kchibo KK-9803 User Manual

Kchibo KK-9803 User's Manual
Picture Illustration
1. Antenna
2. Frequency Display
3. Tuning Indicator
4. AM Led
5. FM Led
6. Tuning Switch
7. AM Button
8. FM Button

Radio Operation

1. Install 2 AA batteries into the batteries compartment (11) or use a power adapter
to connect with the D.C. jack(13).
2. Turn on the radio (9).
3. Adjust the volume (15) to the desired level.
4. Press the FM button (8) for FM reception, the FM Led (5) will turn on.
5. Press the AM button (7) for AM/SW reception. User can select AM/SW 1-8 band
through the Band Selector (10). The AM Led will turn on.
6. Rotate the Tuning switch (6) to the desired station.
7. When the signal is strong, the Tuning Led (3) will turn on.
8. User may need to extend the antenna for better reception of FM and SW bands.
9. User may need to adjust the position of the radio for better reception of AM band.
10. When earphone is plugged in, the speaker will turn off automatically.
9. Power
10. Band Selector
11. Battery Compartment
12. Hand Strap
13. D.C. Jack
14. Earphone Jack
15. Volume Control
