Summary of Contents for Advanced Technology Video DYK-14G
- Page 1 迷你可攜式監控錄放影機組 M i n i S e c u r i t y R e c o r d e r U S E R M A N U A L Ver.: 1.0, P/N: R040110/2...
-
Page 2: Table Of Contents
Contents 1. SAFETY PRECAUTIONS ......................... 1 2. FEATURES ............................2 3. PACKING LIST ..........................3 4. NAME and FUNCTION of EACH PART..................4 4.1 Front View ............................ 4 4.2 Side View ............................. 5 5. Basic Configuration ..........................6 6. Operation ............................7 6.1 Power On ............................ -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. It is advised to read the Safety Precaution Guide through carefully before operating the product, to prevent any possible danger. -
Page 4: Features
2. FEATURES The DVR supports NTSC or PAL video system, and auto detects video loss. The DVR is built-in with MPEG4-SP video and G.726 audio codec. It supports 1 channel video and 1 channel audio recording and playback operation. ... -
Page 5: Packing List
3. PACKING LIST Check to make sure all of the items shown below are included in your Portable Security Recorder Kit. If something is missing, contact your dealer as soon as possible. Item Description Item Picture Mini Portable Security Recorder Audio/ Video Cable Power Adaptor DC 12V/ 410mA Input: AC 100~240V... -
Page 6: Name And Function Of Each Part
4. NAME and FUNCTION of EACH PART 4.1 Front View Po we r Pl ay Me nu /Lo ck Re c S to p /E x it R ec En te r Di sp lay Pl ay /Pa use Me nu P o w e r P l a y M e n u / L o c k... -
Page 7: Side View
4.2 Side View (15) AV IN: Audio/ Video Input Video In (yellow) AV In Audio In (white) Audio/Video IN: 3.5 mm jack for audio/ video line in. (16) AV OUT: Audio/ Video Output Video Out (yellow) AV Out Audio Out (white) Audio/Video OUT: 3.5 mm ... -
Page 8: Basic Configuration
5. BASIC CONFIGURATION 1. Power: Use the power adaptor supplied, nickel metal hydride (NiMH), alkaline batteries. 2. Video System: Connect the camera, the device auto detects NTSC/ PAL video system (the output video system will be setup the same as its input video system). Without connecting the camera, the video system setup will be the same as its previous setup. -
Page 9: Operation
6. OPERATION 6.1 Power On 1. The power switch is situated on the right side of the device, switch to DC when using the supplied power adaptor or switch to BATT when using battery. NOTE: Each time after power-on, the system auto-detects its peripherals. When the REC LED flashes indicates that the SD card is proceeding testing (complete boot time is several seconds) When an image file error has been detected, the system will initiate auto repairing. -
Page 10: Record Mode
SD Card Status: ： SD Card has not been inserted or malfunction. ： SD Card is proceeding file testing. ： SD Card is functioning normally. ： Disk full and overwrite record. When SD card is not inserted, record and playback function is inapplicable, but monitoring is applicable. -
Page 11: Playback Mode
4. The event status is determined by the system recording, according to the order of priority. 5. The order of priority: Manual Record, Motion Detection and then Schedule Record. 6. Different recording modes may have different kinds of setups. Basic setup: video size, recording frames, video quality, and audio recording. -
Page 12: Pc Playback
Press《Stop》button to stop playback function and to return to live status. (2) Search and Playback: Enter MENU and select【SEARCH AND PLAY】item. S E A R C H A N D P L A Y ■ ■ D A T E L E S ... -
Page 13: Sd Card Maintenance
6.6 SD Card Maintenance 1. The device supports only FAT16/ 32 file system; therefore it is unable to determine other file systems. Please format the SD card (enter 【 MENU/ SD CARD OPTIONS】 and select “Format”). 2. The system supports only partial SD card file system repair. The system is unable to detect any file system damage, therefore please format the SD card (enter【MENU/ SD CARD OPTIONS】and select “Format”). -
Page 14: Menu Setup
7. MENU SETUP 7.1 Main Menu M E N U ¡ ½ S E A R C H A N D P L A Y > S E T D A T E I M E > S E T M O T I O N... -
Page 15: Motion Detection
7.3 Motion Detection 1. Window setup: ■ ■ ■ A R E A M O D E C E L L M O D E P L A Y Detection Cell: Whole screen is divided into 22x15 square cells. Detection Block: Two or more cells form a block. -
Page 16: Manual Record & Schedule Record
Sensitivity Bar ： Color black indicates image variable value and color red indicates the MD threshold. ： Current image variation value. MD Energy MD Threshold ： Press《》 or《》button, to change the motion detection threshold value. 7.4 Manual Record & Schedule Record Selectable manual or schedule recording, basic setups are shown below: 1. -
Page 17: Sd Card Options
： Enable or disable schedule recording (ON/ OFF). RECORD SCHEDULE ： ab:cd – ab:cd = 24 hour recording and 00:00 – 00:01 = Record of one minute image from 00:00 to 00:01. Motion Detection Recording DURATION TIME Setup: DURATION ： Duration time when motion detection has been triggered (5SEC / 10SEC / 15SEC/ 20SEC / 30SEC). -
Page 18: System Status
⑤ FORMAT ： All recordings will be deleted and creates a dvr directory under root directory ( NOTE 3 ⑥ SD UNMOUNT ： Switch off the recording and perform the removal process before withdrawing the SD Card. NOTE 1: Proceeding continuous recording, old videos can be deleted and overwritten. Please confirm before setup. -
Page 19: Trouble Shooting
8. TROUBLE SHOOTING Q1. Does the product support SDHC 32G? A1. Suggested tested brands are as shown below: Brand Capacity Specification A-DATA Class 6 Transcend Class6 Silicon-Power Class6 Apacer Class4 Kingston Class4... -
Page 20: Specification
9. SPECIFICATION System NTSC / PAL Video System and Video Loss Auto Detection Codec MPEG4-SP ASF File Format 1, 2, … , Maximum fps selectable Maximum: Record Frame Rate NTSC: 30 fps@352x240/ 24 fps@704x240/ 12 fps@704x480 PAL: 25 fps@352x280/ 20 fps@704x280/ 10 fps@704x560 Record Quality Low / Medium / High Frame Rate@...
