FT5X User Guide

Installation And User Manual

1.1 Product Features

•

Supports dual-mode voice access (Mobile network GSM and Telecom PSTN).

•

GSM Fax function

•

GSM data function

•

Supports traditional PBX access

•

Dynamic echo cancellations to ensure the perfect voice quality

•

Off-power bypass functions (when power is off, system switches to PSTN network

automatically)

•

Modem mode (Access the Internet by GPRS through the PC serial port)

•

Supports the phone book stored in the SIM card or in the terminal

•

Intelligent routing (Able to set up dialling regulation to route voice or fax intelligently)

•

Setup by Keyboard prompt line for convenient operation.

•

Incoming caller display function

•

Auto-dialing function

•

Internal calling divert function

•

Real time displaying of wireless network signal power

•

Support POS connection (depend on the networks)

•

Software upgrade

www.microdata.fi

FT5X

OVERVIEW

support@microdata.fi

1/31

Table of Contents

Need help?

Do you have a question about the FT5X and is the answer not in the manual?

Questions and answers

Summary of Contents for Star-net FT5X

Page 1 FT5X User Guide www.microdata.fi support@microdata.fi FT5X Installation And User Manual OVERVIEW 1.1 Product Features • Supports dual-mode voice access (Mobile network GSM and Telecom PSTN). • GSM Fax function • GSM data function • Supports traditional PBX access • Dynamic echo cancellations to ensure the perfect voice quality •...
Page 2 FT5X User Guide www.microdata.fi support@microdata.fi 1.2 Technical Specification Frequency Bands • EGSM 900,GSM1800MHz Transmission Power EGSM 900 Class4 (2W Peak) • GSM 1800 Class1 (1W Peak) • Frequency Range EGSM 900 890~915 MHz 935~960 MHz • GSM 1800 1710~1785 MHz 1805~1880 MHz •...
Page 3: Battery Operation
FT5X User Guide www.microdata.fi support@microdata.fi or any other places with hazard of explosion (such as gas leakage site). 4、 Please avoid using this product on any metal surface that might weaken power of received signal 5、 Please avoid using PSTN network during thunderstorm, or it might cause remote electric shock.
Page 4: Installation Instruction
FT5X User Guide www.microdata.fi support@microdata.fi INSTALLATION INSTRUCTION 2.1 Interface Description FT5X Back plane FT5X Back plane interface description: ……… Antenna port DC 12V………Power supply ON/OFF……… Power switch IOIO ………… RS232 Serial Port PHONE ………Phone port, connect to the regular phone FAX……………...
Page 5 FT5X User Guide www.microdata.fi support@microdata.fi 2、 Network：Network indicator；two color indicator； 1） Green Slow Flash：searching network； 2） Green Fast Flash：voice SMS(but don’t support voice mail)； 3） Green：Connect to network，strong signal； 4） Red：connect to network，weak signal； 5） Dark：network registration failed 3、 Inuse：phone/fax/data indicator；two color indicator；...
Page 6: Hardware Installation Steps
Connect a regular telephone into the socket marked ‘Phone’ indicated on FT5X back plane. 3、 Connect a G3 Fax machine into the socket marked ‘Fax’ indicated on FT5X back plane. Caution: Do NOT plug external line into Telephone socket, or it may cause device damage.
Page 7 Voice mode application 3.2 Voice/FAX mode application FT5X connects regular telephone, FAX, Modem via phone and fax ports. The PSTN port connects with entry line. The Ethernet port connects with Ethernet that make the device become one wireless modem. In normal situation, user can call in and call out while telephone routes GSM network.
Page 8 FT5X User Guide Switched data) uplink. According to this communication plan, people do not need any change when using the traditional POS, and allocate numbers remain the same. Application plane is show as bellow: Pos connection application 3.4 PBX relay mode application the phone port connects with PBX exterior interface (TRUNK port), the exterior line port connects with the entry line.
Page 9 FT5X User Guide wireless relay line separately, this mode is a best choice. The device’s external line socket connects with PBX internal interface (EXT ports). The external line socket connects with the internal interface (EXT ports) or any extension. The PBX extension can call the extension number of access terminal and then realize the voice call in and call out through the access terminal that access the GSM/GPRS.
Page 10 FT5X User Guide 4. Operating Instruction 4.1 Telephone Function 4.1.1 Making a phone call 1. Off-hook：Pick up the handset; you will hear a dialing tone. 2. Dial：Dial the phone number, the system will send out your dialed number automatically. 3. Conversation：When recipient picks up handset at the other end, voice communication is established.
Page 11 4.2.2 Receiving a fax User can receive a fax by attaching a regular G3 Analogue fax machine to the Fax port on the back panel of the FT5X unit. The device supports two fax receiving mode: synchronous mode and asynchronous mode.
Page 12 4.3 Data Function 4.3.1 POS function When the traditional POS connected to the FT5X, through the RJ11 ports (phone port and fax port) you should make sure the number the traditional POS dialed out is data number.
