Niles iC7500 Installation Manual

c e i l i n g M o u n t l o u d s p e a k e r s
SPECIFICATIONS
Recommended Normal Frequency
Model
Sensitivity
Amplifier Power Impedance Response
iC7500 8 ohm
56Hz - 91 dB with 2.83 V pink
7" injection-molded TCC™ 10 to 125 watts nominal;
21kHz noise input measured at
woofer and one pivoting 1" per channel 6 ohm
+/-3dB 1 meter on axis
Teteron ® tweeter. minimum
iC7600 8 ohm
54Hz - 91 dB with 2.83 V pink
10 to 150 watts nominal;
7" interlaced glass fiber
21kHz noise input measured at
woofer and one pivoting 1" per channel 6 ohm
+/-3dB 1 meter on axis
minimum
Teteron ® tweeter.
iC8500 8 ohm
91 dB with 2.83 V pink
49Hz -
8" injection-molded TCC™ 10 to 150 watts nominal;
noise input measured
21kHz
per channel 6 ohm
woofer and one pivoting 1"
+/-3dB at 1 meter on axis
Teteron ® tweeter. minimum
iC8600
8 ohm
49Hz - 91 dB with 2.83 V pink
10 to 150 watts nominal;
8" interlaced glass fiber
noise input measured
21kHz
woofer and one pivoting 1" per channel 6 ohm
+/-3dB
at 1 meter on axis
Teteron tweeter. minimum
®
