Summary of Contents for SAFARI R1100
- Page 1 #R1100 operating instructions...
- Page 2 Pan Lock Pan Handle Concentric Lock Pan Handle Clamp Slide Lock Lever Camera Platform Tilt Drag Clamp Nut Bubble Level Tilt Lock Quick Release Clamp ¼” and pin carriage Camera Plate...
- Page 3 FEATURES AND CONTROLS 55mm Bowl Leg Angle Lock Leg Cover Leg Lock Lever Rubber Foot...
- Page 4 OPERATING INSTRUCTIONS Operating Instructions Thank you for purchasing the SAFARI Before operating please read the follow- tripod system for use with lightweight ing operating instructions. Do not omit portable video camcorders. They are any step. N.B. The safe operation of this...
- Page 5 DRAG CONTROL The SAFARI tripod head provides adjustment for tilt drag control (Fig.3). Rotate clockwise to increase friction resistance, and anti-clockwise to decrease friction resistance.
- Page 6 TRIPOD SETUP Remove the tripod system from the carry bag and stand on a level surface. Setup 1. Separate legs slightly so they are parallel. 2. Working with each leg individually, release the leg lock levers (fig.4). 3. Extend to desired length and return leg Lock levers to locked position.
- Page 7 Mid position setting The mid-angle position is self engaging after closing the leg from the fully spread position. The mid angle position will increase the footprint of the tripod system but offers optimum stability. TRIPOD PULL DOWN Remove the camera from the tripod system.
- Page 8 234 mm (9.2) Transport Length mm (in) 680 mm (26.8) WARRANTY This warrants that the safari tripod system supplied (II) defectiveness is due to neglect, misuse, will, under proper use, be free from defects due excessive heating, accidents, operation contrary to solely to faulty material and workmanship for a instructions for use, or normal wear or tear or;...
