- Page 2 The CM9088 is packed with numerous features that will enable you to bring the joy of the great outdoors into your home, so please make sure to begin by reading through this manual in order to get the most out of your new weather station.
-
Page 3: Table Of Contents
CM9088 Wireless Desktop Weather Station Contents What’s in the Box?................. Page 3 Features....................Page 4 Setup Guide..................... Page 5 3.1 Battery Installation ..............Pages 5 & 6 3.2 Sensor Installation..............Pages 6 & 7 Display Console ................Pages 7 & 8 4.1 Weather Forecasting ................. -
Page 4: What's In The Box
CM9088 Wireless Desktop Weather Station 1. What’s in the Box? > Weather Console > Remote Sensor with Mounting Bracket > Instruction Manual You May Also Need: > Three AA batteries for the weather console > Two AAA batteries for the outdoor sensor >... -
Page 5: Features
CM9088 Wireless Desktop Weather Station 2. Features Wireless Outdoor and Indoor Temperature (°F or °C) Wireless Outdoor and Indoor Humidity (%RH) Records Min and Max Temperature Records Min and Max Humidity Barometric Pressure 24-hour History Graph (inHg or hPa) Weather Tendency Arrow... -
Page 6: Setup Guide
CM9088 Wireless Desktop Weather Station 3. Setup Guide 3.1 Battery Installation: Note: To avoid operating problems, please take note of battery polarity be- fore/when inserting any Alkaline Batteries (permanent damaged could be introduced by inserting the battery in wrong direction). Use good quality Alkaline Batteries and avoid rechargeable batteries. -
Page 7: Sensor Installation
CM9088 Wireless Desktop Weather Station 3.1 Battery Installation Continued: Note: Please make sure not to press any keys during the initial learning-period – if a key is pressed before the station receives the temperature signal, you will need to follow the battery installation procedure again. - Page 8 CM9088 Wireless Desktop Weather Station 3.2 Sensor Installation Continued: 2) Remote sensor Note: To achieve a true temperature reading, please try to avoid mounting the remote sensor in direct sunlight. The outer casing of the sensor could potentially heat up and then take time to cool again, resulting in false temperature readings.
- Page 9 CM9088 Wireless Desktop Weather Station 4. Display Console Continued Weather forecast icon low battery indicator MIN/MAX information Sunrise time Moon phase indicator Sunset time Indoor temperature low / high alarm Indoor temperature display Temperature display unit 10. Indoor humidity display 11.
-
Page 10: Weather Forecasting
CM9088 Wireless Desktop Weather Station 4.1 Weather Forecasting: The four weather icons Sunny, Partly Cloudy, Cloudy and Rainy are used for weather forecasting. There are also two weather tendency indicators to show the air pressure tendency between the displayed weather icons. The weather forecasting is calculated from the changing air pressure. -
Page 11: Program Mode
CM9088 Wireless Desktop Weather Station 5. Program Mode The display console uses five keys for operation: SET, ALARM, MIN/MAX, + and SNOOZE/LIGHT. There are also four program modes available: Quick Display Mode, Setting Mode, Alarm Mode and Min/Max Mode. The selected program mode can be exited at any time by either pressing the SNOOZE/LIGHT key, or simply pressing no keys and waiting for the 10-second time-out to take effect. - Page 12 CM9088 Wireless Desktop Weather Station 5.2 Setting Mode Continued: The following table provides times zones throughout the world. Locations in the eastern hemisphere are positive, and locations in the western hemisphere are negative. Hours Time Zone Cities from GMT IDLW: International Date Line West...
- Page 13 CM9088 Wireless Desktop Weather Station 5.2 Setting Mode Continued: 12/24 hour format. Press the SET key again to adjust the 12/24 hour format setting. Press the + key to change between 12 hour and 24 hour format. Latitude Location. Press the SET key again to adjust the Northern and Southern Hemisphere settings.
- Page 14 CM9088 Wireless Desktop Weather Station 5.2 Setting Mode Continued: Calendar setting (year /month /date). Press the SET key again to set the calendar year. Press the + key or MIN/MAX key to adjust the calendar year. Press the SET key again to set the calendar month. Press the + key or MIN/MAX key to adjust the calendar month.
