COVERT-
SYSTEMS.COM
928-759-2121
DTMF
RS-485
Pelco P or D
LAW
LAW
ENFORCEMENT
ENFORCEMENT
PRODUCTS
PRODUCTS
Covert
Covert-Systems.com
DTMF Control System
Operations Manual
SurvDome
Operation's Manual
Controlled Using
Covert-Systems.com
CS-RS485
Interceptor Module
Pelco D&P Extended Codes
Rapid SurvDome OSD Codes
& Rapid Presets Setup
Systems. com, 12305 Triple T Lane, Prescott Valley, AZ 86314
CS-RS485-Interceptor
With
CS-485-Interceptor_Flyer.pdf
Advertisement
Related Manuals for Covert Systems SurvDome
Summary of Contents for Covert Systems SurvDome
- Page 1 Pelco P or D SurvDome Operation's Manual Controlled Using Covert-Systems.com CS-RS485 Interceptor Module With Pelco D&P Extended Codes Rapid SurvDome OSD Codes & Rapid Presets Setup ENFORCEMENT ENFORCEMENT PRODUCTS PRODUCTS Covert Systems. com, 12305 Triple T Lane, Prescott Valley, AZ 86314 Covert-Systems.com...
- Page 2 Pan, Tilt, Zoom, Focus or Iris Control on any Pelco D or Pelco P device Including all current extended codes With rapid OSD access codes for Covert Systems *SurvDome including Battery BU Real Time Clock and ID Line Automated Codes Plus standard Baud rate selection Dimensions: 4.3 x 2.9 x 1.0"...
-
Page 3: Block Diagram
COVERT- SurvDome Setup SYSTEMS.COM BLOCK DIAGRAM CS-RS485-Interceptor 928-759-2121 SurvDome KSC-260Z KSC-300Z SurvDome VIDEO RS485 CONTROL ENFORCEMENT ENFORCEMENT Note: PRODUCTS PRODUCTS All equipment is 12VDC Powered User Defined RS485 Functionality Available Covert Systems. com, 12305 Triple T Lane, Prescott Valley, AZ 86314 Covert-Systems.com... -
Page 4: Radio Control
COVERT- Radio Control SYSTEMS.COM BLOCK DIAGRAM CS-RS485-Interceptor 928-759-2121 Video Transmitter KST-1550 SurvDome KSC-260Z KSC-300Z SurvDome VIDEO Control Receiver VHF or UHF DTMF RS485 CONTROL SWITCHED POWER TRANSMITTER 12VDC IN ENFORCEMENT ENFORCEMENT Note: PRODUCTS PRODUCTS All equipment is 12VDC Powered User Defined RS485 Functionality Available Covert Systems. - Page 5 TRANSMITTER SWITCHED PWR 12VDC IN SurvDome KSC-260Z KSC-300Z RS485 FROM SERVER RS485 CONTROL VIDEO TO SERVER Video SurvDome VIDEO VIDEO TO TRANSMITTER ENFORCEMENT ENFORCEMENT Note: PRODUCTS PRODUCTS All equipment is 12VDC Powered User Defined RS485 Functionality Available Covert Systems. com, 12305 Triple T Lane, Prescott Valley, AZ 86314 Covert-Systems.com...
- Page 6 *Note: Trunk Line 2 may be any trunk line connected to the telephone company (previously unused). To operate the SurvDome or Pelco D/P coded device ENFORCEMENT ENFORCEMENT simply switch to that line number. The Interceptor will power the trunk line. Continuous tones must be output...
- Page 7 2. 1111# Power Relay On, 3333# Power Relay Off 3. 3330# Intercept on Tones Only, 3331# Always Intercept Server Control 4. Codes starting with '1' = Non-OSD Functions 5. Codes starting with '3' = SurvDome OSD Functions SINGLE KEY Control Functions '1' Power Relay ON (4 Times) &...
- Page 8 Pelco P or D PRESET Functions (SurvDome preset positons 1 through 31) Pan/Tilt and Zoom SurvDome to each desired position to set presets 14XX# Set Preset number XX (1401# for preset 1) 15XX# Clear Single preset number XX (1509# clears preset 9)
- Page 9 COVERT- SurvDome Setup SYSTEMS.COM Preset Setup Example CS-RS485-Interceptor 928-759-2121 DTMF Rapid Preset Setup Example RS-485 SURV-DOME Pelco P or D Preset Setup Proceedure 1. Zoom out to full zoomed out position, pan & tilting as desired 2. Set preset 1 code by entering 1401# 3.
- Page 10 3. Recall preset 3 code by entering 1603# or QuickCode 13# 4. Recall preset 4 code by entering 1604# or QuickCode 14# 5. To sequence through these images enter Group 1 Code 1301# Group 1 always sequences through Presets 1-4 on SurvDome ENFORCEMENT ENFORCEMENT...
- Page 11 COVERT- SurvDome Setup SYSTEMS.COM Using Group Sequencing CS-RS485-Interceptor 928-759-2121 DTMF Group Sequencing RS-485 SURV-DOME Pelco P or D Preset 1 Preset 2 Preset 3 Preset 4 Group = Presets 1-4 Group = Presets 9-12 Group = Presets 5-8 Group = Presets 13-16 Code 1301# &...
- Page 12 COVERT- SurvDome Setup SYSTEMS.COM Image Reversal Codes CS-RS485-Interceptor 928-759-2121 DTMF Image Reversal Codes RS-485 SURV-DOME Pelco P or D Image 1 May be corrected directly to Image 3 by either of these Codes 32846#, 32864#, 38246# or 38264# (3 +...
- Page 13 COVERT- SurvDome Setup SYSTEMS.COM Pan/Tilt Key Reversal Codes CS-RS485-Interceptor 928-759-2121 DTMF Pan/Tilt Key Reversal Codes RS-485 SURV-DOME Pelco P or D Reversing either Pan or Tilt keys is performed the same way as flipping or mirring the image with the exception that a '1' is used in place of the '3' as the first key pressed in the code.
