Summary of Contents for Russell Hobbs RHUCFF48W
- Page 1 48cm Under Counter Fridge Freezer USER’S GUIDE Model number: RHUCFF48W For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE...
-
Page 2: Table Of Contents
Page BEFORE USING THE APPLIANCE ………………………………………. Safety Instructions ………………………………………. Safety Instructions Before Switching On ………………………………………. Installing and Switching on the Appliance ………………………………………. The Appliance and the Compartments …………………………….………… Usage Information ………………………………………. Thermostat Setting Cleaning and Maintenance ……………………………….……… Replacing the Lamp ………………………………………. -
Page 3: Before Using The Appliance
BEFORE USING THE APPLIANCE Safety Instructions • The model contains R600a (the coolant, Isobutene), a natural refrigerant gas that is environmentally friendly but also combustible. When transporting and installing the unit, care must be taken to ensure that none of the refrigeration circuit components are damaged. -
Page 4: Safety Instructions
Safety Instructions Warning: • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 5: Installing And Switching On The Appliance
Installing and Switching on the Appliance • Operating voltage for your fridge is 220-240V at 50Hz. • If you need help or are unsure how to install the unit, please contact Customer Services on 0845 208 8750 or visit www.productcareuk.com. •... -
Page 6: The Appliance And The Compartments
THE APPLIANCE AND THE COMP ARTMENTS 1. Freezer Compartment Crisper Crisper Cover Freezer Door Rack Glass Shelf Thermostat Control and light Unit Can Holder Rack Bottle Rack Item Quantity Vegetable crisper Glass shelf Glass cover (Crisper) Instruction Booklet Parts may vary according to the appliance model. For Customer Services &... -
Page 7: Usage Information Thermostat Setting
USAGE INFORMATION Thermostat Setting • The thermostat automatically regulates the inside temperature of the refrigerator compartment. By rotating the knob from position « 1 » to « 7 », colder temperatures can be obtained. (1 being HIGH and 7 being LOW) •... -
Page 8: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Disconnect the appliance from the power supply before cleaning. • Do not pour water directly over or on the appliance. • The refrigerator compartment should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. •... -
Page 9: Replacing The Lamp
Replacing the lamp • Unplug the appliance from the mains. • Locate the lamp cover which is on the rear of the temperature control panel in the top right hand side of the refrigeration compartment. • Replace the bulb with a new one, rated at no more than 10W. •... -
Page 10: Important Notes
IMPORT ANT NOTES: The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling sound) even when the compressor is not running. T his is quite normal. If these sounds are different check that ; • The appliance is level. •... -
Page 11: Connection To The Mains Supply
Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or coloured... -
Page 12: Transportation And Handling
Transportation and Handling For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the base and rear corners of cabinet. Lift the refrigerator carefully. Never use the door handles for lifting. To move the refrigerator on a flat level surface, tilt it slightly backwards onto the two rear moulded feet and push backwards. -
Page 13: Installation
Installation • After installation, do not switch the power to the refrigerator on for at least 3 hours – the unit needs to stand. The unit should be kept away from direct sunlight. • Remove all transport tapes and foam protection pieces . Clean the interior of the appliance with a cloth dampened in lukewarm soap and water. -
Page 14: Reversing The Door
Reversing the Door You will need to tilt the fridge backward to access the lower hinge which holds screws. Do not tilt more than 45 degrees and do not lay the fridge flat on its side. For your own safety, a minimum of 2 people should lift or tilt this product. •... -
Page 15: Troubleshooting
Troubleshooting Problem Solution The fridge/freezer doesn't work. - Check that the appliance is switch on. - Check that there has not been a power cut. - Check that the plug is faulty. - Check that the fuse has not blown. - Check that the voltage is correct for the appliance. -
Page 16: Guarantee
Warranty This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: The product must be returned to the retailer with the original proof of •... - Page 17 Notes: For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 18 For Customer Services & Spare Parts please call 0845 208 8750 Opening times: Monday – Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com Revision 2 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