-
Page 15: Setting Calibrated Humidity
CM9088 Wireless Desktop Weather Station 5.2 Setting Mode Continued: 14) Relative pressure setting from 700hPa – 1100hPa (default 1013.5hPa). Press the SET key to adjust the relative barometric pressure. Press the + key or MIN/MAX key to adjust the relative barometric pressure up or down. -
Page 16: Setting Barometric Pressure
CM9088 Wireless Desktop Weather Station 5.4 Setting Barometric Pressure: The display console displays two different pressures: absolute (measured) and relative (corrected to height above sea-level). To compare pressure conditions from one location to another, meteorologists correct pressure to sea-level conditions. Because the air pressure decreases as you rise in altitude, the sea-level corrected pressure is generally higher than your measured pressure. - Page 17 CM9088 Wireless Desktop Weather Station 5.5 Alarm Mode Continued: While In the High Alarm Mode, press the SET key to scroll through the following alarm modes: Time alarm (hour/minute) Indoor humidity/high alarm Indoor temperature high alarm Outdoor humidity high alarm...
- Page 18 CM9088 Wireless Desktop Weather Station 5.5 Alarm Mode Continued: The Outdoor Weather Alarm When an outdoor weather alarm has been triggered it will flash on the LCD display. The primary outdoor alarm icon and high/low alarm icon will also flash accordingly.
-
Page 19: Sunrise And Sunset
CM9088 Wireless Desktop Weather Station 5.7 Sunrise and Sunset: To determine your longitude and latitude,we recommend the following website: www.bing.com/maps Reference Figure 5 below: Enter your address and select the search button The latitude (first number) and longitude (second number) are returned. -
Page 20: Minimum/Maximum Mode
CM9088 Wireless Desktop Weather Station 5.8 Minimum/Maximum Mode: While in Normal Mode, press the MIN/MAX key to enter the maximum mode. The MAX logo and the general Max record will then be displayed. Press the MIN/MAX key again to enter the minimum mode. The MIN icon and minimum record will now be displayed instead. -
Page 21: Support
CM9088 Wireless Desktop Weather Station 6. Support Problem Cause Remedy Your time zone is set to You will need to set the My stations clock is an default. time zone. hour fast. TO SET THE TIME ZONE 1) Press and hold the SET button for at least 10 seconds. -
Page 22: Support .......................................................................................
CM9088 Wireless Desktop Weather Station Support Continued Problem Cause Remedy My weather tendency The number in which You will need to set the is not showing any your barometric barometric pressure change or is changing pressure threshold is threshold. too often. -
Page 23: Product Specification
CM9088 Wireless Desktop Weather Station 7. Product Specification Outdoor data Transmission distance in open field 100 meters max Frequency 433MHz Temperature range -40°C to +65°C (show OFL if outside range) Resolution 0.1°C Measuring range rel. humidity 20%～95% Humidity accuracy +/-5% under 0-45°C...
Need help?
Do you have a question about the CM9088 and is the answer not in the manual?
Questions and answers
The sunrise/ sunset remain wrong even when the latitude/longitube & date / time are correct (device Climemet CM9088)
The sunrise/sunset time on the ClimeMET CM9088 may be incorrect even with correct latitude, longitude, and date/time settings if the time zone is not set to 0 for the UK or if the console has not yet updated to the correct time after the time zone adjustment. The displayed time affects the sunrise and sunset times, so it’s important to wait for the console to pick up the correct time after changes.
This answer is automatically generated
Outdoor temperature and humidity not reading on display even when I bring the sensor close.
The ClimeMET CM9088 outdoor temperature and humidity sensor may not display readings even when close to the display if the sensor and display console are not properly synchronized. This can happen after changing the batteries. Each time the remote sensor is powered on, it sends a new random security code that the display must recognize. To fix this, remove all batteries from both the sensor and console, wait one minute, then reinsert all batteries within 30 seconds. This allows the display to re-learn the transmitter and receive data.
This answer is automatically generated
CHANGE UNITS IMPERIAL TO DECIMAL
To change the units on the ClimeMET CM9088, press the SET key to toggle between different measurement units. For air pressure, you can switch between hPa and inHg by pressing the SET key again. For further unit adjustments, refer to the manual.
This answer is automatically generated
