  • Page 1 Digital Writing Pad User Manual...

  • Page 2: Table Of Contents

    Wireless Transmission ................16 4. Instruction of Edu Tab................17 5. Definitions of On Screen Display Control Key........19 5-1 Navigating the OSD Menu ..............19 5-2 OSD Menu on VGA Mode ..............20 5. Revision History ..................22 10" Wireless interactive whiteboard User Manual...

  • Page 3: Product

    10” widescreen display that is user-friendly and requires no practice before operating. 2. Wireless Transmission With a wireless design, 10” wireless interactive whiteboard help you get rid of those annoying cables and it allows maximum distance of data transmission 10 meters.

  • Page 4: Functions

    Enter OSD menu / Select Decrease the value “ ━ ” (minus), or “◄” (Left) Select below function Increase the value “ ┿ ” (plus), or “►” (Right) Select up function No function No function 10" Wireless interactive whiteboard User Manual...

  • Page 5: Hardware Installation

    2. Hardware Installation 2-1 Illustration of Installation ※ To release the battery pack: ※ Battery can be used about 3 hours when it is fully charged. 10" Wireless interactive whiteboard User Manual...

  • Page 6: Install Step By Step

    • Step 7 Pull the Wireless Device Adapter out the PC’s another USB port, and plug it in the Wireless interactive whiteboard’s USB port. • Step 8 The indicator light of Wireless Device Adapter and Wireless PC Adapter start to twinkle.

  • Page 7: Edu Tab Software And Touch Driver

    3. Edu Tab Software and Touch Driver The installation process will automatically run after put the driver CD in the CD-ROM Drive; please select step1 to 6 in the main page accordingly. 10" Wireless interactive whiteboard User Manual...

  • Page 8: Install Microsoft Dot Net Framework

    Select “Step1. Microsoft Dot Net Framework” to begin the installation. Select “I accept the terms of the Enter the installation page. Select “Next” to proceed. License Agreement” and click “Next” to proceed. Installation is complete. Microsoft Dot Net Framework is being installed. 10" Wireless interactive whiteboard User Manual...

  • Page 9: Install Microsoft Xp Tablet Pc Edition Development Kit 1.7

    1.7” to begin the installation. Select “Next” to proceed. Enter the installation page. Select “Everyone who use the Select “I accept the terms in the computer (all users)” and “Next” to license agreement” and “Next” to proceed。 proceed. 10" Wireless interactive whiteboard User Manual...
  • Page 10 Select “Custom” and “Next” to Select “Next” to proceed. proceed. Select “Install” to install the The installation page will be closed software. automatically after the installation is done. 10" Wireless interactive whiteboard User Manual...

  • Page 11: Install Microsoft Xp Tablet Pc Edition 2005 Recognizer Pack (Windows Xp Only)

    Please select “Custom” and “ Next” Select “Next” to proceed after filling to proceed. out Customer Information. Select “Install” to install the software. The installation page will be closed automatically after the installation is done. 10" Wireless interactive whiteboard User Manual...

  • Page 12: Install Touch Driver

    Please select “None” to do 4 point Select “Next” to proceed. calibration when the system starts and select “Next” to proceed. After making sure the USB Touch device is installed correctly, select “OK” to proceed. Select “Next” to proceed. 10" Wireless interactive whiteboard User Manual...
  • Page 13 Select “Next” to proceed. Select “Next” to proceed. The installation page will be closed automatically after the installation is done. 10" Wireless interactive whiteboard User Manual...

  • Page 14: Install Edu Tab Software

    Please select “All users” or “Just After entering the installation page, select “Next” to proceed. me” according to your demand and select “Next” to proceed. Select “Next” to install the Please select “Close” to close the software. installation page. 10" Wireless interactive whiteboard User Manual...

  • Page 15: Click-N-Type Screen Keyboard (Install From Internet)

    Wireless Driver file to proceed. Select language and read the license agreement, select “I Accept” and precede installation Installation page automatically Wireless Driver has been installed in your proceed. computer. 10" Wireless interactive whiteboard User Manual...

  • Page 16: Install Wusb Driver

    WUSB file to proceed. Installation page automatically proceed. If your computer is 64 bits, select “WUSB WinDrivers_×64.exe” which is in the WUSB file to proceed. Choose your geographic location. Installation page automatically proceed. Setup complete 10" Wireless interactive whiteboard User Manual...

  • Page 17: Wireless Transmission

    Step5: Turn your wireless interactive whiteboard on. • Step6: The indicator of both wireless USB dongles (PC/Device Adapter) will start to flashing and the monitor of wireless interactive whiteboard will receive images. The Wireless icon turns to green (The Wireless icon turns to red represent no signal is being received.)

  • Page 18: Instruction Of Edu Tab

    Edu Tab icon to call main page. 4-2 Main page of Digital Writing Pad software: Main Menu Notes Tab* Onscreen Keyboard Hotkeys *Please refer the Notes Tab software manual in driver CD for details. 10" Wireless interactive whiteboard User Manual...
  • Page 19 4-3 Through Hotkeys (F1, F2, F3 and F4) you can set 4 shortcuts of any functions. Besides functions listed on the menu, you can browse programs (executable files) you need. 10" Wireless interactive whiteboard User Manual...

  • Page 20: Definitions Of On Screen Display Control Key

    D. Exit the OSD menu To return the regular screen viewing, press the button. If there is no command respond for 10 seconds, OSD menu will be closed automatically. 10" Wireless interactive whiteboard User Manual...

  • Page 21: Osd Menu On Vga Mode

    PHASE is used to adjust the phase control (Phase adjustment may be required to optimize the display quality ) u WHITE BALANCE is used to set the RGB signal voltage level 10" Wireless interactive whiteboard User Manual...
  • Page 22 GAMMA 0 to GAMMA 3. Select “RETURN” to the main menu. RECALL RECALL is used to recall the original factory default setting by selecting “YES”. Select “NO” to return the main menu. 10" Wireless interactive whiteboard User Manual...

  • Page 23: Revision History

    GAMMA 2 GAMMA 3 H-POSITION POSITION RECALL V-POSITION AUTO CLOCK IMAGE PHASE OSD EXIT WHITE BALANCE USER(RED/GREEN/BLUE) 9300K COLOR 6500K ADC BRIGHTNESS 5. Revision History Version Date Note Author ü 2010.02.01 First Version Alicia Liao 10" Wireless interactive whiteboard User Manual...
