- Page 1 INSTALLATION GUIDE Mounting & Sealing of Housing & Electrical Details S-Type COOLDOME™ ENCLOSURE ST-CD (12V DC) ST-CD-24V (DC) COOLDOME™ Enclosures...
-
Page 2: Limited Warranty
LIMITATION OF LIABILITY THE LIABILITY OF DOTWORKZ SYSTEMS, IF ANY, AND PURCHASER'S SOLE AND EXCLUSIVE REMEDY FOR DAMAGES FOR ANY CLAIM OF ANY KIND WH ATSOEVER, REGARDLESS OF THE LEGAL THEORY AND WHETHER ARISING IN TORT DP CONTRACT SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE OF THE PRODUCT WITH RESPECT TO WHICH SUCH CLAIM IS MADE. IN NO EVENT SHALL DOTWORKZ SYSTEMS BE LIABLE TO PURCHASER FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND INCLUDING BUT NOT LIMITED TO COMPENSATION, REIMBURSEMENT OR DAMAGES ON ACCOUNT OF THE LOSS OF PRESENT OR PROSPECTIVE PROFITS, OR FOR ANY OTHER REASON WHATSOEVER. - Page 3 2. These Installation and Operating Instructions. For technical questions or product returns – call Dotworkz Customer Service (866-575-4689) 7:30 AM to 4:30 PM (PST). The proper technician will contact you as soon as possible. ...
-
Page 4: Electrical Conduit Guidelines
Electrical Putty & Putty Tapes Dotworkz does not endorse, nor has it evaluated any of these products. Test products first, and follow all manufacturers’ instructions. Follow all applicable electrical and building codes and installation guidelines. End user assumes liability for applicability of these products and... - Page 5 VENT STOPPER PLUGS for Conduit Foam Conduit Feed Plugs for ½” I.D. Conduit Prevents Humid Air exchange from venting thru electrical conduit into Dotworkz sealed enclosure. Thus eliminating condensation issues within Dotworkz sealed enclosures. QUICK INSTALLATION GUIDE 4) Push plug into conduit mouth with finger 1) Pull wires to final installed length.
- Page 6 All Cable Ports, wire feeds, or Conduit must be fully sealed to eliminate moisture within Enclosure. All Dotworkz Enclosures are required to be fully sealed before placing into service, to protect integrated products, to eliminate any moisture driven shock hazard, to perform optimally as designed.
- Page 7 Component Check List & Standard Hardware: S-Type Models ST-HB-MVP Models ST-HB-Solar ST-TR-MVP models ST-RF-MVP models ST-CD models Included in S-Type Package 1 - S-Type Enclosure Housing (1) 2 – Mounting Arm for Wall Mounting (1) 3 – Cable Gland Seals, pre-installed (2) 4 –...
- Page 8 Tools recommended for Enclosure & camera mounting Hand Tools Drill & Bits Pole Strapping Tools Hand Tools - #1 & #2 Phillips head screw driver -#1 Flat Blade screw driver or smaller - 7/16" Socket wrench, or box / open end wrench, or adjustable wrench - 9/16"...
- Page 9 Mounting S-Type Enclosure Attaching Enclosure to Dotworkz Strong-Arm: Provided on S-Type equipment for Ring of Fire™ & COOLDOME models™ Locate & assemble four ¼”-20 x 5/8” hex bolts with lock washers provided in hardware pack of Strong-Arm. Turn over S-Type housing to show threaded base inserts, pre-install four ¼” diameter bolts in Tilt head of Strong-Arm. Note orientation of tilt locking screws toward rear of S-Type.
- Page 10 S-Type Strong-Arm Mount Wall Mounting Pattern Not to Scale...
- Page 11 Pole Mounting S-Type with Strong-Arm Pre-Install EZ-Lock Pole Mount #BR-MPM1 (sold separately) by following Instructions detailed in Installation Guide provided with pole mount bracket. Pole Mount requires user supplied stainless steel strapping to secure Pole Mount Bracket to the pole, strapping into final desired position.
- Page 12 COOLDOME™ Input Power Configuration: ST-CD-12VDC Provided P/S Must be Site Power Available Housed Indoors, or in a Nema Electrical Enclosure LOW VOLTAGE RUN 12 VDC Cable to COOLDOME 110 – 220 VAC Power Source 250 watt Step Down P/S Single Phase Only High Voltage to 12 VDC Turn Off Power or leave power disconnected during Installation of All Wiring.
- Page 13 24V DC Low Voltage Wire Gage Selector Chart- Per Conductor Pair, Per Cooler...
- Page 14 COOLDOME™ Input Power Configuration: ST-CD-12VDC Warning!!!: COOLDOME Enclosure runs on 12 VDC only! If high voltage is applied directly to COOLDOME™ enclosure, you will damage housing, void warranty, and create electrocution hazard that can be harmful or fatal. Do not start wiring until you have fully read and understand these installation instructions. External Power Supply The output of the S-250-12 external power supply, can be adjusted up and down 10%.
- Page 15 Generic Camera Installation Open enclosure by unscrewing 4 captive phillps screws and open hinge. Remove camera mount plate by unscrewing four philips screw, and loosening 2 front camera plate screws. One ¼”-20 x 3/8” camera mount screw is provided on camera plate; organize camera parts to be installed. Using ¼”...
- Page 16 S-Type COOLDOME Internal Wiring S-Type COOLDOME Before camera & S-Type COOLDOME Power install after power & camera installation- typical Pull power and Data cables into housing thru Cable Gland strain relief seal ports near rear of S-Type enclosure. Strip back wires on Low Voltage 12VDC power cable brought into enclosure, observing DC polarity. With a Volt Meter, Check voltage on wires pulled in from power supply, before attaching wires to assure Low Voltage 12 VDC input wires and proper polarity.
