Spare Part List - Whirlpool ADP 950/3 WH Service Manual

24.09.1999 / Page 4
Doc. No: 4812 718 14355

Spare part list

Model ADP 950/3 WH
Service No. 854295041410
Version 854295041410
Pos. No. 12NC Code Description
003 0 4812 440 19382 Traverse
004 0 4812 440 18952 Drip tray assy
004 1 4812 401 18402 Holder
011 0 4812 505 18357 Foot short
022 0 4812 440 18951 Side panel left
022 1 4812 440 18949 Side panel right
022 2 4812 440 18953 Spacer
024 0 4812 440 19463 Panel, rear
030 0 4812 310 18428 Table top AMH4000WH
034 0 4812 404 78237 Spacer
034 1 4812 404 78242 Fastener table top
040 1 4812 417 18774 Hinge left
040 2 4812 417 18773 Hinge right
040 3 4812 417 18784 Protector f.door (set)
044 0 4812 492 38358 Spring f.door
044 1 4812 492 38364 Spring f.cap
047 0 4812 404 48591 Brake f.door
047 1 4812 401 18397 Band,brake
047 2 4812 404 68023 Hook
053 0 4812 440 88887 Plinth WH
103 0 4812 440 18978 Door outer
120 0 4812 440 19456 Door,inner
120 1 4812 440 18969 Batten
130 0 4812 417 58361 Tilt lock
131 0 4812 401 18416 Hook lock
191 0 4812 466 68564 Gasket door
192 0 4812 466 68467 Gasket, door lower
241 0 4812 458 18913 Basket upper/straight
241 1 4812 458 18324 Holder cups right white
241 3 4812 528 88068 Wheel,basket upper (set)
241 8 4812 466 68553 Spacer cap set
241 9 4812 528 88075 Wheel,basket basket upper
242 0 4812 458 18919 Basket lower cpl.
242 1 4812 528 88069 Wheel,basket lower
242 4 4812 466 48059 Fixation
243 0 4812 458 18272 Basket cutlery
261 0 4819 462 38271 Rail telescope, inner
261 1 4819 404 48819 Cap rail
261 2 4812 462 78995 Cap rail ahead
263 0 4819 520 18013 Ball cage cpl.
263 1 4812 520 48001 Ball Niro 8 D
301 0 4812 453 70355 Control panel WH
303 1 4812 460 38055 Plate,handle WH
305 0 4812 440 18964 Batten WH
322 0 4812 453 70352 Insert panel WH
322 1 4812 440 19468 Sticker Multizone blue
331 0 4812 413 58926 Knob program cpl. WH
332 0 4812 410 28564 Push button cap WH
350 0 4812 276 58075 Display board (DB)
400 0 4812 361 58126 Motor + spraypump cpl.
405 0 4812 360 18371 Spray pump
405 1 4819 515 28158 Gasket
420 0 4812 121 18132 Capacitor
421 0 4812 121 18161 Interf.filter
430 0 4812 360 18357 Pump,draining
ADP950/3WH
8542 950 41410
Pos. No. 12NC Code
430 1
450 0
480 0
480 1
480 2
480 3
490 0
490 1
521 0
571 0
571 3
583 0
620 0
633 0
680 0
680 1
681 1
681 2
682 0
691 0
701 0
701 0
701 0
701 1
701 2
710 2
710 3
714 0
714 2
716 0
716 1
716 2
721 1
721 2
721 3
721 4
722 0
722 2
723 0
723 1
723 2
723 3
726 0
726 1
726 2
726 3
726 4
743 1
751 0
751 1
751 2
755 0
755 2
761 0
761 2
Whirlpool Europe
S E R V I C E
Customer Service
Description
4812 466 68506 Shaft seal
4812 259 28684 Heating element
4812 321 28386 Cable harness set
4812 321 28371 Cable
4812 321 28383 Cable 6poles
4812 401 18418 Protector f.wiring
4812 321 18053 Cable,mains
4812 321 28367 Strain relief
4812 214 78251 Control board (CB)
4812 281 28365 Valve inlet
4812 281 28363 Valve f.zone-washing
4812 271 28355 Switch diaphragm
4812 218 38056 User board (UB)
4812 271 38355 Microswitch door
4812 418 68154 Combidosage
4812 466 68495 Gasket
4812 466 68497 Gasket
4812 440 18975 Flap
4812 466 68496 Gasket
4812 282 68012 Feeler NTC
4812 530 28081 Hose, inlet 3/8Z cpl. 5m
4812 530 28082 Hose, inlet 3/8Z cpl. 3m
4819 530 28928 Hose, inlet
4812 310 18302 Yoke
4822 480 50159 Sieve inlet
4819 310 38536 Threaded ring
4819 466 69562 Gasket set
4812 462 78012 Threaded cap
4812 440 18963 Cabinet non-return flap
4812 418 68142 Reg.dosage
4812 466 68475 Gasket
4812 462 78994 Cover
4812 360 68061 Spray arm lower. cpl.
4812 466 68491 Gasket 25x2,3B
4812 466 68558 Gasket 30x3,0
4812 440 19455 Flange
4812 360 68044 Spray arm upper
4812 360 68056 Hub upper straight cpl.
4812 360 68049 Spray arm ceiling
4812 466 68483 Gasket
4812 404 48597 Clip,fix spray arm
4812 505 18362 Screwed joint
4812 530 28786 Tube
4812 530 28787 Tube
4812 505 18358 Nut
4812 466 68512 Gasket
4812 462 79633 Centering
4812 530 28102 Hose, inlet
4812 418 18205 Water collector
4812 418 18203 Water guide
4812 440 19454 Fastener frame
4812 530 28849 Bend
4812 530 48148 Tray,leak
4812 480 58082 Sieve fine
4812 418 18204 Cover sieve
