Scanner SDX7 User Manual

SPECIFICATIONS

SDX7 Receiver
Receiver Mode: Crystal controlled single channel
Receiver Type: Non-diversity
Carrier Frequency: Spot frequency, factory set
Frequency Stability: 0.005%
Deviation: 15KHz (max)
Sensitivity: 20dBµ V (S/N ratio > 60 dB)
De-emphasis: 50µS
Image & Spurious Rejection: >70dB
S/N Ratio: > 60dB
T.H.D: < 0.5%
Frequency Response: 50Hz – 15KHz
Audio Output: Unbalanced 775mV, 5 KΩ load
Power Supply: DC 12-15V at 300mA
Dimension: 202 (L) x 134 (W) x 38 (H) mm
Weight: 290g
SDX7 Hand Held Microphone Transmitters
Operating Frequency: Spot frequency, factory set
Modulation: 15KHz (max)
RF Power Output: 2mW (max)
Pre-emphasis: 50µS
Spurious: > 60dB below carrier frequency (typical)
T.H.D: < 0.5%
Frequency Response: 50Hz – 15KHz Overall
Battery: MN1604
Battery Life: About 8 hours (with alkaline batteries)
Current Consumption: < 20mA
Dimension: 35mm diameter body, 238mm long. (Head 45mm diameter)
Weight: 188g (excluding battery)
www.jhs.co.uk
EXCLUSIVE WORLDWIDE TRADE DISTRIBUTORS:
JOHN HORNBY SKEWES & CO. LTD., SALEM HOUSE, PARKINSON APPROACH, GARFORTH, LEEDS LS25 2HR, UK.
Telephone: 01132 865381 Fax: 01132 868515 Email: info@jhs.co.uk
©2006 JHS & Co. Ltd. Specifications are subject to change without prior notice.
S S c c a a n n n n e e r r
T T h h e e
VHF RADIO SYSTEM
MODEL: SDX7
USER GUIDE
