Table of Contents System Overview.....................1 Important Safety Precautions....................1 Components ....................2 Capacitor Box ....................3 Rear View..........................3 Front View ..........................3 Layout and Installation of Antennas ..............4 Preparation of Installation ......................5 Positioning and Fixing Antennas....................5 Connection of System ......................5 Capacitance Matching......................
System Overview Floor antenna system consists of three parts: Antenna, Controller and Capacitor Box Important Safety Precautions The electronics inside the controller and the antenna is extremely sensitive static electricity. Always discharge yourself by touching ground point before WARNING touching any of the electronics to avoid damage. Electronics are with high voltage, when opening the housing of the controller or the antenna base cover, do not touch with your hands the solder points, the antenna...
Components Antenna AMA2000 Alarm buzzer is not together with the antenna. The buzzer is connected directly connected to controller. Controller AMS3010 Capacitor AMS3011 Cables Power Cable of Controller RS485 RX&TX Cables...
Capacitor Box Rear View Connect to antenna receiver RX1 IN: Connect to antenna transmitter TX1 IN: Up to three antennas can be connected to one capacitor box: RX1/TX1, RX2/TX2, RX3/TX3 Front View Connection to controller receiver RX1 OUT: Connection to controller transmitter TX1 OUT: For other important information of the electronics in the capacitor box see...
Layout and Installation of Antennas Up to three antennas can be connected to one controller and one capacitor box. Please decide number of antennas to be installed according to the specific test range of the floor antenna. 2.0-2.2m Label Hard Tag Detection Detection Detection...
Preparation of Installation Always check the installation site of the end-user before signing any agreement with customer and before final installation. If the antenna has to be very close to big metal frame or big metal part underground, you have to inform the customer that the detection performance of the floor antenna system will be interfered seriously by the metal object and the detection height might not be as high as they expect.
Page 8
TX cable connector into the 【TX OUT】interface on the capacitor box. And connect the other end of the cable with the controller. Note: Try to place the capacitor box together with the controller. Better to use a standard 0.5m cable between the controller and the capacitor box.
Capacitance Matching Transmitting current is observed by an oscilloscope which shall be between 15A to 20A. If the transmitting current was too small, the system would not work properly. Clamping an oscilloscope current probe onto the transmitter red (positive) wires (a pair) connecting to the capacitor box.
Please kindly note that we, Beijing CSS Technologies Development Co., Ltd., do not promise to any partners or customers about the performance of our floor antenna systems. So, you should not promise to your customers as well before on-site investigation and test.
CSS AM Floor System Specifications Electrical AMS-3010 Controller Primary Input........110/220VAC,50-60Hz Primary Power Fuse......3.15/5.0A Current Draw........5.0A@120VAC, 3.15A@230VAC Input Power........450W@120VAC with3 ants 450W@230VAC with 3 ants Operating Frequency......50-60Hz Transmit Burst Duration......1.6ms Transmit Current....... 8 – 16Ao-p Center Frequency......58kHz±200Hz Cap Board Tx/Rx cable.......
