Summary of Contents for ECO Charger EC-90
- Page 1 OWNERS MANUAL EC-90 BATTERY SYSTEM PO BOX 956 Boulder, CO 80306 web: www.ecocharge.com voice: 303.449.5761 fax: 303.449.1545 © Copyright 2002, Eco-Charge LLC...
- Page 2 With the advent of hundreds of portable electronic devices, each with different and demanding power requirements, battery power can be confusing to say the least. The EC-90 offers the user new features to make life in the field easier and more convenient.
- Page 3 SPECIFICATIONS BATTERY VOLTAGE BATTERY CAPACITY 7.2A/h CHARGE TIME 8 hours maximum MAX. CURRENT 12V MAX. CURRENT REGULATED MAX. TOTAL BATTERY CURRENT 2.25A DIMENSIONS L6” x W2.75” x H5” WEIGHT 5.5 lbs. TECHNICAL FEATURES AUTO SHUT OFF This feature is designed to protect the battery from deep discharge and maximize battery life.
- Page 4 “CHARGER IN” connector. REGULATED OUTPUT The dual voltage EC-90 uses a high efficiency switch mode regulator to provide 6V or 7.5V output from the 12 volt battery. This regulator has a maximum output current of 2 Amperes. The switch mode regulator is activated when the proper power cable is connected to the XLR output.
- Page 5 Make sure to use the correct power cable for your application. First, engage and lock the male XLR connector on the power cable to the correct output connector on the EC-90. Second, connect the mating end of the power cable to the intended device. You are now ready to turn on the device and begin using the EC-90.
- Page 6 OPERATING TIME The operating time for the EC-90 is determined by the total battery current. The total battery current is the sum of the current being drawn from the 12V unregulated output and the regulated output. Since the EC-90 has two outputs, there are many possible output load configurations.
- Page 7 No battery last forever, but Eco-Charge has implemented a battery replacement program that’s as kind to the environment as it is to your wallet. EC-90 batteries can be returned at the end of service life and rebuilt at an affordable price. The top assembly is reused to build a new battery while the spent battery is recycled with the SAV-LEAD program.
- Page 8 TRANSPORTATION All Eco-Charge batteries are unregulated for air transportation because they meet the requirements of Special Provision--”A67” as promulgated by the International Civil Aviation Association (IATA) and the International Civil Aviation Association (ICAO). They also meet the Vibration and Pressure Differential Tests of the International Maritime Dangerous Goods (IMDG) regulations.
