General integration 75-030 Setup & Operation Manual

14" drill press
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rotating, 45° tilting, crank-operated work-
table with quick release clamp.
Large front mounted stop switch with
lock-out safety feature to prevent unwan-
ted or unintentional start-up.
Adjustable spindle tension return spring.
Built-in lamp illuminates the drilling area.
Spindle is supported by high quality ball
bearings.
Cast-iron pulleys reduce vibration.
Industrial 1/2 HP motor.
Heavy-duty positive depth stop for quick
adjustment.
5/8" drill chuck.
SWING
13
3 ⁄
'' (340 mm)
8
DRILLING CAPACITY
5 ⁄
" (16 mm)
8
CHUCK SIZE
" (16 mm)
5 ⁄
8
SPINDLE TRAVEL
3
1 ⁄
" (80 mm)
8
SPINDLE DISTANCE TO TABLE
15
" (387 mm)
1 ⁄
4
SPINDLE DISTANCE TO BASE
32
1 ⁄
" (819 mm)
4
TABLE SIZE
11
3 ⁄
" (289 mm)
8
COLUMN DIAMETER
2
" (73 mm)
7 ⁄
8
NUMBER OF SPEEDS
12
SPINDLE SPEEDS
280-3000 RPM
SPINDLE TAPER
MT 2
OVERALL HEIGHT
38
1 ⁄
" (978 mm)
2
BASE SIZE
10" x 16
" (254 x 429 mm)
7 ⁄
8
MOTOR
1 ⁄
HP , 110 V, 8 A
2
WEIGHT
105 LBS (48 kg)
VERSION 2 - AUGUST 06/12
© COPYRIGHT GENERAL INTERNATIONAL 08/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 75-030 and is the answer not in the manual?

Questions and answers

Summary of Contents for General integration 75-030

  • Page 1 Rotating, 45° tilting, crank-operated work- table with quick release clamp. Large front mounted stop switch with lock-out safety feature to prevent unwan- ted or unintentional start-up. Adjustable spindle tension return spring. Built-in lamp illuminates the drilling area. Spindle is supported by high quality ball bearings.
  • Page 2 Telephone (514) 326-1161 • Fax (514) 326-5555 • www.general.ca THANK YOU for choosing this General International model 75-030 Drill Press. This drill press has been carefully tested and inspected before shipment and if properly used and maintained, will provide you with years of reliable service. To ensure optimum perform- ance and trouble-free operation, and to get the most from your investment, please take the time to read this manual before assembling, installing and operating the unit.

  • Page 3: Rules For Safe Operation

    Rules for Safe Operation To help ensure safe operation, please take a moment to learn the machine’s applications and limita- tions, as well as potential hazards. General® International disclaims any real or implied warranty and holds itself harmless for any injury that may result from improper use of its equipment. 1.

  • Page 4: Installing The Chuck

    14” DRILL PRESS 75-030 A S S E M B LY I N S T R U C T I O N S Before proceeding with the assembly, read the operating and maintenance instructions manual and familiarize yourself with correct assembly, setup, maintenance and safety procedures.

  • Page 5: Adjustments And Controls

    CONNECTING TO A POWER SOURCE Plug the drill into a proper receptacle. Your power tools should be connected to a dedicated electrical circuit of not less than #14 wire and should be protected with a 15 amp time lag fuse. If an extension cord is needed, use only 3-wire cords with 3-prong grounded-type plugs and 3-pole receptacles.

  • Page 6: Adjusting Table Height

    TABLE SWING ADJUSTMENT TABLE ROTATION ADJUSTMENT ADJUSTING TABLE HEIGHT Loosen column lock handle (1). Loosen the column lock Loosen the table lock handle (3). handle (1). Swing the table arm bracket and Rotate the table to the desired the table to the desired position. Turn the crank handle (2) position.

  • Page 7: Cutting Speed

    CHANGING SPEEDS MAKE SURE THE DRILL PRESS HAS COME TO A COMPLETE STOP BEFORE CHANGING SPEEDS. REFER TO THE SPINDLE SPEED SELECTION CHART LOCATED ON THE INSIDE OF THE SPINDLE COVER. Disconnect the drill press from the power source. Loosen the slide bar bolt (1) located on the right side of the head. Pull the motor (2) in towards the head to loosen the belts.

  • Page 8: Recommended Optional Accessories

    RECOMMENDED OPTIONAL ACCESSORIES We offer a large variety of products to help you increase convenience, productivity, accuracy and safety when using your drill press Here’s a small sampling of optional accessories available from your local General International dealer. For more information about our products, please visit our website at www.general.ca 25 PIECE - RUBBER DRUM ABRASIVE SLEEVES SANDING SET...
  • Page 9 PARTS LIST 75-030 PART N0. DESCRIPTION 75025-01 BASE 75125-02 WASHER 75125-03 BOLT 75025-04 BASE FLANGE 75125-05 SCREW 75125-06 CRANK SLEEVE HANDLE 75125-07 TABLE BRACKET 75125-07-1 TILT SCALE 75125-08 GEAR SHAFT 75125-09 HELICAL GEAR 75125-10 ELEVATING WORM 1/2 75125-11 CLAMP BOLT...

  • Page 10: Parts List

    PARTS LIST 75-030 PART N0. DESCRIPTION 75125-43 BEARING 75125-44 SNAP RING 75125-45 BEARING 75125-46 QUILL GASKET 75125-47 QUILL 75125-48 BEARING 75125-49 SUPPORT / CLAMP SEAT DEPTH STOP 75125-49-1 75125-50 SCREW 75125-51 SPINDLE 75125-52 DRIFT KEY 75125-53 ARBOR 75125-54 CHUCK 75125-55...
  • Page 11 DIAGRAM SIDE A 85(2) 77(2) 40-1 40-1 32-1 58(2) 30(2) 29(4) 56(2) 28-1 26-1 36(3) 26-2 35-2N 35-1N 39(3) 23(3) 22(3) 49-1 12-1 3(4) 2(4)
  • Page 12 75-030 8360, Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Tel.: (514) 326-1161 Fax : (514) 326-5565 Parts & Service Fax : (514) 326-5555 Order Desk orderdesk@general.ca www.general.ca IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity...
