Spytec Inventio-HD Pro User Manual

www.spytecinc.com

Storage

A. The Inventio-HD Pro supports up to 32GB
microSD cards. MicroSD cards with a speed
of Class 6 or higher are strongly recom-
mended for optimal video quality.
B. When your microSD card is full, the Inven-
tio-HD Pro blue LED light will light up for
1-2 seconds. At this point, the Inventio-HD
Pro will automatically save all data and
power off.

Battery

A. To charge the Inventio-HD Pro battery,
connect the Inventio-HD Pro to a computer
or AC adaptor using the enclosed cables.
B. A red LED light will appear, indicating that
the battery is successfully charging. It
should require approximately 3-4 hours to
fully charge your Inventio-HD Pro.
C. A green LED light will appear when the
battery is fully charged.
* If the Inventio-HD Pro is unresponsive or the blue LED light
blinks rapidly, this is often an indication that the battery needs
to be charged

Troubleshootings

Symptom Possible Reason Solution
Fail to start Low Power Recharge Battery
System Halted Reset, then start
again
Auto shut off Low Power Recharge battery
Green LED flash
Device can not USB Cable failure Replace new cable
be recognized by
PC Bios disabled Set USB enabled
computer
Main board does not sup- Update mainboard
port USB port driver
Data not Saving Memory is full Remove video files
Power off automati- Low Power Recharge
cally after starting
Memory is full Remove Video files

Specifications

Product size 6 x 1.5 x 2in. (folded)
USB 2.0(HS)
Physical Weight 2oz
Resolution 1920x1080P@30fps 1280x720P @60fps
Power Supply Embedded 550mAH Li-polymer Battery
Video Format Mov/H.264
Pixels 5 mega
Power Duration about 1 hour
Memory Support Max High Speed 32gb TF card
Power Consumption <1.5W
Audio Stereo
Working Temp 23 °F to 104 °F
Storage Temp 4 °F to 158 °F
Fov 135 degree
Menu Language English
Player VLC, Media player, Real Player, Quicktime
Operating System win7, WinXP, Windows Vista, Mac Os 10.7
USER MANUAL
