RouterBOARD 751 series

User's Manual

Copyright and Warranty Information

Copyright and Trademarks. Copyright MikroTikls SIA. This manual
contains information protected by copyright law. No part of it may be
reproduced or transmitted in any form without prior written
permission from the copyright holder. RouterBOARD, RouterOS,
RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All
trademarks and registered trademarks appearing in this manual are
the property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of fifteen (15) months from the
shipping date to be free of defects in materials and workmanship under normal use and service, except in case
of damage caused by mechanical, electrical or other accidental or intended damages caused by improper use
or due to wind, rain, fire or other acts of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization)
procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA
process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company
regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your
equipment directly from MikroTik in Latvia.
2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for
RB1000, RB1100, RB1200.
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to
the sender at sender's cost.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
Manual. This manual is provided "as is" without a warranty of any kind, expressed or implied, including, but
not limited to, the implied warranty of merchantability and fitness for a particular purpose. The manufacturer
has made every effort to ensure the accuracy of the contents of this manual; however, it is possible that it may
contain technical inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found
in this publication, nor for direct or indirect, incidental, consequential or other damages that may result from
such an inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to
support@mikrotik.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RouterBoard 751 series and is the answer not in the manual?

Questions and answers

Summary of Contents for RMA RouterBoard 751 series

  • Page 1 To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process.
  • Page 2: Table Of Contents

    USER'S MANUAL ................................1 COPYRIGHT AND WARRANTY INFORMATION ........................1 SYSTEM BOARD VIEW AND LAYOUT ..........................3 SPECIFICATIONS ................................3 HARDWARE GUIDE ................................4 ..............................4 EMORY AND TORAGE EVICES Memory .................................... 4 Storage Device ................................. 4 ................................4 NPUT UTPUT ORTS Ethernet ports ..................................
  • Page 3: System Board View And Layout

    RouterBOARD 751 Series User's Manual System Board View and Layout You can download the board dimensions and case design files (PDF and DXF) from www.routerboard.com Specifications RouterBOARD 751U-2HnD / RouterBOARD 751G-2HnD AR7241 400MHz Memory 32MB DDR SDRAM onboard Boot loader...
  • Page 4: Hardware Guide

    RouterOS RouterOS v5, Level4 license Wireless specifications Wireless Integrated Wireless 2.4GHz 802.11b/g/n 2x2 MIMO Antenna 2x2 MIMO PIF antennas, max gain 2.5dBi, external MMCX option RX Sensitivity 802.11g: -96dBm (6Mbit/s) to -81dBm (54Mbit/s) 802.11n: –96 dBm (MCS0) to –78 dBm (MCS7) TX Power 802.11g: 30dBm (6Mbps) to 27dBm (54Mbps) 802.11n: 30dBm (MCS0) to 26dBm (MCS7)
  • Page 5: Booting From Network

    TFTP server address and boot image name Operating System Support MikroTik RouterOS starting from version v5 is fully compatible with RouterBOARD 751 series devices. If your device is preinstalled with an earlier RouterOS release, please upgrade RouterOS to v5.8 or newer.
  • Page 6: Onfiguration

    Buttons and Jumpers  RouterOS reset jumper hole (on the bottom of case) – resets RouterOS software to defaults. Must short circuit the metallic sides of the hole with a screwdriver and boot the device. Hold screwdriver in place until RouterOS configuration is cleared. ...
  • Page 7: Routeros Functions

    RouterBOARD 751 Series User's Manual The Primary boot loader has the default settings, which can not be changed. It is also not possible to upgrade RouterOS functions The default OS of RouterBOARD devices is RouterOS, when the routerboard.npk package is installed, RouterOS...
  • Page 8: Ethernet Cables

    Button Index Buttons and Jumpers Software Reset 1 button. (see ” ”) Buttons and Jumpers RESET Software Reset 2 jumper hole. Resets RouterOS settings (see „ ”) (unlabeled) Ethernet Cables RJ45 Color Function Function RJ45 pin for Straight cable RJ45 pin for Crossover cable (100Mbit) (1Gbit) (MDI, EIA/TIA568A)