Page 13 FT5X User Guide To set up your PC to connect to the FT5X unit via the serial port follow the following instructions: 13/31...
Page 14 FT5X User Guide 4.3.2.1 Installing the Modem From the Start Menu, click Control Panel Note: If the screen displayed differs to that shown here click Switch to Classic View Double click Phone and Modem Options Select the Modems Tab Click Add…...
Page 15 FT5X User Guide Select Don’t detect my modem, I will select it from a list Click Next Ensure that Standard Modem Types is selected on the left and click on Standard 33600 bps Modem on the right Click Next 15/31...
Page 16 FT5X User Guide Select the serial port that the FT5X is attached to and click Next Click Finish 16/31...
Page 17 FT5X User Guide Click OK The FT5X is now installed as a modem on your PC. If you wish to use GPRS refer to section 4.3.2.4 for instructions on setting up for GPRS. 17/31...
Page 18 FT5X User Guide 4.3.2.2 Connecting to the Internet It is assumed that an Internet account has already been set up with a service provider. You will have been given: • Telephone number for the dial-up connection • Username and Password...
Page 19 FT5X User Guide Click Dial-up connection and click Next Click Next Enter a name for the connection and click Next Enter the phone number for your internet provider and click Next Click Finish 19/31...
Page 20: Disconnecting From The Internet
When on-line there is a computer icon in the bottom right corner of the screen that flashes whenever data is being transferred. To terminate the connection, right click on this icon and click on Disconnect. The FT5X will then go off line and return to voice mode after a few seconds.
Page 21 The following are additional steps that need to be carried out in order to use the FT5X unit with GPRS. To connect to the internet via GPRS the FT5X requires a GPRS enabled SIM Card and the following information must be provided by the Network Operator: Access Point Name (APN) •...
Page 22: Configure Connection
FT5X User Guide Under Extra initialisation commands enter the following text exactly as it appears here: AT+CGDCONT=1,”IP”,”APN” Where APN is the access point name provided by the Network operator. Click OK to confirm the settings Click OK to exit the Phone and Modem options screen.
Page 23 FT5X User Guide 4.4 Telephone Keypad Configuration Commands User may enter commands by using telephone keypad of a telephone connected to the Phone socket on the back panel of the unit as follows: 1. Lift Receiver 2. Enter Command – a confirmation tone will then be heard 3.
Page 24 FT5X User Guide 9. Set FAX and Voice Ring both Command：#*68*n# Description：Set FAX and Voice Ring both，when n is 0 means off， and 1 means o. This function is NO effective on the hardware board version 2.0. 10. Minute Prompt Command：#*110*n#...
Page 25 FT5X User Guide Set the call divert number from GSM to FXO Command：#*77*number# Description： Set the call diverts number from GSM to FXO. When the function of call diversion from GSM to FXO is on, GSM dial this Number from FXO port.
Page 26 FT5X User Guide 4.4.7 Hotline call number 1． Set the hotline call number Command：#*65*hotlineNumber# Description：Set the hotline call number ，hotlineNumber is the hotline call number. 2． Set the hotline dialing time Command：#*66*seconds# Description：Set the time from picking up to auto-sending the hotline number by the device.
Page 27 FT5X User Guide 4.4.9 GSM network configuration The following command code is in the keyboard commands: Command Function code Activate Register and activate Status check Unable Unregistered and unable Dialing number Password GSM divert always Command：(*|#|*#|**|##) 21*DN*BS# Description：GSM divert always GSM divert on busy Command：(*|#|*#|**|##) 67*DN*BS#...
Page 28 FT5X User Guide Description：GSM restrict all the incoming call 11. GSM all incoming call restriction roam Command：(*|#|*#) 351*PW*BS# Description：GSM restrict all incoming call during roaming 12. GSM enable/disable call waiting Command：(*, #, *#43#) Description：GSM enable/disable call waiting function 28/31...
Page 29: Frequently Asked Questions
Q: What type of fax machine do I need to use? A: FT5X is in line with G3 fax criteria. Any compatible G3 standard fax machine is OK. Q: When I use GSM fax, is it possible to fax like desktop fax machine, i.e. make a phone call before sending faxes? A: Not possible.
Page 30: Warranty
FT5X User Guide WARRANTY Dear User: Thank you for choosing the fixed wireless terminal of our company. In order for you to enjoy our complete service, please read the following warranty conditions carefully. Product warranty conditions: From the date you purchased this product, unless otherwise damaged by intention, •...
Page 31: Warranty Card
FT5X User Guide Warranty Card User is required to fill out the form carefully and keep it in a safe place, for future repair claim. Customer Tel: Name Product Device Type Purchase Dealer Date （Seal of Distributor/Dealer） 31/31...
