Ref: HVBTR4800-002
HVBTR-4800
OLIN Products:
HVBTR‐4800 – Recording to external USB HDD.
This document is a supplement to the HVBTR-4800 User Guide.
Connecting the external USB HDD
(For more information on the types of External USB Hard Disc Drives, refer to HVBTR1200-003C.pdf - HVBTR-
1200 / HVBTR-1400 / HVBTR-1600 / HVBTR-4800 - External drive and Flash Drive support notes under the
Product FAQs on
www.olinlivenow.com.au
)
HVBTR-4800
Connect USB HDD to the USB port on the front of the unit.
Light on the HDD should indicate power.
The HVBTR-4800 should recognise the USB HDD and display on screen – USB device is inserted.



Advertisement

loading
Need help?

Need help?

Do you have a question about the HVBTR?4800 and is the answer not in the manual?

Questions and answers

Related Manuals for Olin HVBTR?4800

Summary of Contents for Olin HVBTR?4800

  • Page 1                                                                        Ref: HVBTR4800-002 HVBTR-4800 OLIN Products: HVBTR‐4800 – Recording to external USB HDD.  This document is a supplement to the HVBTR-4800 User Guide. Connecting the external USB HDD (For more information on the types of External USB Hard Disc Drives, refer to HVBTR1200-003C.pdf - HVBTR-...
  • Page 2 A recording symbol appears in the top left corner showing the progress. Press INFO key on the top line of the RCU to display detailed information about the recording and your USB ext HDD. Press INFO key again to clear the detailed information. HVBTR4800‐002  2 | P a g e  ...
  • Page 3 Example of same LCN would be ONE HD / TEN Digital / ELEVEN or 7 Digital / 7TWO / 7mate and so on. You would need to check your local transmission information for LCN details. HVBTR4800‐002  3 | P a g e  ...
  • Page 4 TIP: EPG is not always up to date and does not always take into account program overruns and so on. You may want to change the Start Time to a few minutes earlier to allow for early starts and the Finish Time to a few minutes later to allow for the program running over. HVBTR4800‐002  4 | P a g e  ...
  • Page 5 (Manual Page 25) Useful if you know what time your program is on and you want to set options outside of the EPG information. Press the EPG key to open the Program Guide: HVBTR4800‐002  5 | P a g e    ...
  • Page 6 Change the Start Time and End Time to the appropriate times. In the example below the short kids program runs from 17:00 to 17:11. The Start Time has been set a little earlier and the End Time a little later to make sure the whole program is recorded. HVBTR4800‐002  6 | P a g e  ...
  • Page 7 Press EPG key to enter the EPG screen. Press INFO key to enter the Schedule screen. This screen will show all your scheduled recordings eg: Recordings or Events can be added, edited or deleted from this screen. HVBTR4800‐002  7 | P a g e  ...
  • Page 8 The message Enter Record,Waiting and a timer will display on the screen. The timer will increase through the recording: When the recording has finished you will see the message Recording Complete. Press RETURN/EXIT key to return to normal viewing. HVBTR4800‐002  8 | P a g e    ...

  • Page 9: Playback Recorded Program

    Press OK key and the recorded programs will be displayed. The recording filename shows the station recorded – date of recording – time recording started. Press OK key to show the preview. The preview screen shows the length of the recording and the file size. HVBTR4800‐002  9 | P a g e  ...
  • Page 10 Includes the same information as the Preview screen plus Scan Type (resolution) and Frame Rate. The Time function is very useful when fast forwarding etc. Press INFO key again to clear the information from the screen. HVBTR4800‐002  10 | P a g e  ...
  • Page 11 From the recorded program screen, press the green key to Rename the recording. Use the arrow keys and OK key to type in the new name. OK on the screen with the OK key on the controller to save the new name. HVBTR4800‐002  11 | P a g e  ...

  • Page 12: Appendix A. Time Shifting Live Tv - Recording Via Time Shift

    PVRRECORD folder described earlier in this guide. This includes reviewing, renaming, deleting and so on. Press the USB key and choose Multimedia / PVR. There will be two folders – PVRRECORD and TIMESHIFT: HVBTR4800‐002  12 | P a g e  ...

  • Page 13: File Deleting

    Multimedia / PVR. Select the TIMESHIFT folder and press the OK key. Then choose the program you wish to delete: Press Yellow key to mark the recording for deletion. Press OK key to confirm the deletion HVBTR4800‐002  13 | P a g e  ...
  • Page 14 PVRRECORD or TIMESHIFT folders can be deleted. Example: deleting the TIMESHIFT folder Note: deleting the folder will delete ALL the recordings in that folder. Also note that the PVRRECORD or TIMESHIFT folders will be recreated next time you do a recording or time shift. HVBTR4800‐002  14 | P a g e  ...
