Summary of Contents for E-Bench Bench KH 2222
- Page 1 KH 2222 Surround Sound System with Q-Sound Operating Instructions...
- Page 2 KH 2222 IB v. 1.0, 04-12-2003 Kompernaß Handelsgesellschaft mbH Burgstraße 21 D-44867 Bochum, Germany — www.kompernass.com...
-
Page 3: Table Of Contents
Index 1. Technical Data 1.1. Output ... 4 1.2. Speakers ... 4 1.3. Dimensions (in mm)... 4 2. Scope of delivery 3. Application and Function 4. Safety Information/Setting up the equipment 5. Control Elements and Displays 5.1. Front of center speaker ... 6 5.2. -
Page 4: Technical Data
1. Technical Data 1.1. Output Subwoofer... 30 W (8 Ohm, THD: 1%) Front and rear speakers both ... 12 W (4 Ohm, THD: 1%) Center speaker ... 12 W (4 Ohm, THD: 1%) Power consumption... 150 W Mains voltage ... AC 230 V ~ 50 Hz 1.2. - Page 5 any container filled with water – such as e.g. vases – on the components. Attention! If water runs into the components, it can cause irrepara- ble damage! Warning! In this case there is additionally also a fire risk! The technical components of the surround sound system are designed for temperatures between 5º...
-
Page 6: Control Elements And Displays
5. Control Elements and Displays 5.1. Front of center speaker 1. Display 2. CD display 3. AUX display 4. Q SOUND display 5. Stereo/3 channel stereo display 6. DVD/5.1 display 7. TV display 8. Standby/Mute display 9. 5.1 EXT display 5.2. -
Page 7: Remote Control
5.4. Remote control 20. STANDBY button 21. MUTE button 22. CD button 23. TV button 24. AUX button 25. DVD/5.1 button 26. 5.1EXT button 27. STE./3STE. button 28. SURR + button 29. CENTER + button 30. RESET button 31. SW + button 32. -
Page 8: Preparing The Surround Sound System For Operation
6. Preparing the Surround Sound System for Operation 6.1. Unpacking the components Remove the components of the surround sound system • 1 bass reflex active subwoofer with power cord • 1 center speaker with integrated receiver • 2 front speakers •... -
Page 9: Connecting The Surround Sound System To Audio/Video Equipment
• the end of the grey lead of the speaker cable into the red terminal and • the end of the black lead of the speaker cable into the black terminal on the back of the subwoofer. Insert the individual speaker cables into the following terminals: •... -
Page 10: Connection Via Scart /Euro Av Jacks
Insert one cinch cable into each of the cinch jacks. Insert the other end of the cinch cable into one of the pairs of jacks • AUX L/R • TV L/R • CD L/R on the back of the subwoofers. It does not matter which of the three pairs of jacks you use. -
Page 11: Functions During Operation
• have positioned the components of the surround sound system in a suitable place and • have connected them to the subwoofer with the sup- plied cables • have connected the required audio/video devices with the named connecting options to the surround sound system and •... -
Page 12: Setting The Bass And The Treble
press the buttons, you set the volume between the val- ues -10 (minimum volume) and 10 (maximum volume). • To change the volume of the subwoofer: Press the SW + button to increase the volume. Press the SW – button to lower the volume. -
Page 13: No Surround Sound
Have you perhaps not chosen the source for the sound, which you would like to play back, with the remote control of the surround sound system? Example: You would like to play back the sound of an audio/video device, which is connected to the AUX pair of jacks. In- stead of pressing the AUX button, you pressed the TV button. - Page 16 KH IB v. ., -- Kompernaß Handelsgesellschaft mbH • Burgstraße • D- Bochum, Germany www.kompernass.com...
