Summary of Contents for EelCam SER1472X
-
Page 1: Fish Finder
underwater camera fish finder Common Type Recording Type Instruction Manual... - Page 2 Ⅰ Safety Notes: 1、Please read the manual carefully before using it. 2、Handle it carefully during operation, avoid throwing down or pressing it heavily. 3、If the users disassemble or deliberately damage the machine, it will beyond the warranty. 4、Please copy your information before connecting the SD card, the manufactures will not be responsible for the loss caused by losing data.
-
Page 3: Specifications
Ⅲ Specifications Program parameter Charger 100VAC-240VAC DC12.6V 2000MA Battery The continued using time of the battery about 7 hours The monitoring depth Camera light source six high-power brightly white lights Camera angle 92° camera picture color monitor image color camera: 600 TVL monitor input voltage 12VDC... -
Page 4: Recording Type
Ⅳ Display operation interface instructions Common Type 1、power 2、adjustment + 3、adjustment - 4、menu Recording Type 1、indicator light 2、power 3、adjustment -/ view the video 4、menu/play the video 5、adjustment +/ record 6、quit/view the picture 7、delete/ take a picture 8、continuously record/ continuously take pictures... - Page 5 Ⅴ how to operation Common Type 1、Boot Connect all the connectors and press the power key, the system will start to work. 2、Menu Settings 1> Brightness Press the MENU key to enter brightness setting, press the ―+ -‖ key to set the brightness, and then press the MENU key again to quit the menu page after doing this.
- Page 6 Recording Type 1、Boot Connect all the joints and press the power key, the system will start to work. 2、Menu settings (MENU) 1> Press the MENU key to enter the menu page. 2> Press the MENU key again to select the setting content, including date setting, time setting, recording time setting, recording model setting, contrast setting and color setting.
- Page 7 package at one time, it you want to record again after finishing the former one, you should press the + key again. 4、Take pictures (DEL) Press the DEL key to take a picture; it will save it into the SD card automatically. 5、Continuously record (REC) 1>...
- Page 8 7 View the video（-） 1> Press the – key to show the saved recorded packages, on the lower left corner will show the quantity of the saved recorded packages, on the lower right corner will show the recorded date and time. 2>...
- Page 9 Ⅵ Connection camera connector power connector video connector Ⅶ Charging When the battery power is low, it needs charging, and the method is as below: 1、Take out the battery and charger from the box. 2、Connect the charger to the battery(red to red, black to black). 3、Connect the charger to the alternating current of 110-200v.
- Page 10 Ⅷ The method of taking out the SD card 1、 Press the buttons on both sides of the display with two hands at the same time to pop the display. 2、Press the SD card slightly on the left corner of the display to pop the SD card.
- Page 11 Ⅸ Product components and accessories battery display charger camera aluminum box cable Attached picture...
- Page 12 Ⅹ Common breakdown and process breakdown Reasons and process No electricity check all the conntion to see whether something goes wrong No picture shows when 1、check all the connection the indicator is on; the 2、check the battery powerful or not, try again indicator can’t be on after charging.
