BUSINESS CONTINUITY
Business Continuity Solutions
SonicWALL CDP Series
SonicWALL CDP 3440i/4440i
Getting Started Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SonicWALL CDP 3440i and is the answer not in the manual?

Questions and answers

Summary of Contents for SonicWALL SonicWALL CDP 3440i

  • Page 1 Business Continuity Solutions SonicWALL CDP Series BUSINESS CONTINUITY SonicWALL CDP 3440i/4440i Getting Started Guide...
  • Page 2 SonicWALL Continuous Data Protection (CDP) appliance into an existing or new network. The SonicWALL CDP appliance backs up data as changes occur and replicates them first locally and then to a secure offsite location. This real-time data protection provides the most current file and system backup possible.

  • Page 3: Table Of Contents

    “Registering Your SonicWALL CDP Appliance” on page 7 • “Configuring Time Zone and Network Settings” on page 10 • “Connecting The SonicWALL CDP Appliance to Your Network” on page 15 • “SonicWALL CDP Software Interfaces” on page 15 • “Downloading and Installing the SonicWALL CDP Software” on page 16 •...

  • Page 4: Before You Begin

    * The included power cord is intended for use in North America only. For European Union (EU) customers, a power cord is not included. * Das eingeschlossene Netzkabel ist für Gebrauch in Nordamerikas nur vorgehabt. Für Europaïsche Union (EU) Kunden, ist ein Netzkabel nicht eingeschlossen. SonicWALL CDP 3440i/4440i Getting Started Guide Page 3...

  • Page 5: What You Need To Begin

    Before continuing, record the following configuration information for your reference: Networking Information CDP IP Address: Select a free static IP address for your SonicWALL CDP appliance that is within the range of your local subnet. CDP Subnet Mask: Enter the subnet mask for the local subnet where you are installing your SonicWALL CDP appliance.

  • Page 6: Overview Of The Sonicwall Cdp Appliance

    * Pressing the reset button for several seconds will result in a reboot of the SonicWALL CDP appliance. ** Do not plug devices into any ports (other than those indicated) unless explicitly instructed to do so by a SonicWALL technical support representative. Doing so may void your warranty. Feature...
  • Page 7 * Pressing the reset button for several seconds will result in a reboot of the SonicWALL CDP appliance. ** Do not plug devices into any ports (other than those indicated) unless explicitly instructed to do so by a SonicWALL technical support representative. Doing so may void your warranty. Feature...

  • Page 8: Setting Up The Sonicwall Cdp Appliance

    • “Activating Your SonicWALL CDP Appliance” on page 20 Registering Your SonicWALL CDP Appliance The SonicWALL CDP appliance must be registered with the software license key before first use. Perform the following steps to register your SonicWALL CDP appliance: Note: You need a mySonicWALL.com account to register the SonicWALL CDP...
  • Page 9 Enter the serial number, found on the back of your SonicWALL CDP appliance. Friendly Name Enter a friendly name for your SonicWALL CDP appliance. Authentication Code Enter your authentication code, found on the back of your SonicWALL CDP appliance (just below the serial number).
  • Page 10 1. If you purchased optional Offsite Data Backup Service and have an activation key, scroll down to Applicable Services. If you do not have an Offsite Data Backup Service activation key, click Buy or contact your SonicWALL vendor. Next to Offsite Data Backup Service, click Enter Key.

