Page 1: Installation And Operation
Installation and Operation Instructions SP Series Plate Amplifiers SpeakerPower Inc. 3001 S Harbor Blvd, Santa Ana CA 92704... -
Page 2: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 3 I. Introduction 1. Intended Application. To Be Installed Only in Restricted Access Areas (Dedicated Equipment Rooms, Equipment Closets, or the like) in Accordance with Articles 110-18, 110-26, and110-27 of the National Electrical Code, ANSI/NFPA 70. The equipment must be operated and maintained only by trained personnel.
- Page 4 6. Parts Check List. The amplifier comes with an appropriate AC power cord. The user must provide input and speaker cabling appropriate for the application. 7. Panel Layout. The arrangement of the connectors may differ from model to model. Mute switches Fuse Power In/out DSP Connector...
-
Page 5: Getting Started
Getting Started 1. Speaker Connections. Speakers are connected to the internal amplifiers by the white 6 pin AMP mate n lock connector on the rear panel. The mating connector is AMP MATE-N-LOC 350715-1 (Digikey part number A14288-ND). The individual pins are Amp 350552-1 (Digikey A14303-ND) for .130 - .200 inch diameter wire insulation. - Page 6 Rear View Wire Exits Side View End view 1+ 2- 3+ 3- 2+...
-
Page 7: Basic Operation
4. AC mains connection. The mains disconnect of the amplifier is the AC plug. It must be removed from the AC service to completely remove power from the amplifier. The AC mains power cord is connected to the front panel through the blue Neutrik Powercon. -
Page 8: Advanced Operation
IV. Advanced Operation 1. Software Installation and PC Interface Setup. 2. Make sure power is off on amplifier and computer 3. Plug the interface board into the parallel port of the computer 4. Plug the interface cable into the interface board and the SP amplifier. 5. - Page 9 21. You may now unmute the amplifier channels and measure the response. 22. To save the configuration into the amplifier so it is available with the computer removed, select EEPROM on the EQ GUI panel. Select “EEPROM Write”. After several seconds you will see “EEPROM Done” Click OK and close the EEPROM panel.
- Page 10 c. Fourth order Butterworth. Use two Vari Q filters, one with a Q of 1.31 and the other with a Q of 0.541. d. Eighth order Butterworth. Use four Vari Q filters with Q of 0.51, 0.60, 0.90, and 2.56. e.
- Page 11 51. The value of 0XF9 in the configuration file must read 01 41 24 11 to enable 96Khz operation. Xf5 and Xf7 should have values 00 04 04 04. 52. Select “BQ12” on the flow chart. 53. Pull down Ch1 drop down menu, select wipe.EQ310X and press ENTER. You must do this before loading an EQ310X file to wipe out the previous settings.
