table3-8 mini PCI_E 3.9 KEY_PAD Function: A standard Key_Pad interface Description of interface: please see table 3-9 Signal Function VDD33 3.3V power SATA1 SATA1 VDD18 1.8V power KPD_C0 Keypad atrix column 0 output KPD_R0 Keypad matrix row 0 intput HALL_RIGHT...
Table3-10 UART debug interface 3.11 TFT_LCD Function: TFT_LCD interface Description of interface: please see table 3-11 Signal Function Select up or down scanning direction Select left or right scanning direction GND7 DCLK Sample clock GND6 Red data input(LSB) Red data intput Red data input GND5 Red data input...
Blue data input(MSB) GND0 Horizontal Sync Signal intput Vertical Sync Signal intput Data Enable MODE DE or HV mode control VCC2 3.3V Power voltage for digital circuit VCC1 3.3V Power voltage for digital circuit GNDLED2 Ground for LED circuit GNDLED1 Ground for LED circuit Adjust the led brightness with PWM Pulse VLED2...
Maintenance Service Maintenance service clause: The period of warranty for K7 MID (except LCD) is 90 days effective from sale. The warranty is invalid if you did not purchase through an authorized distributor and can't provide the original bill as proof of purchase, you had opened the MID case and the warranty label has been removed or damaged or altered.
Page 15