  • Page 11: Configuring Time Zone And Network Settings

    Configuring Time Zone and Network Settings The SonicWALL CDP appliance requires correct time zone settings and a static IP address on your local subnet in order to communicate with your network. The following procedures provide instructions to configure local time zone settings and network settings on your SonicWALL CDP appliance.
  • Page 12 SonicWALL CDP appliance, connect the LAN port on the computer to the LAN port on the back of your SonicWALL CDP appliance. 2. Set the computer you use to manage the SonicWALL CDP appliance to have a static IP address of 192.168.168.50. For help with setting up a static IP address on your computer, refer to “Configuring a Static IP Address”...
  • Page 13 Click the Add button to add your own NTP server. If you do not add your own NTP server, an internal list of servers will be used by default. 3. Click the Apply button to save changes. Your SonicWALL CDP appliance is now set to your local time. Page 12...
  • Page 14 3. In the Add/Entry field, enter a single domain name server and click the OK button. Repeat steps 2 and 3 to add additional DNS entries. 4. Click the Apply button at the top of the screen to save your settings. SonicWALL CDP 3440i/4440i Getting Started Guide Page 13...
  • Page 15 SonicWALL CDP appliance IP address to 10.10.10.20. 3. Press the Submit button to submit the IP address change. Your SonicWALL CDP appliance is now set to communicate with your network using a static IP address. Disconnect your management computer from the SonicWALL CDP appliance, and continue to the next section to connect the SonicWALL CDP appliance to your local area network.

  • Page 16: Connecting The Sonicwall Cdp Appliance To Your Network

    3. Plug the supplied power cable into the back of the SonicWALL CDP appliance. 4. Plug the other end of the supplied power cable into an AC socket. The SonicWALL CDP appliance automatically powers on and begins the initial boot process.

  • Page 17: Downloading And Installing The Sonicwall Cdp Software

    Downloading and Installing the SonicWALL CDP Software Perform the following steps to install the SonicWALL CDP software on the management computer as well as each agent computer that requires access to the SonicWALL CDP appliance for data backup. Downloading the Latest SonicWALL CDP Software 1.
  • Page 18 5. If you agree to the terms and conditions, select the I accept the terms of the license agreement option and click the Next button. 6. Enter a User Name and Company Name and click the Next button to continue. SonicWALL CDP 3440i/4440i Getting Started Guide Page 17...
  • Page 19 7. Select a type of installation, either Complete or Custom (recommended for advanced users), and click Next. 8. SonicWALL CDP is ready to install. Click Install to continue. The Setup Status page displays. Page 18...
  • Page 20 9. Once the software installation is complete, click Finish. You have successfully completed installing the SonicWALL CDP software. SonicWALL CDP 3440i/4440i Getting Started Guide Page 19...

  • Page 21: Activating Your Sonicwall Cdp Appliance

    Activating Your SonicWALL CDP Appliance Perform the following steps to activate your SonicWALL CDP appliance. You will need the product registration code that you obtained in “Registering Your SonicWALL CDP Appliance” on page 7 to complete this section. Alert: You must have Internet connectivity to register and activate SonicWALL CDP.
  • Page 22 3. Enter “password” in the Password field and click Login. 4. The Appliance Registration Wizard Internet Connectivity page displays. Click Verify Appliance Internet Connectivity. SonicWALL CDP 3440i/4440i Getting Started Guide Page 21...
  • Page 23 “Connection succeeded. Click Next to continue.” Click Next. Note: If you receive a registration error, it is probably because the SonicWALL CDP appliance network settings are incorrect and the appliance cannot communicate with the Internet. Login to the CDP appliance user interface and navigate to Network >...
  • Page 24 7. When you see the message “Appliance Registration Was Successful”, click Finish. The SonicWALL Enterprise Manager status window displays. You have successfully completed registration of your SonicWALL CDP appliance. Your SonicWALL CDP appliance is now fully operational. Continue with “SonicWALL Enterprise Manager Status Overview”...

  • Page 25: Preparing The Sonicwall Cdp Appliance For First Use

    Preparing the SonicWALL CDP Appliance for First Use This section provides instructions for preparing your SonicWALL CDP appliance for first time use with the SonicWALL CDP Enterprise Manager. This section contains the following subsections: • “SonicWALL Enterprise Manager Status Overview” on page 24 •...
  • Page 26 Description Administrative Settings Appliance Displays the name of the current SonicWALL CDP appliance. Appliance IP Displays the IP address of the current SonicWALL CDP appliance. Administrator Displays the E-mail address of the current administrator to this E-mail SonicWALL CDP appliance.

