Instruction Manual
www.minolta.co.uk
Technical Specifications
Number of effective pixels:
CCD:
Camera
sensitivity:
Focal length:
Lens construction:
Maximum aperture:
Minimum focus distance:
Maximum magnification:
Area covered at
maximum magnification:
Monitor LCD:
Shutter:
Shutter speed range:
Autofocus system:
Autofocus areas:
Metering:
Multi-segment metering:
The essentials of imaging
2.0 million
1/3.2-type interline primary-colour CCD
Total pixels: 2.1 million
Auto (between ISO 64 –200 equivalent), ISO
64,100, 200, 400 equivalents
4.8 – 14.4mm (35mm equivalent: 37 – 111mm)
10 elements in 9 groups (includes two double-
sided aspheric elements)
f/2.8 – f/3.7
0.10m from front of camera
0.111x (1:9.01)
Equivalent to 0.857x (1: 1.17) in 35mm format
40 x 30mm
4.0cm digital-interface TFT colour
monitor with anti-reflection coating
Total pixels: 84,960
Automatic monitor amplification
CCD electronic shutter and mechanical shutter
4 - 1/1000 s
Video AF
Wide focus area (five point AF)
Multi-segment
256 segments
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Minolta X 20
Summary of Contents for Minolta X 20
- Page 1 www.minolta.co.uk Technical Specifications Number of effective pixels: CCD: Camera sensitivity: Focal length: Lens construction: Maximum aperture: Minimum focus distance: Maximum magnification: Area covered at maximum magnification: Monitor LCD: Shutter: Shutter speed range: Autofocus system: Autofocus areas: Metering: Multi-segment metering: The essentials of imaging 2.0 million 1/3.2-type interline primary-colour CCD Total pixels: 2.1 million...
- Page 2 www.minolta.co.uk Exposure control: Exposure compensation: Flash range: Flash modes: Continuous advance: Self timer: Self portrait: Multi frame: Image pasting: Movie recording: Audio: White balance control: Toning: Portrait mode: Noise reduction: The essentials of imaging Programmed AE ±2 Ev in 1/3 increments Wide: 0.1 –...
- Page 3 www.minolta.co.uk Digital zoom: E-mail Copy function: Favourites: Slide show: Rotate: Date imprinting: Key customisation: Image quality modes: Number of recorded pixels (Still images): Number of recorded pixels (Movie clips): Storage capacity: Fine Standard Economy Movie *Still images recorded without voice memo or audio caption **Actual number of images may vary depending upon the subject and memory card.
- Page 4 www.minolta.co.uk File formats: Folder name formats: Printing output control: Recording media: Computer interface: Direct print: Remote camera: AV output: Batteries: Battery performance (Playback): Battery performance (Recording): External power source: Dimensions: Weight: Operating temperature: The essentials of imaging JPEG, Motion JPEG (MOV), WAVE DCF 1.0-compliant DPOF-compliant (Supported by printing functions in ver.
-
Page 5: Standard Accessories
www.minolta.co.uk Standard accessories: Optional accessories: Specifications and accessories are based on the information available at the time of printing and are subject to change without notice. The essentials of imaging Neck Strap NS-DG500 AV Cable AVC-200 USB Cable USB-500 8MB SD (Secure Digital) Memory Card Two AA Alkaline batteries DiMAGE Viewer Metal Chain Neck Strap NS-DG100... - Page 6 www.minolta.co.uk System Requirements Compatible computers when the camera is used as mass storage devise: IBM PC/AT compatible computers with Windows XP Home, Windows XP Professional, Windows Me, Windows 2000 Professional, Windows 98*, or Windows 98 Second Edition* and with a USB port as standard interface. Apple Macintosh computers with preinstalled Mac OS 9.0 –...