  • Page 27: Changing Password And Administrator Settings

    Changing Password and Administrator Settings Perform the following steps to set your SonicWALL CDP appliance password and verify administrator settings and information. 1. In Enterprise Manager, select Edit > Administrative Settings from the top menu bar and complete the fields as described in the table below:...
  • Page 28 5. Select a common folder from the list, such as Desktop or My Documents, and click the Add button to start a backup. 6. Click the Status button to return to system Status view. SonicWALL CDP 3440i/4440i Getting Started Guide Page 27...
  • Page 29 Congratulations! You have successfully set up and tested your SonicWALL CDP appliance operation. To add additional computers to SonicWALL CDP, install the SonicWALL CDP Agent Tool software on each agent machine that requires data backup to the SonicWALL CDP appliance.
  • Page 30 Allow unrestricted airflow around the unit and through the vents on the side of the unit. A minimum of 1 inch (25.44mm) clearance is recommended. • Mount the SonicWALL appliances evenly in the rack in order to prevent a hazardous condition caused by uneven mechanical loading. •...
  • Page 31 Seite des Gehäuses frei sind. Hier ist ein Belüftungsabstand von mindestens 26 mm einzuhalten. • Bringen Sie die SonicWALL gerade im Rack an, um mögliche Gefahren durch un- gleiche mechanische Belastung zu vermeiden. • Prüfen Sie den Anschluss des Geräts an die Stromversorgung, damit der Über- stromschutz sowie die elektrische Leitung nicht von einer eventuellen Überlastung...
  • Page 32 4. Select Specify an IP Address and type 192.168.168.50 in the IP address field. 5. Type 255.255.255.0 in the Subnet Mask field. 6. Click OK, and then click OK again. 7. Restart the computer for the changes to take effect. SonicWALL CDP 3440i/4440i Getting Started Guide Page 31...
  • Page 33 CDP 4440i Unauthorized Ports Do not plug devices into any ports (other than those indicated) unless explicitly instructed to do so by a SonicWALL technical support representative. Doing so may void your warranty. FCC Part 15 Class A Notice This equipment was tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 34 EN 61000-3-3 (1995) + A1 EN 60950-1 (2001) +A11 National Deviations: AT, AU, BE, CH, CN, CZ, DE, DK, FI, FR, GB, GR, HU, IE, IL, IN, IT, JP, KR, NL, NO, PL, SE, SG, SI SonicWALL CDP 3440i/4440i Getting Started Guide Page 33...

  • Page 35: Cable Connections

    All products with country code “C” or “D” are made in Taiwan R.O.C. Lithium Battery Warning The Lithium Battery used in the SonicWALL Internet security appliance may not be replaced by the user. The SonicWALL must be returned to a SonicWALL authorized service center for replacement with the same or equivalent type recommended by the manufacturer.
  • Page 36 Kabelverbindungen Alle Ethernet-Kabel eignen sich für die Verbindung von Geräten in Innenräumen. Schließen Sie an die Anschlüsse der SonicWALL keine Kabel an, die aus dem Gebäude herausgeführt werden, in dem sich das Gerät befindet. SonicWALL CDP 3440i/4440i Getting Started Guide...

  • Page 37: Copyright Notice

    Copyright Notice © 2006 SonicWALL, Inc. All rights reserved. Under the copyright laws, this manual or the software described within, can not be copied, in whole or part, without the written consent of the manufacturer, except in the normal use of the software to make a backup copy. The same proprietary and copyright notices must be affixed to any permitted copies as were affixed to the original.
  • Page 38 Trademarks SonicWALL is a registered trademark of SonicWALL, Inc. Microsoft Windows 98, Windows NT, Windows 2000, Windows XP, Windows Server 2003, Internet Explorer, and Active Directory are trademarks or registered trademarks of Microsoft Corporation. Netscape is a registered trademark of Netscape Communications Corporation in the U.S.
  • Page 39 Notes Page 38...
  • Page 40 Notes SonicWALL CDP 3440i/4440i Getting Started Guide Page 39...
  • Page 41 F +1 408.745.9300 www.sonicwall.com PN: 232-000971-01 Rev A ©2006 SonicWALL, Inc. is a registered trademark of SonicWALL, Inc. Other product names mentioned herein may be trademarks and/or registered trademarks of their respective companies. Speci cations and descriptions subject to change without notice.
